DS22
!
·
Use caution if installing on heated floor.
·
Do not install door stop within foot traffic area as this may
create a tripping hazard.
1a
Screw Mount
Wall
(Not Included)
Drill
(Not Included)
Pilot Hole
Determine the position and location on the floor. Mark the
mounting position for the mounting hardware and drill a
6.00mm [1/4"] DIA. and 26.00mm [1-1/32"] deep.
2024.11.06
WARNING
!
38.00mm DIA.
[1-1/2"]
TOP VIEW
Door
(Not Included)
TABLE OF CONTENTS
44.00mm DIA.
[1-25/32"]
FRONT VIEW
2a
Place plastic anchor into the pilot hole.
1
. . . . . . . . . . . 1X DS22
. . . . . . . . . . 1X 1-9/16"
Wood Hanger
Bolt
. . . . . . . . 1X Plastic Anchor
31.00mm
[1-3/16"]
Plastic Anchor
(For carpet and
hardwood
flooring only)
Advertisement
Related Manuals for Mockett DS22
Summary of Contents for Mockett DS22
- Page 1 TABLE OF CONTENTS · Use caution if installing on heated floor... . 1X DS22 · Do not install door stop within foot traffic area as this may create a tripping hazard.
- Page 2 Wall (Not Included) Door (Not Included) Flip DS22 upside down and peel off the pre installed adhesive Determine the position and location on the flloor. Mark the backing. Install by aligning DS22 to marked position. Press mounting position. down for a few seconds to ensure door strop is secure.
