- Page 1 USER’S MANUAL AIO-200-ASL-3L Series All IN One Touch Panel PC...
-
Page 2: Table Of Contents
AIO-200-ASL-3L l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 03 Revision ………………………………………………..……………….…......…….. 03 Disclaimer ………………………………….………………………….…………………....03 Copyright Notice ………………………………………………………………………....03 Trademarks Acknowledgment …………..………………………………....... 03 Environmental Protection Announcement ………………….…………………..03 Safety Precautions …………………………………….…………….…………………………….. 04 Technical Support and Assistance ………………….…………….………………... 05 Conventions Used in this Manual ……………………………….….…………….... 05 Package Contents ……………………………………………………….…………….... -
Page 3: Prefaces
2025/01/06 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc. -
Page 4: Safety Precautions
AIO-200-ASL-3L l User’s Manual Preface Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. ⚫... -
Page 5: Technical Support And Assistance
Preface AIO-200-ASL-3L l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at https://premioinc.com/ where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. -
Page 6: Package Contents
Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty AIO-200-ASL-3L Series All IN One Touch Panel PC Adapter 60W 12V 5A 128G M.2 B key SATA SSD 8GB DDR5 4800 MT/s Ordering Information Model No. -
Page 7: Available Models
AIO-200-ASL-3L l User’s Manual Preface Available Models Model No. Description 10.1” Full WXGA Capacitive All IN One Touchscreen Computer AIO-W210-3L-N97 with Intel® Alder lake N97 Processor, 3x 2.5 GbE LAN 10.1” Full WXGA Capacitive All IN One Touchscreen Computer AIO-W210-3L-X7835RE with Intel®... -
Page 8: Chapter 1 Product Introductions
Chapter 1 Product Introductions... -
Page 9: Overview
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.1 Overview Key Features ⚫ 10.1“ / 15.6“ / 21.5" All IN One Touch Panel PC ⚫ World Class Certifications for Safety and Reliability: CE/FCC Class A/CB/UL/UKCA/IC ⚫ Front IP65 Rating for protection against water and dust ⚫... -
Page 10: Hardware Specification
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification Display AIO-W210-ASL-3L AIO-W215-ASL-3L AIO-W221-ASL-3L LCD Size 10.1" (16:10) 15.6" (16:9) 21.5" (16:9) Max. Resolution 1280 x 800 1920 x 1080 (FHD) 1920 x 1080 (FHD) Brightness (cd/m2) Contrast Ratio 800:1 800:1 1,000:1... - Page 11 AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions Operating System 1x DP 1.4a up to 4096 × 2304 @60Hz DisplayPort Windows Windows 10 / Windows 11 HDMI 1x HDMI 1.4b up to 3840x2160 @30Hz Linux Linux Ubuntu 22.04 2x RS-232/422/485 Power 2x USB 3.2 Gen 2 (10 Gbps) Power Adapter...
-
Page 12: System I/O
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.3 System I/O 1.3.1 AIO-W210-ASL-3L Power On/Off LAN port Press to power-on or power-off the system Used to connect the system to a local area network USB 3.2 Gen 2 port Used to connect USB 3.2 device DisplayPort Used to connect a DisplayPort monitor DC IN... -
Page 13: Aio-W215-Asl-3L
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.3.2 AIO-W215-ASL-3L Power On/Off LAN port Press to power-on or power-off the system Used to connect the system to a local area network USB 3.2 Gen 2 port Used to connect USB 3.2 device DisplayPort Used to connect a DisplayPort monitor DC IN... -
Page 14: Aio-W221-Asl-3L
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.3.3 AIO-W221-ASL-3L Power On/Off LAN port Press to power-on or power-off the system Used to connect the system to a local area network USB 3.2 Gen 2 port Used to connect USB 3.2 device DisplayPort Used to connect a DisplayPort monitor DC IN... -
Page 15: Mechanical Dimension
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 AIO-W210-ASL-3L Unit: mm... -
Page 16: Aio-W215-Asl-3L
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.4.2 AIO-W215-ASL-3L Unit: mm... -
Page 17: Aio-W221-Asl-3L
AIO-200-ASL-3L l User’s Manual Chapter 1: Product Introductions 1.4.3 AIO-W221-ASL-3L Unit: mm... -
Page 18: Chapter 2 Front Panel Controls
Chapter 2 Panel Controls... -
Page 19: Users Controls
AIO-200-ASL-3L l User’s Manual Chapter 2: Panel Controls 2.1 Users Controls Power On/Off Power Button System power on or off. -
Page 20: Chapter 3 System Setup
Chapter 3 System Setup... -
Page 21: Replacement Of Internal Modules
AIO-200-ASL-3L l User’s Manual Chapter 3: System Setup Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.1 Replacement of Internal Modules In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source. 1. -
Page 22: Replacement Of Memory Module
AIO-200-ASL-3L l User’s Manual Chapter 3: System Setup 3.2 Replacement of Memory Module 1. Pull out the locking tabs on both sides of the memory slot to release the memory module, allowing it to pop out. 2. After the memory module pops up, pull it out. Carefully remove the thermal pad underneath the memory module. -
Page 23: Replacement Of M.2 Storage Module
AIO-200-ASL-3L l User’s Manual Chapter 3: System Setup 3.3 Replacement of M.2 Storage Module 1. Use a screwdriver to remove the single screw securing the M.2 card. After removing the M.2 card, carefully remove the thermal pad underneath. -
Page 24: Install Wireless Network Card And Antenna
AIO-200-ASL-3L l User’s Manual Chapter 3: System Setup 3.4 Install wireless network card and antenna 1. Install the network card in the designated red frame and secure it with screws. 2. Ensure the internal antenna is securely connected to the network card, and the antenna interface is properly installed in the designated opening on the chassis cover. - Page 25 AIO-200-ASL-3L l User’s Manual Chapter 3: System Setup 3. Connect the external antenna to the internal antenna, reattach the main unit to the screen following the original steps, and secure it with the four screws.
-
Page 26: Appendix
AIO-200-ASL-3L l User’s Manual Appendix – Panel Mount VESA Mount / Panel Mount: Panel mount bracket VESA mount bracket (75mm x 75mm/100mm x 100mm) Model Panel Mount Kit M4X6L x8 pcs AIO-W210-ASL-3L AIO-W215-ASL-3L AIO-W221-ASL-3L... -
Page 27: Mounting Guide
AIO-200-ASL-3L l User’s Manual Appendix – Panel Mount Mounting Guide Flush Mount / Panel Mount: • Cut hole in the wall w/ dimensions according to the screen size you have purchased. Please refer to the next page for the list of cutout dimensions and max wall depths Max. - Page 28 AIO-200-ASL-3L l User’s Manual Appendix – Panel Mount AIO Series Model Wall Cut-Out (W x H) Unit: mm Max Wall Thickness (mm) AIO-W210-ASL-3L 249 x 163 AIO-W215-ASL-3L 394 x 243 AIO-W221-ASL-3L 528 x 318...
- Page 29 Premio Inc. All Rights Reserved www.premioinc.com...
