- Page 1 ® AQUAGUARD SURE DELIGHT NXT...
-
Page 2: Prerequisites For Installation
PREREQUISITES FOR INSTALLATION Product installation should be done only by a trained Eureka Forbes Service Technician only. 1. Input water must be tested for Total Dissolved Solids (TDS) and Total Hardness - Install the product in a dry ventilated place. Keep it away from direct sunlight, heating devices or areas below 10 - The purifier should be placed in area which is free of ants/insects/other pests. - Page 3 THE PROCESS OF PURIFICATION (For UV+UF Variant) Stage Treatment Materials Benefits Multi-layered Polypropylene Removes fine suspended particles such as dust, dirt mud and sand from i - Filter roving wound cartridge water. Dust-free Bacteriostatic Activated Reduces excess chlorine and organic impurities. Also adsorbs bad taste and Chemi-Block Carbon block filter odor from the water.
-
Page 4: Technical Specifications
TDS concerns, we recommend to install the Taste Enhancer cartridge. supplied , UF Filter The above accessories are available with our company at an additional cost. ELECTRICAL SPECIFICATIONS Performance data sheets are available with Eureka Forbes Technical Documentation Power Rating 20 Watts Centre. Power Supply Input 230V AC,50 Hz Warranty void if the product is not installed as per recommendations. - Page 5 ® LED INDICATION CHART FOR AQUAGUARD SURE Delight NXT UV+UF PARAMETERS LED INDICATION REMARKS Red, Green, and Blue will glow one after other for 1 sec. Blue LED will be Solid Power All LEDs if Power is Available. Power Blue LED will be solid. Purification Process Service RED LED will Be OFF...
- Page 6 THE PROCESS OF PURIFICATION (For RO+UV Variant) Stage Treatment Materials Benefits Multi-layered Polypropylene Removes fine suspended particles such as dust, dirt mud and sand from i-Filter™ Roving Wound Cartridge water. Dust-free Bacteriostatic Activated Reduces excess chlorine and organic impurities. Also adsorbs bad taste and Chemi-Block™...
- Page 7 40 Watts The above accessories are available with our company at an additional cost. Power Supply Input 230V AC,50 Hz Performance data sheets are available with Eureka Forbes Technical Documentation Operating Voltage Range 150 VAC to 280 VAC, 50 Hz Centre.
- Page 8 ® LED INDICATION CHART FOR AQUAGUARD SURE Delight NXT RO+UV PARAMETERS LED INDICATION REMARKS Red, Green, and Blue will glow one after other for 1 sec. Blue LED will be Solid Power All LEDs if Power is Available. Power Blue LED will be solid. Purification Process Service RED LED will Be OFF...
- Page 9 THE PROCESS OF PURIFICATION (For RO+UV+UF Variant) Stage Treatment Materials Benefits Multi-layered Polypropylene Removes fine suspended particles such as dust, dirt mud and sand from i-Filter™ Roving Wound Cartridge water. Dust-free Bacteriostatic Reduces excess chlorine and organic impurities. Also adsorbs bad taste and Chemi-Block™...
- Page 10 40 Watts The above accessories are available with our company at an additional cost. Power Supply Input 230V AC,50 Hz Performance data sheets are available with Eureka Forbes Technical Documentation Operating Voltage Range 150 VAC to 280 VAC, 50 Hz Centre.
- Page 11 ® LED INDICATION CHART FOR AQUAGUARD SURE Delight NXT RO+UV PARAMETERS LED INDICATION REMARKS Red, Green, and Blue will glow one after other for 1 sec. Blue LED will be Solid Power All LEDs if Power is Available. Power Blue LED will be solid. Purification Process Service RED LED will Be OFF...
- Page 12 LIST OF CONSUMABLE CARTRIDGES Refer the list of cartridges as per the standard purification mentioned in technical specification CONSUMABLE COMPONENTS AVERAGE SERVICE LIFE i-Filter™ Cartridge 6,000 litres Chemi block 6,000 litres RO Membrane Cartridge 6,000 litres UF Cartridge 6,000 litres UV Lamp (11W) 8,000 burning hours* UV Lamp (4W)
-
Page 13: Cleaning And Disinfection Of Water Storage Tank
9. Now your unit is ready to use. In case you notice any medicinal taste/smell, discard the tank of water fully & let it refill again. 10. Please ensure that this disinfection process is carried out by the authorised installation person/service technician during first installation and in every subsequent mandatory servicing of the product. *Available with Eureka Forbes Service Technician... - Page 14 Eureka Forbes Limited, during prolonged non-usage of your water purifier. Beyond usable life of the filters, it is recommended to replace with new ones. • Ensure that the replacement of the consumable cartridges is done by a trained Eureka Forbes technician when end-of-life filter change indication appears.
- Page 15 Flushed out water from a RO system is an unavoidable technology limitation. It maintains the performance of the purification process and the service life of the membrane also. Eureka Forbes has taken utmost care to minimize the water wastage in our RO system without compromising on the performance of the product.
- Page 16 2. Have you kept the purified water in 2. Dispose of water and clean the tank. the tank for too long? 3. Call an authorised Eureka Forbes Service 3. Is it time to change the filter? Technician. Less water has been purified 1.
-
Page 17: Warranty Terms And Conditions
WARRANTY TERMS & CONDITIONS* 1. The Products are warranted against manufacturing defects for a period of twelve (12) months from the date of original purchase. 2. The Customer will notify the Company in writing promptly of any defects noticed and give the Company or its authorized agent adequate opportunity to inspect test and remedy them for which the Customer will deposit the goods at its own expense, if so, required by the Company with the Company's Office/Service Centre along with the original invoice in the city where they are sold. - Page 18 3. If during such servicing it is necessary for the company to replace or repair defective components or parts, the customer shall be required to pay for the same as per the company's prevailing price list. 4. Eureka Forbes limited reserves the right to offer annual maintenance contract/ensure availability of spares only up to 7 years from the date of invoice. *Conditions apply.
-
Page 19: Environment Protection
Should you have any queries, the nearest authorized service center of Eureka Forbes will be able to guide you.
