Service Manual
©
Copyright 2003 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by SL 0406 Service Audio
Version 1.0
TABLE OF CONTENTS
Location of PCBs & Version variations ...................... 1-2
Technical Specifications ............................................. 1-3
Measurement setup .................................................... 1-4
Service Aids, Safety Instruction, etc. .......................... 1-5
Connections & Functional Overview ............. 1-7 to 1-12
Disassembly Instructions & Service positions .............. 2
Service Test Programs .................................................. 3
Set Block diagram ...................................................... 4-1
Set Wiring diagram ..................................................... 4-2
Front Control Board ....................................................... 5
Front Display Board ....................................................... 6
ECO6 Tuner Board : Systems Non-Cenelec ............. 7A
Systems Cenelec ..................... 7B
PWR303 Module UCD 100-150W for FWM569 ......... 8A
PWR303 Module UCD 200-250W for FWM587 ......... 8B
AF12 Board .................................................................... 9
5DTC Module (MP3 Version) ...................................... 10
Set Mechanical Exploded view & parts list ................. 11
Printed in The Netherlands
Subject to modification
FWM569
Page
LASER PRODUCT
FW-M569
/37
FW-M587
/37
FWM587
CLASS 1
3140 785 32860
GB
