Eureka Forbes Aquaguard Aquasure Smart Plus RO+UV+MTDS User Manual

AquaSure Smart Plus RO+UV+MTDS has approx. 6 litres of purified water storage capacity and the rate of recovery for purified water is approx 25%. It is also
equipped with a Microswitch Float Valve Mechanism which automatically shuts off the pump. The sealed lid of the storage tank protects water from dust and other
foreign objects.
TDS modulator is located inside the product. As per factory setting it comes in fully closed mode. TDS level of output water can be increased by slowly loosening
(anticlockwise) the spindle of the TDS modulator. Normally a slight quarter turn is enough to increase the TDS of output water. Rotating the spindle in clockwise
direction, closes the TDS modulator and reduces the level of TDS blending. Please note that TDS blending and its adjustment is dependent upon the level of TDS of
Input water and on the TDS reduction capacity of the RO Membrane. TDS adjustment should be done by the Company authorized personnel.
Not a part of the product, Membrane life enhancer is recommended if the input water TDS is more than 1,000 ppm (mg/L) or input water hardness is more than
***
300 ppm (mg/L). Available at extra cost.
***
Note: The color and speci cations of the product may vary from
that shown on the user manual.
1. This adsorbs colour, odour, excess chlorine & organic impurities from the
incoming water.
2. It removes very fine turbidity from the water.
3. Its Unique "Particle Trap Filter" entraps any released micro particle.
