9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
Check entire box and inside all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical all parts be carefully inspected by the installer prior to installation to ensure no damage
occurred in transit and a damaged part is not used. If any damage occurred in transit, Aqua Creek
Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's warranty
and may aff ect the safety of the user.
Copyright © 2020 Aqua Creek Products All Rights Reserved
US PATENT NUMBER: [D507,769 S] [7,249,386 B2]
Lift safety can only be ensured if the lift is installed and
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• Do not use the Portable Pro Pool 2 for deck-to-waterline
measurements over 13"
• NEVER operate lift without the 11 weight plates installed
OR 650 pounds of sand.
• NEVER use the lift with a dry pool
• For safety reasons, NEVER swim alone
READ CAREFULLY
Portable
Pro Pool 2
PART #: F-PPP2 / F-PPP2S
350 LB. [160 kg] MAXIMUM WEIGHT CAPACITY
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
Read and follow all instructions.
operated according to these instructions.
1
Revised 7/28/20
Advertisement
Related Manuals for aqua greek products Portable Pro Pool 2
Summary of Contents for aqua greek products Portable Pro Pool 2
- Page 1 • Do not allow children to use the lift without adult supervision • NEVER apply direct water pressure to the electronics • Do not use the Portable Pro Pool 2 for deck-to-waterline measurements over 13” • NEVER operate lift without the 11 weight plates installed OR 650 pounds of sand.
- Page 2 Table of Contents PAGE DESCRIPTION PAGE DESCRIPTION Portable Pro Pool 2 Components Portable Pro Pool 2 Lift Parts List Portable Pro Pool 2 Assembly Instructions Portable Pro Pool 2 Cart Parts List Basic Troubleshooting Warranty Proper Care of Pool & Spa Lifts Portable Pro Pool 2 Components 1.
- Page 3 Portable Pro Pool 2 Assembly Instructions (Weight Plates) TOOLS REQUIRED: • 7/16” wrench 1. Using a 7/16” wrench, remove the four (4) nylock nuts and at washers that are currently holding the hood onto the platform. These were installed strictly for shipping purposes and can be thrown away.
- Page 4 Portable Pro Pool 2 Assembly Instructions (Sand Ballast) 1. Fill the ballast tank with sand (not included) as shown below. Gently shake or tap the tank sides periodically to help level the sand. Alternate between ll ports to make sure sand is evenly distributed (use a large funnel to help in this step).
- Page 5 Portable Pro Pool 2 Assembly Instructions 4. Attach seat belt to the seat as shown in diagram to the LOOP ON TOP FOR EASY ACCESS right. 5. Place the battery on the charger and bring to a full charge. 6. Apply dielectric grease on the metal tabs of the battery and the control box on the lift.
- Page 6 Basic Troubleshooting Problem: The lift won’t move. Solution: 1. Make sure the battery is properly seated: You should hear a click when Click! the battery is properly seated on the control box or charger. NOT Properly Attached: Properly Attached: Note: the white bracket is Note: the white bracket in front of the silver clip, is behind the silver clip,...
- Page 7 Proper Care of Pool & Spa Lifts BEFORE DAILY WEEKLY MONTHLY PROCEDURE EACH USE Check battery level indicator on control box Run the lift through a complete test cycle (fully ex- tend actuator) to verify it is functioning properly Wash lift with fresh water and dry with clean, soft, ...
- Page 8 Portable Pro Pool 2 Lift Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION PF2-100-02 BASE WELDMENT BH 5/16 X 4 1/2 5/16-18 X 4 1/2 HCS MAIN FRAME ASSEM- WF 5/16 5/16 FLAT WASHER PF2-200-03 NN 5/16...
- Page 9 Portable Pro Pool 2 Cart Parts List Item # QTY PART # DESCRIPTION PP2-100WM-00 PORTABLE PRO POOL 2 CART WELDMENT PP2-109-00 WHEEL SPACER PP2-110-00 AXLE SHAFT 5.00008.459.2.SSRB WHEEL, RUBBER, PERFORMA, SS BEARING 2NF100SA 4” SS CASTER ASSEMBLY BB 5/16 X 3/4...
- Page 10 Revised_07.24.20 AQUA CREEK PRODUCTS, LLC LIMITED FIVE (5) YEAR WARRANTY: PORTABLE PRO POOL 2 LIFT (ITEM #’s F-PPP2, F-PPP2-T, F-PPP2-G, F-PPP2-C, F-PPP2S, F-PPP2S-T, F-PPP2S-G, F-PPP2S-C) Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua...
