- Page 1 USER’S MANUAL AIO Series All IN One Touch Panel PC...
-
Page 2: Table Of Contents
AIO Series l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 03 Revision ………………………………………………..……………….…......…….. 03 Disclaimer ………………………………….………………………….…………………....03 Copyright Notice ………………………………………………………………………....03 Trademarks Acknowledgment …………..………………………………....... 03 Environmental Protection Announcement ………………….…………………..03 Safety Precautions …………………………………….…………….…………………………….. 04 Technical Support and Assistance ………………….…………….………………... 05 Conventions Used in this Manual ……………………………….….…………….... -
Page 3: Prefaces
Preface AIO Series l User’s Manual Prefaces Revision Revision Description Date Manual Released 2024/06/18 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. -
Page 4: Safety Precautions
AIO Series l User’s Manual Preface Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. -
Page 5: Technical Support And Assistance
Preface AIO Series l User’s Manual Technical Support and Assistance 1. Visit the C&T Solution Inc website at https://www.candtsolution.com/ where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. -
Page 6: Package Contents
AIO Series l User’s Manual Preface Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty AIO-200-ADL-N97 Series All IN One Touch Panel PC Adapter 60W 12V 5A 128G M.2 B key SSD... -
Page 7: Chapter 1 Product Introductions
Chapter 1 Product Introductions... -
Page 8: Overview
AIO Series l User’s Manual Chapter 1: Product Introductions 1.1 Overview Key Features ⚫ 10.1“ / 15.6“ / 21.5" All IN One Touch Panel PC ⚫ World Class Certifications for Safety and Reliability: CE/FCC/CB/UL/UKCA/IC ⚫ Front IP65 Rating for protection against water and dust ⚫... -
Page 9: Hardware Specification
AIO Series l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification Display AIO-W210ADL-N97 AIO-W215-ADL-N97 AIO-W221-ADL-N97 LCD Size 10.1" (16:10) 15.6" (16:9) 21.5" (16:9) Max. Resolution 1280 x 800 1920 x 1080 (FHD) 1920 x 1080 (FHD) Brightness (cd/m2) Contrast Ratio... - Page 10 AIO Series l User’s Manual Chapter 1: Product Introductions Operating System • DisplayPort • Windows HDMI / DP / LVDS / eDP Windows 10 / Windows 11 • COM • Linux 2x RS-232/422/485 by internal cable Linux Ubuntu 22.04 • USB Power •...
-
Page 11: System I/O
AIO Series l User’s Manual Chapter 1: Product Introductions 1.3 System I/O 1.3.1 AIO-W210-ADL-N97 Power On/Off LAN port Press to power-on or power-off the system Used to connect the system to a local area network USB 3.2 Gen 2 port Used to connect USB 3.2 device... - Page 12 AIO Series l User’s Manual Chapter 1: Product Introductions 1.3.2 AIO-W215-ADL-N97 Power On/Off LAN port Press to power-on or power-off the system Used to connect the system to a local area network USB 3.2 Gen 2 port Used to connect USB 3.2 device...
- Page 13 AIO Series l User’s Manual Chapter 1: Product Introductions 1.3.3 AIO-W221-ADL-N97 Power On/Off LAN port Press to power-on or power-off the system Used to connect the system to a local area network USB 3.2 Gen 2 port Used to connect USB 3.2 device...
-
Page 14: Mechanical Dimension
AIO Series l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 AIO-W210-ADL-N97 Unit: mm... - Page 15 AIO Series l User’s Manual Chapter 1: Product Introductions 1.4.2 AIO-W215-ADL-N97 Unit: mm...
- Page 16 AIO Series l User’s Manual Chapter 1: Product Introductions 1.4.3 AIO-W221-ADL-N97 Unit: mm...
-
Page 17: Chapter 2 Front Panel Controls
Chapter 2 Panel Controls... -
Page 18: Users Controls
AIO Series l User’s Manual Chapter 2: Panel Controls 2.1 Users Controls Power On/Off Power Button System power on or off. -
Page 19: Chapter 3 System Setup
Chapter 3 System Setup... -
Page 20: Replacement Of Internal Modules
AIO Series l User’s Manual Chapter 3: System Setup Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.1 Replacement of Internal Modules In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source. -
Page 21: Replacement Of Memory Module
AIO Series l User’s Manual Chapter 3: System Setup 3.2 Replacement of Memory Module 1. Pull out the locking tabs on both sides of the memory slot to release the memory module, allowing it to pop out. 2. After the memory module pops up, pull it out. -
Page 22: Replacement Of M.2 Storage Module
AIO Series l User’s Manual Chapter 3: System Setup 3.3 Replacement of M.2 Storage Module 1. Use a screwdriver to remove the single screw securing the M.2 card. After removing the M.2 card, carefully remove the thermal pad underneath. -
Page 23: Install Wireless Network Card And Antenna
AIO Series l User’s Manual Chapter 3: System Setup 3.4 Install wireless network card and antenna 1. Install the network card in the designated red frame and secure it with screws. 2. Ensure the internal antenna is securely connected to the network card, and the antenna interface... - Page 24 AIO Series l User’s Manual Chapter 3: System Setup 3. Connect the external antenna to the internal antenna, reattach the main unit to the screen following the original steps, and secure it with the four screws.
- Page 25 AIO Series l User’s Manual Appendix – Panel Mount VESA Mount / Panel Mount: Panel mount bracket VESA mount bracket (75mm x 75mm/100mm x 100mm) Model Panel Mount Kit AIO-W210-ADL-N97 AIO-W215-ADL-N97 AIO-W221-ADL-N97...
-
Page 26: Appendix
AIO Series l User’s Manual Appendix – Panel Mount Mounting Guide Flush Mount / Panel Mount: • Cut hole in the wall w/ dimensions according to the screen size you have purchased. Please refer to the next page for the list of cutout dimensions and max wall depths Max. - Page 27 AIO Series l User’s Manual Appendix – Panel Mount AIO Series Model Wall Cut-Out (W x H) Unit: mm Max Wall Thickness (mm) AIO-W210-ADL-N97 247 x 161 AIO-W215-ADL-N97 392 x 241 AIO-W221-ADL-N97 526 x 316...
- Page 28 Premio Inc. All Rights Reserved www.premioinc.com...
