- Page 1 Aqua Creek Products Leaders in Recreation, Fitness and Ability USE THIS MANUAL FOR CATALOG #’s: F-MTY400 / F-MTY400-C / F-MTY400-G/ F-MTY400-T / F-MTY400-W INSTALLATION & OPERATION MANUAL MODEL: MIGHTY 400 CATALOG #: F-MTY400 9889 GARRYMORE LANE WWW.AQUACREEK.COM MISSOULA, MT 59808 UPDATED: 2024 AQUA CREEK PRODUCTS.
-
Page 2: Table Of Contents
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY TABLE OF CONTENTS SAFETY INFORMATION................3 ADA REQUIREMENTS FOR POOL LIFTS (US ONLY)......4 PRODUCT OVERVIEW AND APPLICATIONS........... 5 PRODUCT COMPONENTS................. 6 PRODUCT ASSEMBLY................7 OPERATION INSTRUCTIONS.............. -
Page 3: Safety Information
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY IMPORTANT SAFETY INFORMATION When installing this product, basic safety precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. -
Page 4: Ada Requirements For Pool Lifts (Us Only)
Aqua Creek Products LEADERS IN RECREATION, FITNESS AND ABILITY ADA REQUIREMENTS FOR POOL LIFTS* (US ONLY) 1009.2.1 Pool Lift Location Pool lift shall be located where the water level does not exceed 48". If entire pool water level exceeds 48", place pool lift where convenient. 1009.2.2 Seat Location In the raised position, the centerline of the seat shall be located over the deck a minimum of 16"... -
Page 5: Product Overview And Applications
PRODUCT OVERVIEW AND APPLICATIONS The ADA Compliant, UL Certified, Mighty 600 pool lift is our strongest lift. Like its sister lift, the Mighty 400, the unique patented design provides for a very safe, durable, and reliable lift. Ideal for in-ground... -
Page 6: Product Components
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT COMPONENTS MIGHTY 400 - INV01698 ITEM PART NO. QTY. REV. DESCRIPTION INV03491 ASSEMBLY - ANCHOR SPINDLE - 1.90" DIA. SQ DRIVE INV02792 ASSEMBLY - MAIN FRAME INV01835 RETAINING RING - 1-1/4"... -
Page 7: Product Assembly
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY NOTES: • READ ALL INSTRUCTIONS FULLY AND USE ALL COMPONENTS SHOWN IN EACH STEP BEFORE MOVING ON TO THE NEXT STEP. •... - Page 8 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY BOLT - HEX 5/16"-18X3" PART NO. INV00418 NN - 5/16"-18 NYLOCK NUT 2 PLCS PART NO. INV00742 2 PLCS STEP 2) SLIDE THE SEAT...
- Page 9 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PRODUCT ASSEMBLY STEP 4) REMOVE THE FULLY CHARGED BATTERY FROM THE CHARGER AND INSTALL THE BATTERY TO THE CONTROL BRACKET, ON TOP OF THE CONTROL BOX.
-
Page 10: Operation Instructions
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY OPERATION INSTRUCTIONS CONGRATULATIONS, YOUR LIFT IS NOW READY FOR USE! ROTATION LEFT (COUNTER CLOCKWISE) ROTATION RIGHT (CLOCKWISE) DOWN ROTATE RIGHT (CLOCKWISE) ROTATE LEFT (COUNTER CLOCKWISE) - Page 11 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY LIFT INSPECTION INFORMATION Test Date: Pool Lift Model: Serial Number: Inspected By: Inspection Notes: Please read and fill out all information carefully Improper use and/or maintenance of pool lift can lead to actuator and/or other mechanical failures and possible personal injury.
- Page 12 PRODUCT NAME Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY OVERALL VISUAL INSPECTION Corrosion is common with anything in a swimming pool environment; even stainless steel. Proper and regular maintenance and cleaning will prevent most instances of corrosion. Replace any components that have corrosion caused pitting, cracking, thinning of the base metal, or other instances of corrosion that can't be eliminated and/or minimized through thorough cleaning.
- Page 13 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY PHYSICAL POOL LIFT TEST A physical test of the lift function is required when doing an annual inspection. NOTE: The lift should always be run through a completed cycle without a load prior to each use.
- Page 14 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY ELECTRONICS INSPECTION Most electronic issues are due to pool electrical connections and/or a defective battery. Always remove the battery and place on the charger when the lift is not in use. NOTE: Even if your lift is equipped with a solar charger, it is a good idea to place the battery on the wall charger periodically or during extended periods of non-use or storage.
-
Page 15: Maintenance Instructions
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY MAINTENANCE INSTRUCTIONS BEFORE WEEKLY MONTHLY PROCEDURE DAILY EACH USE Check battery level indicator on control box. Run the lift through a complete test cycle (fully extend actuator) to verify it is functioning properly. -
Page 16: Replacement Parts Order Form
ASSEMBLY - SEAT 18.00" - BLUE HARDWARE ONLY:☐ FULL ASSEMBLY: ☐ INV01903 ACCESSORY - FOOTREST - BLUE HARDWARE ONLY:☐ INV01892 LABEL SHEET - MIGHTY 400 INV01153 BATTERY - VITO 9889 GARRYMORE LANE WWW.AQUACREEK.COM MISSOULA, MT 59808 UPDATED: 2024 AQUA CREEK PRODUCTS. ALL RIGHTS RESERVED. -
Page 17: Component Review
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - ANCHOR SPINDLE - 1.90" DIA. SQ DRIVE - INV03491 ITEM PART NO. QTY. REV. DESCRIPTION WELDMENT - ANCHOR INV03490 SPINDLE SQ DRIVE... - Page 18 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - CONTROL ARM - 51.25" (B) - INV02795 ITEM PART NO. QTY. REV. DESCRIPTION INV02078 WELDMENT - CONTROL ARM - 51.00"...
- Page 19 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW ASSEMBLY - LIFTING ARM - 49.75" - INV02798 ITEM PART NO. QTY. REV. DESCRIPTION INV02085 WELDMENT - LIFTING ARM - 49.75" INV00448 BRB - 1/2"X3/8"X3/8"...
- Page 20 ITEM PART NO. QTY. REV. DESCRIPTION INV02082 WELDMENT - SEAT CRADLE INV01082 END CAP - SQR. 2.00"X.120" MIGHTY 400 - INV01698 ITEM PART NO. QTY. REV. DESCRIPTION INV00819 ROTOMOLD - SEAT 18.00" - BLUE INV01031 HAND GRIP - RUBBER 1.00" DIA.
- Page 21 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY COMPONENT REVIEW STOCK BOX - VITO - INV03287 ITEM PART NO. QTY. REV. DESCRIPTION INV01152 CHARGER - VITO 24V INV01804 LABEL #146 - DAILY CHARGE...
- Page 22 MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY LIMITED FIVE (5) YEAR WARRANTY Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua...
-
Page 23: Basic Troubleshooting
MIGHTY 400 PRODUCT NAME F-MTY400 Aqua Creek Products CATALOG # LEADERS IN RECREATION, FITNESS AND ABILITY BASIC TROUBLESHOOTING Make note of the complaint, such as lift is not operating at all, lift won’t return to deck, etc… Make note of any noises the lift may be making, such as grinding, clicking, buzzing, beeping. Try to identify where the noises are coming from, i.e.
