BRV2
SPECIFICATIONS
·
Maximum cord diameter is 1-5/32".
1
Make a cut out in the desired location on your work surface.
Cut a hole at 80.00mm[3-5/32"] diameter.
2023.03.15
88.00mm DIA.
[3-15/32"]
TOP VIEW
80.00mm DIA.
[3-5/32"]
CUT OUT
75.00mm DIA.
[2-15/16"]
24.00mm
[15/16"]
FRONT VIEW
2
Tab
Remove BRV2 lid by rotating to match the tab to locking
grooves and lifting from the brush opening.
1
TABLE OF CONTENTS
. . . . . . . . . . . . 1X BRV2
. . . . . . . . . . . . 1X BRV2
21.00mm
[13/16"]
80.00mm DIA.
[3-5/32"]
CUT OUT
BRV2
Lid
Locking
Grooves
Lid
Liner
1.50mm
[1/16"]
