Operating and installation instructions Induction hobs To avoid the risk of accidents or damage to the appliance it is essen- tial to read these instructions before it is installed and used for the first time. en-GB M.-Nr. 12 430 221...
Hob data ........................32 Commissioning......................33 Unpacking the hob ......................33 Cleaning the hob for the first time ................33 Switching on the hob for the first time................ 33 Miele@home ........................34 Installing the Miele app ................... 34 Setting up Miele@home ..................34...
Page 3
Contents Establishing a direct connection with the cooker hood..........37 Operation ........................39 Safety notes for operation..................... 39 Switching the hob on ..................... 40 Switching off a cooking zone/the hob ................. 40 Positioning cookware..................... 40 Power level ........................41 Setting the power level .................... 41 Setting the power level –...
Page 4
Contents Good to know......................... 50 How induction hobs work ..................... 50 Noises ..........................50 Pans..........................51 Adjusting settings ......................52 Cleaning and care ......................55 Safety notes on cleaning and care ................55 Unsuitable cleaning agents................... 56 Troubleshooting......................57 Messages in the display ....................57 Unexpected behaviour....................
Page 5
Contents UK Conformity declaration ................... 90...
Miele cannot be held liable for injury or damage caused by non- compliance with these instructions. Keep these instructions in a safe place and pass them on to any fu-...
Warning and Safety instructions Correct application This hob is intended for domestic use and use in other similar en- vironments. This hob is not intended for outdoor use. It is intended for domestic use only to cook food and keep it warm. ...
Page 8
Warning and Safety instructions Safety with children Children under 8 years of age must be kept away from the hob un- less they are constantly supervised. Children over 8 years of age may use the hob without supervision if its operation has been clearly explained to them and they are able to use it safely.
Page 9
Unauthorised installation, maintenance and repairs can cause con- siderable danger for the user. Installation, maintenance and repairs must only be carried out by a Miele authorised technician. Damage to the hob can compromise your safety. Check the hob for ...
Page 10
Miele authorised service technician. Otherwise the warranty is invalidated. Miele can only guarantee the safety of the appliance when genuine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts. The hob is not intended for use with an external timer switch or a ...
Warning and Safety instructions Correct use The hob gets hot when in use and remains hot for a while after be- ing switched off. There is a danger of burning until the residual heat indicators go out. Oil and fat can overheat and catch fire. Do not leave the hob unat- ...
Page 12
Warning and Safety instructions When using an electrical appliance, e.g. a hand-held food blender, near the hob, ensure that the cable of the electrical appliance cannot come into contact with the hot hob. The insulation on the cable could become damaged.
Page 13
Warning and Safety instructions Metal utensils stored in a drawer under the hob can become hot if the appliance is used intensively for a long time. The hob is fitted with a cooling fan. If a drawer is fitted directly un- ...
Page 14
(see “Familiarisation – Safety switch-off”). Miele will guarantee to supply functional spare parts for a min- imum of 10 years and up to 15 years following the discontinuation of...
Recycling the packaging material re- with Miele, free of charge. By law, you duces the use of raw materials. Use ma- are solely responsible for deleting any terial-specific collection points for valu-...
Familiarisation Your hob KM 7360 FR, KM 7360 FL a Cooking zone with Booster function b Cooking zone with Booster function c Cooking zone with Booster function d Controls and indicators...
Familiarisation KM 7361 FR, KM 7361 FL a Cooking zone with Booster function b Cooking zone with Booster function c Cooking zone with Booster function d Cooking zone with Booster function e Controls and indicators...
Familiarisation KM 7363 FR, KM 7363 FL a Cooking zone with Booster function b Cooking zone with Booster function c Flex cooking zone with Booster can be combined with Flex cooking zone to form Flex cooking area d Flex cooking zone with Booster e Controls and indicators...
Familiarisation KM 7373 FR, KM 7373 FL a Cooking zone with Booster function b Cooking zone with Booster function c Flex cooking zone with Booster can be combined with Flex cooking zone to form Flex cooking area d Flex cooking zone with Booster e Controls and indicators...
Familiarisation Controls and display a Hob On/Off sensor control b Numerical display sensor controls – To set the power level – To set the times c Flex cooking zones sensor control (depending on model) For manual connection/disconnection of Flex cooking zones d Stop&Go sensor control To stop/start a cooking process in progress e Stop&Go display...
Page 21
Familiarisation j Cooking zone selection and display sensor control Cooking zone is ready for operation to Power level Residual heat Auto heat-up Cookware missing or unsuitable Booster function Keeping warm k Entry sensor control –...
Familiarisation Cooking zones KM 7360 FR, KM 7360 FL Linked Cooking Max. rating Ø in cm cooking zone in watts for 230 V zone Normal 2300 14–28 Booster 3000 Normal 2300 11–22 Booster 3000 Normal 1350 9–16 Booster 1850 Total 6600 Cookware with a base diameter within the given range may be used.
Page 23
Familiarisation KM 7361 FR, KM 7361 FL Linked Cooking Max. rating Ø in cm cooking zone in watts for 230 V zone Normal 2300 11–22 Booster 3000 Normal 1350 9–16 Booster 1850 Normal 1400 10–19 Booster 2100 Normal 1400 10–19 ...
Page 24
Familiarisation KM 7363 FR, KM 7363 FL Size in cm Linked Cooking Max. rating cooking zone in watts for 230 V Ø zone Normal 1350 9–16 Booster 1850 Normal 2300 11–22 Booster 3000 11 x 11 Normal 2100 11–21 – Booster 3000 21 x 21...
Page 25
Familiarisation KM 7372 FR, KM 7372 FL, KM 7373 FR, KM 7373 FL Size in cm Linked Cooking Max. rating cooking zone in watts for 230 V Ø zone Normal 2300 11–22 Booster 3000 Normal 1350 9–16 Booster 1850 11 x 11 Normal 2100 11–21 –...
Familiarisation Effects of power distribution Power management If a cooking zone gives power to another Total power zone, this can have the following effects The hob has a maximum total permitted on the zone giving the power: power consumption which cannot be - The power level is reduced.
Familiarisation Selecting a cooking zone Operating principles If you want to configure settings for a Hob when switched off cooking zone, the cooking zone must be When the hob is switched off, you can selected first. only see the printed symbols for the To select a cooking zone, touch the rel- sensor controls and the numerical dis- evant cooking zone indicator.
Miele cooker hood. - Control a connected Miele cooker Miele@home hood automatically via the hob set- After installing the Miele app on a mo- tings (Con@ctivity 3.0) bile device, you can do the following: - Call up information on the operating...
When Stop&Go is deac- nication system between your hob and a tivated, the cooking zones will operate Miele cooker hood. Communication is at the power level previously selected. achieved by means of networking. Tip: Use this function when the control Con@ctivity 3.0 enables the cooker...
Familiarisation System lock Keeping warm If the system lock is activated, then the This function enables food to be kept hob cannot be switched on. warm after it has finished cooking. The maximum duration for keeping food Safety lock warm is 2 hours. The safety lock is activated when the Programming hob is switched on.
Familiarisation Safety switch-off Power level* Maximum operating time [h:min] Sensor controls are covered Safety setting Your hob will switch off automatically if one or several of the sensor controls re- 10:00 8:00 5:00 main covered for longer than 10 seconds, for example, by finger con- 10:00 7:00 4:00...
Familiarisation Overheating protection Triggering the overheating protection mechanism In order to prevent the hob from being damaged by excessive temperatures, The overheating protection may be ac- the overheating protection mechanism tivated under the following circum- intervenes in one of the following ways: stances: - The cookware being heated is empty.
Commissioning Unpacking the hob Switching on the hob for the first time Please stick the data plate for the ap- pliance, supplied with this document- The metal components have a protect- ation, in the space provided in the ive coating. When the hob is used for “Customer Service Department”...
The WiFi connection shares a frequency Installing the Miele app range with other appliances (including The ability to use the Miele app de- microwave ovens and remote control pends on the availability of the toys). This can give rise to sporadic or Miele@home service in your country.
Page 35
Miele between the hob and a Miele cooker hood (Con@ctivity 3.0). cooker hood (Con@ctivity 3.0). - The Miele app is installed on your - You must have a WPS (WiFi pro- mobile device. tected setup) compatible router.
Page 36
Commissioning Cancelling the process Touch any sensor control. Resetting settings Reset the settings if you are disposing of your hob, selling it or putting a used hob into operation. This is the only way to ensure that all personal data has been removed and the previous owner will no longer be able to access the hob.
Availability of the WiFi connection The WiFi connection shares a frequency - Miele cooker hood with Con@ctiv- range with other appliances (including ity 3.0 microwave ovens and remote control - The hob is not connected to your toys).
Page 38
Commissioning Cancelling the process Touch any sensor control. Resetting settings Reset the settings if you are disposing of your hob, selling it or putting a used hob into operation. This is the only way to ensure that all personal data has been removed and the previous owner will no longer be able to access the hob.
Operation Safety notes for operation Risk of fire with overheated food. Unattended food can overheat and catch alight. Do not leave the hob unattended whilst it is being used. Risk of burning due to hot cooking zones. The cooking zones will be hot after use. Do not touch the cooking zones while the residual heat indicators are on.
Operation Switching the hob on Positioning cookware Touch the sensor control. Refer to the cooking zone data for your hob model for information about cook- Further sensor controls will light up. ware sizes and the corresponding posi- tions (see “Familiarisation – Hob data”). If no further entry is made, the hob will switch itself off after a few seconds for ...
Operation Changing the power level Power level Touch the relevant cooking zone in- Setting the power level dicator. Permanent pan recognition is activated The cooking zone indicator will begin to as standard (see “Adjusting settings”). flash. When the hob is switched on and you ...
Operation Booster Activating/deactivating Stop&Go Activating the Booster The power levels and the timer settings When the Booster function is activated, cannot be altered; the hob can only be the settings for the linked cooking zone switched off. The minute minder, may be changed, see “Familiarisation –...
Operation Activating auto heat-up Auto heat-up Briefly touch the indicator for the re- The heat-up time depends on which quired cooking zone. continued cooking setting has been chosen: Touch the sensor control for the con- tinued cooking setting you want until Continued cook- Heat-up time a tone sounds and lights up in the...
Operation Setting the minute minder Timer Touch the sensor control. Setting timer durations The timer display flashes. A duration of between 1 minute (:) Set the required duration (see “Timer and 9 hours 59 minutes (:) can be – Setting timer durations”). set.
Operation Setting the switch-off time The timer display flashes. A cooking zone will switch off when the Touch the sensor control on the nu- maximum operating time has elapsed, merical display. independently of a set switch-off time Setting multiple switch-off times (see “Familiarisation –...
Operation System lock Safety lock Activating the system lock Activating the safety lock When the safety lock is activated: All sensor controls are locked. A set - The cooking zones and the hob can minute minder time will continue to only be switched off count down.
Operation Activating the Recall function Hob data Switch the hob on again. Displaying the model identifier/serial Immediately after switching the hob number on, touch one of the flashing cooking There must not be any cookware on zone sensor controls. the hob.
Operation Activating/deactivating demo mode Switch the hob on. Press the 0 and 2 sensor controls on the numerical display at the same time for 6 seconds. The following will flash in the timer dis- play for a few seconds: - alternating with (demo mode activated) - ...
Setting ranges for the power levels The hob is programmed with 9 power levels at the factory. If you wish to fine-tune a setting, you can extend the power level range to 17 power levels (see “Adjusting settings”). Setting range Factory set- Extended set- ting ting...
Good to know How induction hobs work Noises An induction coil is located under each When using induction cooking zones, induction cooking zone. The coil creates the following noises can occur in the a magnetic field that reacts directly with cookware, depending on what it is made the base of the pan and heats it up.
Good to know Cookware tips Pans - Position the cookware as centrally as Suitable cookware possible on the relevant cooking - Stainless steel cookware with a mag- zone/cooking area. netic base - To make optimum use of the cooking - Enamelled steel cookware zones, choose cookware with a suit- able base diameter (see “Familiarisa- - Cast iron...
Adjusting settings Accessing programming mode Setting a programme Whilst the programme is visible in the The hob is switched off. display (e.g. :), touch the + sensor control repeatedly until the number of Touch and hold the and sensor the programme you want appears in controls until the + sensor control the display.
Page 53
Adjusting settings Programme Code Settings Demo mode Demo mode off Demo mode on Power management 3680 W 3000 W 2000 W 1000 W Factory default settings Do not restore factory default set- tings Restore factory default settings Power level setting range 9 power levels + Booster 17 power levels + Booster Audible tone when a sensor control is touched...
Page 54
Active and configured (cannot be se- lected; displays whether connection was successful) Connection possible via WPS push button WiFi reset to default ( Direct WiFi connection of hob and cooker hood without Miele app (Con@ctivity 3.0) Sensor controls reaction speed Slow Normal Fast Permanent pan recognition...
Cleaning and care Safety notes on cleaning and care Risk of burns due to hot surfaces. All parts of the hob may be hot after use. Switch the hob off. Allow the hob to cool down before cleaning it. All surfaces could be discoloured or damaged if unsuitable cleaning agents are used or if residues from suitable cleaning agents are heated on the hob.
- Eraser stain remover blocks glass. - Sponges Clean the glass ceramic surface with the Miele ceramic and stainless steel cleaner (see “Optional accessories – Cleaning and care products”) or with a proprietary ceramic glass cleaner. Please follow the cleaning agent man- ufacturer’s instructions.
Troubleshooting Messages in the display Problem Cause and remedy The symbol lights up or No cookware is present on the cooking zone. flashes alternately with Unsuitable cookware is present on the cooking zone. the set power level or The diameter of the base of the cookware is too small in one of the cooking zone indicators.
Page 58
Troubleshooting Problem Cause and remedy will flash alternately The fan is blocked or defective. with , or in Make sure it has not been blocked by an object. the timer display. Remove the obstruction. If this fault message continues to appear in the dis- play, contact the Customer Service Department.
Troubleshooting Unexpected behaviour Problem Cause and remedy Power level 9 is auto- Operating both zones at power level 9 exceeds the matically reduced if you permitted maximum power for the two zones. also set power level 9 for Use a different cooking zone. the connected cooking zone.
There is no power to the hob. zones will not switch on. Check whether the circuit breaker has tripped. Con- tact a qualified electrician or the Miele Customer Service Department (for the minimum fuse rating, see data plate). There may be a technical fault.
Contact in the event of a fault In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Customer Service call-out online at www.miele.com/ser- vice.
After sales service Note for test institutes Test food acc. to EN 60350-2 9 power levels are programmed at the factory. For testing in accordance with the above standard, programme the hob to the ex- tended power level setting (see “Adjusting settings”). Power level ...
Optional accessories Cookware Cleaning and care products Miele offers a wide range of cookware. Ceramic and stainless steel hob These have all been optimised for Miele cleaner 250 ml appliances in terms of functionality and Removes heavy soiling, limescale de- dimensions. Detailed information is posits and aluminium residues.
*INSTALLATION* Installation Safety notes for installation Risk of damage from incorrect installation. Incorrect installation can cause damage to the hob. The hob must only be installed by a qualified specialist. Risk of electric shock from mains voltage. Incorrect connection to the mains supply may result in an electric shock.
*INSTALLATION* Installation Additional safety notes for surface-mounted installation Damage caused by incorrect installation. Using sealant under the hob could result in damage to the hob and the worktop if the hob ever needs to be removed. Do not use sealant between the hob and the worktop. The sealing strip under the edge of the hob provides a sufficient seal for the worktop.
*INSTALLATION* Installation Additional safety notes for flush-fit installation Damage from unsuitable sealant. Unsuitable sealant can damage natural stone. For natural stone worktops and natural stone tiles, only use silicone sealant that is specially formulated for natural stone. Follow the manufacturer’s instructions.
*INSTALLATION* Installation Safety distances Safety distance above the hob The following must be ensured between the hob and the cooker hood above it: - The safety distance specified by the manufacturer of the cooker hood must be maintained. - When two or more appliances which have different safety distances are in- stalled together below a cooker hood, the greatest specified safety distance...
Page 68
*INSTALLATION* Installation Safety distance behind and to the side of the hob The minimum safety distances shown below must be maintained between the appliance and a tall unit or wall: - Between the back of the worktop cut-out and the rear edge of the work- top: 50 mm Not permitted...
Page 69
*INSTALLATION* Installation Safety distance underneath the hob Rear wall cut-out To install the hob while maintaining the For ventilation and accommodating the safety distances, you can choose from mains connection cable, you will need 3 variants: to create a cut-out in the rear wall. Create a cut-out in the rear wall using 1.
Page 70
*INSTALLATION* Installation 1. Without intermediate shelf or base panel To ensure sufficient ventilation to the hob, a minimum safety distance must be left between the underside of the hob and any drawer or oven. The minimum safety distance between the underside of the hob and: - Upper edge of drawer: ≥...
Page 71
*INSTALLATION* Installation 3. Air intake-optimised base panel The performance of the hob depends on the ventilation. The air intake-optimised base panel has openings where the fans are positioned. This section contains instructions for creating an air intake-optimised base panel. ≤ 40 mm ≥...
Page 72
*INSTALLATION* Installation Positions and cut-outs of the ventilation openings X2.1 Y2.1 X1.1 Y1.1 Not to scale. View from above. Surface-mounted cut-out shown. Also applies to flush-fit installation. a Middle of the cut-out height b Middle of the cut-out width c Cut-out for fan, round (Ø 55–70 mm) d Gap (≥...
Page 73
*INSTALLATION* Installation Safety distance from the niche cladding If niche cladding is installed, a minimum safety distance must be maintained between the worktop cut-out and the cladding. High temperatures can alter or damage these materials. Flush-fit installation Surface-mounted installation a Masonry b Dimension x = thickness of the niche cladding material c Worktop d Worktop cut-out...
*INSTALLATION* Installation Building-in dimensions for surface-mounted installation KM 7360 FR, KM 7361 FR All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose...
*INSTALLATION* Installation KM 7360 FL, KM 7361 FL All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose...
Page 76
*INSTALLATION* Installation KM 7363 FR All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose...
Page 77
*INSTALLATION* Installation KM 7363 FL All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose...
*INSTALLATION* Installation KM 7372 FR, KM 7373 FR All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose...
*INSTALLATION* Installation KM 7372 FL, KM 7373 FL All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose...
*INSTALLATION* Installation Installation dimensions for flush-fit installation KM 7360 FL, KM 7361 FL All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose c Stepped cut-out, natural stone worktop d Wooden batten 12 mm (not supplied)
Page 81
*INSTALLATION* Installation KM 7363 FL All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose c Stepped cut-out, natural stone worktop d Wooden batten 12 mm (not supplied)
*INSTALLATION* Installation KM 7372 FL, KM 7373 FL All dimensions are given in mm. a Front b Mains connection box The mains connection cable (L = 1440 mm) is supplied loose c Stepped cut-out, natural stone worktop d Wooden batten 12 mm (not supplied)
*INSTALLATION* Installation If the seal does not sit flush with the Installing a surface-mounted worktop in the corners, the corner ra- dius (≤ R4) can be carefully cut to fit Create the worktop cut-out. Remem- using a jigsaw. ber to maintain the minimum safety ...
*INSTALLATION* Installation Seal the gap between the hob and Installing the hob flush with the worktop with a silicone sealant that is worktop heat-resistant to at least 160 °C. Create the worktop cut-out. Remem- ber to maintain the minimum safety distances (see “Installation –...
Please ensure these match able danger for the user. the household mains supply. Miele cannot be held liable for dam- Please see wiring diagrams for connec- age or injury caused by unauthorised tion. (N.B. This appliance is supplied installation, maintenance or repair single phase only in the UK / AUS / NZ).
Page 86
A Switch the lever from 1 (on) to 0 (off). suitable connection cable is available to order from Miele. Residual current device (RCD) Switch the main switch from 1 (on) to 0 (off) or press the test button.
Page 87
*INSTALLATION* Installation Wiring diagram a b c d e Some connection methods are not permitted in all installation locations. 200-240 V~ Ensure compliance with national reg- 200-240 V~ ulations and any additional regula- tions issued by the local electricity 200-240 V~ provider.
The following data sheets apply to the models described in this operating instruc- tion manual. Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name/identifier KM 7360 FR, KM 7360 FL Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1.
Page 89
*INSTALLATION* Installation Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name/identifier KM 7363 FR, KM 7363 FL Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1. = Ø 90-160 mm face area/cooking zone 2.
< 100 mW WiFi module UK Conformity declaration Miele hereby declares that this ceramic induction hob complies with UK Radio Equipment Regulations 2017, as amended. The complete text of the UK declaration of conformity is available from one of the following internet addresses: - Products, Download from www.miele.co.uk...
Page 91
United Kingdom Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW Tel: 0330 160 6600, Internet: www.miele.co.uk, E-mail: info@miele.co.uk Australia Ireland South Africa Miele Australia Pty. Ltd. Miele Ireland Ltd. Miele (Pty) Ltd. ACN 005 635 398 2024 Bianconi Avenue...
Page 92
KM 7360 FR, KM 7360 FL, KM 7361 FR, KM 7361 FL, KM 7363 FR, KM 7363 FL, KM 7372 FR, KM 7372 FL, KM 7373 FR, KM 7373 FL en-GB M.-Nr. 12 430 221 / 00...
