HABYS MASSAGE GUN PRO Instruction Manual & Warranty

Instruction manual & warranty
MASSAGE GUN PRO
User Manual number: 050/2022/3
User Manual release date: 21.08.2024
General safety use conditions.
1. To avoid the risk of electric shock, fire or injury, this product must be
used in accordance with the following rules:
a) Do not submerge in water. Keep away from liquids and sources of
heat. Protect the ventilation openings from dust and dirt particles.
b) Do not remove the screws, do not take the device apart.
c) Do not use continuously for more than an hour. Wait 30 minutes.
before using it again.
d) The device is intended for use by adults only.
e) Keep out of reach of children. Keep out of the reach of children.
f) Do not use the device on the following body parts: genitals, face,
eyes, surgical wounds, infected, broken skin, damaged bones or
joints.
g) Use only on a clean, dry body surface by lightly pressing and gliding
over the body for approximately 60 seconds on one part.
h) In case of pain or other discomfort, discontinue use immediately.
2. Do not use the massager or other vibrating devices without
consulting a doctor in the following cases: pregnancy, diabetes with
complications such as neuropathy or damage to the retina, use of a
pacemaker, recent surgery, epilepsy, migraine, herniated disc,
spondylolisthesis, spondylosis, spondylolysis recent joint
replacement, IUD, metal rods or plates.
3. Weak people and children should be supervised by an adult when
using the device.
4. The above contraindications do not mean a ban on using the
massager, however, we recommend consulting a doctor first.
Cleaning, maintenance and storage.
Clean with a slightly damp towel, wipe dry with a soft cloth. Do not use
alcohol or alcohol-containing agents for cleaning. It is allowed to use only
a small amount of neutral detergent to clean the device.
Attach the attachments when the appliance is switched off, pressing
firmly until the component is firmly seated.
Do not allow liquids to enter the device.
Specification.
Battery: Lithium-ion 2600mAh
Motor: brushless
Number of speed levels: 30
Speed level range: 1300 - 3600rpm
Vibration amplitude: 16mm
Display: LCD
Noise level ≤50dB
Dimensions: 180mm x 255mm x 50mm
Net weight: 1kg
Unpacking and first use.
1. Package Contents:
a) vibration massager
b) 12 replaceable massager tips
c) charging cable USB / USB-C
d) user manual
e) carrying case
Charging requires a charger min. 2A (charger not included).
2. Unpacking.
Remove all security components from the shipping box. Please read
this user manual and all safety instructions carefully before use.
3. Fully charge the device's battery before using it for the first time.
User manual.
1. Charging.
a) Make sure the power switch is in the "OFF" position before
charging.
b) While the battery is charging, the current level will be displayed at
the bottom of the handle with % values and the battery charging
symbol.
c) A full charge takes approximately 4 hours.
d) The current battery level will also be visible on the main display in
the ranges: 40%, 60%, 80% and 100%.
e) The operating time of the device at the highest speed level is
approximately 8 hours.
f) When the battery level drops below 10%, the red LED will flash.
The device should then be charged.
g) For safety reasons, do not use the device while it is charging.
h) To ensure a long service life, please charge the device when the red
light starts flashing.
2. Replacing the massage heads.
a) Remove the caps when the appliance is switched off by pulling and
twisting slightly.
b) Attach the attachments when the device is turned off, pushing
firmly until the component is seated.
3. Enable / Disable.
a) To start the device, move the power switch to the "ON" position.
b) To turn off the device, slide the power switch to the "OFF" position.
4. Speed adjustment.
a) Level 1 will be set by default when the device is turned on.
b) Each press of the "+" button on the main display will increase the
speed to a higher level.
c) Each press of the "-" button on the main display will decrease the
speed to a lower level.
d) The adjustment level ranges are shown in the table.
LEVEL 1-5 1300-1600 rpm
LEVEL 6-10 1700-2000 rpm
LEVEL 11-15 2100-2400 rpm
LEVEL 16-20 2500-2800 rpm
LEVEL 21-25 2900-3200 rpm
LEVEL 26-30 3300-3600 rpm
Note: The device is equipped with a 10-minute work timer to avoid
muscle and fascia damage caused by over-massage.
5. Main and secondary display.
a) All useful information will be displayed on the main display, such
as: battery charge status, currently set speed, indicator of the
correct pressure during operation.
b) The pressure during work will be indicated by diodes: 3 green
diodes as the correct range of pressure during work, red diodes as
too much pressure during work.
c) The secondary display at the bottom of the handpiece will show
the current battery level.
