R
Aqua Creek Products
Leaders in Recreation, Fitness and Ability
INSTALLATION & OPERATION MANUAL
MODEL: RANGER 2 -FLAT PACK
CATALOG #: F-RNGR2-KD
1
9889 GARRYMORE LANE
WWW.AQUACREEK.COM
MISSOULA, MT 59808
UPDATED:
2024 AQUA CREEK PRODUCTS. ALL RIGHTS RESERVED.
C
(406) 549-0769
2 - 2/25/2025
FAX (406) 549-2602
Advertisement
Table of Contents
Related Manuals for aqua greek products RANGER 2 -FLAT PACK
Summary of Contents for aqua greek products RANGER 2 -FLAT PACK
- Page 1 Aqua Creek Products Leaders in Recreation, Fitness and Ability INSTALLATION & OPERATION MANUAL MODEL: RANGER 2 -FLAT PACK CATALOG #: F-RNGR2-KD 9889 GARRYMORE LANE WWW.AQUACREEK.COM MISSOULA, MT 59808 UPDATED: 2024 AQUA CREEK PRODUCTS. ALL RIGHTS RESERVED. (406) 549-0769 2 - 2/25/2025...
-
Page 2: Table Of Contents
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY TABLE OF CONTENTS SAFETY INFORMATION................3 ADA REQUIREMENTS FOR POOL LIFTS (US ONLY)......4 PRODUCT OVERVIEW AND APPLICATIONS........... 5 COMPATIBLE ANCHORING OPTIONS ............. 5 PRODUCT INSPECTION ................ -
Page 3: Safety Information
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY IMPORTANT SAFETY INFORMATION SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. -
Page 4: Ada Requirements For Pool Lifts (Us Only)
Aqua Creek Products LEADERS IN RECREATION, FITNESS AND ABILITY ADA REQUIREMENTS FOR POOL LIFTS* (US ONLY) 1009.2.1 Pool Lift Location Pool lift shall be located where the water level does not exceed 48". If entire pool water level exceeds 48", place pool lift where convenient. 1009.2.2 Seat Location In the raised position, the centerline of the seat shall be located over the deck a minimum of 16"... -
Page 5: Product Overview And Applications
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT OVERVIEW AND APPLICATIONS The ADA Compliant, UL Certified, Pro Pool Series, Ranger™ 2 lift is very affordable and is the perfect choice for most in-ground pools or spas. The Ranger™ 2 can be found in hundreds of hotels and motels as well as backyard pools throughout the world. -
Page 6: Product Components
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT COMPONENTS RANGER 2 - FLAT PACK / KD - PART NO. INV03418 ITEM PART NO. QTY. REV. DESCRIPTION REORDER INV03459 KD STOCK BOX RANGER 2 - LINAK... -
Page 7: Component Review
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW KD STOCK BOX RANGER 2 - LINAK - PART NO. INV03459 ITEM PART NO. QTY. REV. DESCRIPTION REORDER INV00588 COVER - UNIVERSAL BATTERY - BLUE... - Page 8 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - BASE - PART NO.INV03034 ITEM PART NO. QTY. REV. DESCRIPTION REORDER INV02090 WELDMENT - BASE - RGR2 INV00464 BS - 3/8"X2"X5/16"-18 SHOULDER BOLT...
- Page 9 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - ACTUATOR BRACKET - INV02998 ITEM PART NO. QTY. REV. DESCRIPTION REORDER INV02018 WELDMENT - ACTUATOR BRACKET INV00447 BRB - 3/8"X1/2"X1/4" BRONZE BUSHING INV00462 BS - 3/8"X1 3/4"X5/16"-18 SHOULDER BOLT...
- Page 10 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - CONTROL ARM - PART NO. INV03067 ITEM PART NO. QTY. REV. DESCRIPTION REORDER INV01874 LASER/WJ - CONROL ARM INV00742 NN - 5/16"-18 NYLOCK NUT...
- Page 11 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - RNGR2 BREAK DOWN SEAT CRADLE - PART NO. INV03411 ITEM PART NO. QTY. REV. DESCRIPTION REORDER ASSEMBLY - KNOCK DOWN RNGR2 VERTICAL...
-
Page 12: Product Assembly
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY • READ ALL INSTRUCTIONS FULLY AND USE ALL COMPONENTS SHOWN IN EACH STEP BEFORE MOVING ON TO THE NEXT STEP. - Page 13 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 3) INSTALL THE MOTOR HOUSING END OF THE ACTUATOR TO THE BASE AS SHOWN IN DETAIL A. USE A ⅜" X 2" SHOULDER BOLT, WASHER AND NYLOCK NUT. THIS LIFT IS DESIGNED TO BE ABLE TO REVERSE WHICH SIDE OF THE LIFT THE CHAIR IS ON .
- Page 14 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 4) INSTALL THE SEAT SECTIONS TO SEAT CRADLE PIECES (VERTICAL AND HORIZONTAL) AS SHOWN USE FOUR 5/16-18 BUTTON HEAD BOLTS AND WASHERS PER SEAT SECTION.
- Page 15 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 5) INSTALL THE VERTICAL SEAT CRADLE ON THE MAIN FRAME AWAY FROM ACTUATOR CASE PROTRUSION AS SHOWN IN DETAIL D. ENSURE THE BRONZE BUSHINGS ARE INSTALLED INTO THE MAIN FRAME AS SHOWN.
- Page 16 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 6) INSTALL THE CONTROL ARM TO THE TOP OF THE SEAT CRADLE BRACKET. ENSURE THE FLANGED BRONZE BUSHING IS ORIENTED CORRECTLY IN THE CONTROL ARM, AND NON-FLANGED BUSHING IS SEATED IN THE SEAT CRADLE.
- Page 17 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 8) FULLY TIGHTEN THE 1-8 NYLOCK JAM NUT FROM STEP 5 THAT HOLDS THE SEAT CRADLE TO THE MAIN FRAME AS SHOWN IN DETAIL G.
- Page 18 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 10) INSTALL THE ARMRESTS AS SHOWN ON BOTH SIDES OF THE VERTICAL MOUNTED SEAT SECTION. ENSURE MOUNT IS ORIENTED CORRECTLY AND COMPLETELY IN CENTER SLOT, CONTACTING BOTTOM...
- Page 19 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 11) INSTALL FOOTREST AS SHOWN IN DETAIL K. ATTACH FOOTREST TO FOOTREST TUBE USING THE BOLT, LOCK WASHER AND FLAT WASHER SHOWN.
- Page 20 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 12) UNDO BATTERY COVER HOOK-AND-LOOP FLAP AND PLACE OVER CONTROL BOX. USE TWO 10-24 X ⅜" SOCKET HEAD SCREWS TO ATTACH THE MOUNTING BRACKET TO THE LIFT THROUGH THE HOLES IN THE BACK OF THE COVER (SEE DETAIL L).
- Page 21 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 13) OPEN BATTERY COVER FLAPS AND ATTACH BATTERY AS SHOWN IN DETAIL M (BATTERY COVER NOT SHOWN) BATTERY - LINAK 24V - 2PC PART NO.
- Page 22 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 15) LOOP EACH SEATBELT STRAP THROUGH THE SLOT INDICATED BELOW AND USE HOOK & LOOP PATCHES TO SECURE THE LOOP(SEE DETAIL P).
-
Page 23: Operation Instructions
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY OPERATION INSTRUCTIONS DOWN DOWN DECK LEVEL 2-BUTTON REMOTE FUNCTION 9889 GARRYMORE LANE WWW.AQUACREEK.COM MISSOULA, MT 59808 UPDATED: 2024 AQUA CREEK PRODUCTS. ALL RIGHTS RESERVED. -
Page 24: Lift Inspection
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY LIFT INSPECTION INFORMATION Test Date: Pool Lift Model: Serial Number: Inspected By: Inspection Notes: Please read and fill out all information carefully Improper use and/or maintenance of pool lift can lead to actuator and/or other mechanical failures and possible personal injury. - Page 25 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY OVERALL VISUAL INSPECTION Corrosion is common with anything in a swimming pool environment; even stainless steel. Proper and regular maintenance and cleaning will prevent most instances of corrosion. Replace any components that have corrosion caused pitting, cracking, thinning of the base metal, or other instances of corrosion that can't be eliminated and/or minimized through thorough cleaning.
- Page 26 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY ANNUAL PHYSICAL POOL LIFT TEST A physical test of the lift's function is required when doing an annual inspection. The lift should always run through a completed cycle without a load prior to each use.
- Page 27 RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY ANNUAL ELECTRONICS INSPECTION Most electronic issues are due to poor electrical connections and/or a defective battery. Always remove the battery and place on the charger when the lift is not in use. NOTE: Even if your lift is equipped with a solar charger, it is a good idea to place the battery on the wall charger periodically or during extended periods of non-use or storage.
-
Page 28: Maintenance Instructions
RANGER 2 -FLAT PACK PRODUCT NAME F-RNGR2-KD Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY MAINTENANCE INSTRUCTIONS BEFORE WEEKLY MONTHLY PROCEDURE DAILY EACH USE Check battery level indicator on control box. Run the lift through a complete test cycle (fully extend actuator) to verify it is functioning properly. -
Page 29: Warranty Information
Aqua Creek Products LEADERS IN RECREATION, FITNESS AND ABILITY LIMITED FIVE (5) YEAR WARRANTY Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall be free from defects in material and workmanship for a period of five (5) years from the date of original purchase , provided that Aqua Creek receives prompt notice in writing of any defect or failure and satisfactory proof thereof, with the following exception(s): Exceptions:... -
Page 30: Basic Troubleshooting
Aqua Creek Products LEADERS IN RECREATION, FITNESS AND ABILITY BASIC TROUBLESHOOTING Make note of the complaint, such as lift is not operating at all, lift won’t return to deck, etc... Make note of any noises the lift may be making, such as grinding, clicking, buzzing, beeping. Try to identify where the noises are coming from, i.e.
