- Page 1 Køleskab Brugsanvisning Refrigerator User Manual Kjøleskap Bruksanvisning S9C1741E...
-
Page 2: Table Of Contents
The information can be found on the rating plate. Warning / Caution-Safety information General information and tips Environmental information VISIT OUR WEBSITE: To get usage advice, brochures, trouble shooter, service and repair information: www.smeg.com/services/customer-service CONTENTS 1. SAFETY INFORMATION.................20 2. SAFETY INSTRUCTIONS................22 3. INSTALLATION....................24 4. CONTROL PANEL..................26 5. -
Page 3: Children And Vulnerable People Safety
1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 years • and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. -
Page 4: Safety Instructions
WARNING: Do not use mechanical devices or other means • to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING: Do not damage the refrigerant circuit. • WARNING: Do not use electrical appliances inside the food • storage compartments of the appliance, unless they are of the type recommended by the manufacturer. -
Page 5: Electrical Connection
2.2 Electrical connection • Do not put electrical appliances (e.g. ice cream makers) in the appliance unless they are stated applicable by the WARNING! manufacturer. Risk of fire and electric shock. • If damage occurs to the refrigerant circuit, make sure that there are no flames and WARNING! sources of ignition in the room. -
Page 6: Installation
2.5 Care and cleaning and baskets. Door gaskets are available for at least 10 years after the model has been discontinued. The duration may be WARNING! longer in your country. For further Risk of injury or damage to the appliance. information, please visit our website. - Page 7 3.1 Dimensions ² the height, width and depth of the appliance including the handle, plus the space Overall dimensions ¹ necessary for free circulation of the cooling 1772 Overall space required in use ³ H3 (A+B) 1816 ¹ the height, width and depth of the appliance without the handle 1068 Space required in use ²...
-
Page 8: Ventilation Requirements
3.2 Location in compliance with current regulations, consulting a qualified electrician. To ensure appliance's best functionality, you • The manufacturer declines all should not install the appliance in a place with responsibility if the above safety direct sunlight. Do not install the appliance precautions are not observed. -
Page 9: Switching Off
Freezer temperature indicators To freeze fresh food activate the 4.1 Switching on Extra Freeze function at least 24 hours before placing the food to complete pre- 1. Insert the plug into the wall socket. freezing. 2. Press and hold the appliance ON/OFF button. -
Page 10: Movable Shelves
1. Gradually pull the shelf up until it comes free. 2. Reposition as required. 2. Push the rails inside the cabinet to avoid damage to the appliance when closing the door. 5.2 Movable shelves The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. -
Page 11: Temperature Indicator
2. Place the rear part of the drawer (1) on the rails. This device activates automatically when needed. The fan operates only when the door is closed. Do not remove the cover of the fan. 3. Keep the front of the drawer (2) lifted up while pushing the drawer in. -
Page 12: Hints And Tips
5.8 Thawing CAUTION! Deep-frozen or frozen food, prior to being In the event of accidental defrosting, for consumed, can be thawed in the refrigerator example due to a power failure, if the or inside a plastic bag under cold water. power has been off for longer than the This operation depends on the time available value shown on rating plate under "rising... - Page 13 • Leave enough space around the food to allow air to circulate freely. Type of food Shelf • For adequate storage refer to food life packaging label to see the shelf life of (month food. • It is important to wrap the food in such a Lean fish (e.g.
-
Page 14: Care And Cleaning
• Meat (all types): wrap in a suitable • Butter and cheese: place in an airtight packaging and place it on the glass shelf container or wrap in an aluminium foil or a above the vegetable drawer. Store meat polythene bag to exclude as much air as for at most 1-2 days. -
Page 15: Defrosting Of The Freezer
7.4 Defrosting of the freezer 3. Leave the door open. Protect the floor from the defrosting water e.g. with a cloth or a flat vessel. CAUTION! 4. In order to speed up the defrosting Never use sharp metal tools to scrape off process, place a pot of warm water in the frost from the evaporator as you could freezer compartment. - Page 16 Problem Possible cause Solution There is no voltage in the mains Connect a different electrical ap‐ socket. pliance to the mains socket. Con‐ tact a qualified electrician. The appliance is noisy. The appliance is not supported Check if the appliance stands properly.
- Page 17 Problem Possible cause Solution Food products are not wrapped Wrap the food products better. properly. Temperature is set incorrectly. Refer to "Control panel" chapter. Appliance is fully loaded and is Set a higher temperature. Refer set to the lowest temperature. to "Control panel"...
-
Page 18: Replacing The Lamp
Problem Possible cause Solution The thickness of the frost is Defrost the appliance. greater than 4-5 mm. The door has been opened often. Open the door only if necessary. The Extra Freeze function is Refer to "Extra Freeze function" switched on. section. -
Page 19: Noises
9. NOISES SSSRRR! BRRR! BLUBB! HISSS! CLICK! 10. TECHNICAL DATA The technical information is situated in the It is also possible to find the same information rating plate on the internal side of the in EPREL using the link https://eprel.ec.europa.eu and the model appliance and on the energy label. - Page 20 222384470-A-452024...
