SMARTPULSE™ MV INSTRUCTION MANUAL
Section 1 – Equipment Overview
NGR
Neutral Grounding Resistor
HRG
High Resistance Grounding
HMI
Human Machine Interface
1.1 Exterior View – NEMA 1 Medium Voltage HRG Cabinet
Resistor Compartment
Touchscreen User
Interface
HRG Controls
Compartment
