SMARTPULSE™ MV INSTRUCTION MANUAL
1.3 Interior View – Standard NEMA 1 Control Panel
120VAC Terminal Block
24VDC
Terminal
Block
24VDC
Fuse
Ethernet
Switch
Power
Supply
Smart
Relay
Medium Voltage
Digital Electronics
Module
Serving the Electrical Industry Since 1892
Test Resistor
Relay
Potential
Transformer
™
NGR Terminal Block
Power Bus
Potential
Transformer
Fuse
Phone: 800-537-6144 / 859-283-0778 • Fax: 859-283-2978
6
Alarm Relays
Pulse
Contactor
Control
Terminal
Block
Main Switch
(Control Power)
Pulse
Contactor
Control
Power
Fuses
NGR Current
Transformer
