- Page 1 Antenna Ref. 148930 Kit: 148983 COMPOSITION 148983 Antenna 148930 + P.S.U. 550104 Main Assembly UHF Directors UHF Reflectors Dipole Assembly Connector PSU 550104 216120 accessory...
- Page 2 Antenna assembly RECOMMENDED Scan to TOOLS watch for installation assembly Tightening wrench M10 wrench Cutter or Cutting pliers to release the items video (INCLUDED) (NOT included) (NOT included) Note: Start the assembly procedure after thoroughly checking all parts and becoming familiar with them. Insert the UHF director all the way into CLICK!
- Page 3 Screw connector onto the threaded male input connection of the dipole assembly and tighten with the 216120 accessory, then slide the weather boot over the connector as far as it will go. Insert the Dipole assembly into the antenna orange junction box, sliding it through the guide slot to the point where you will hear an audible “click”...
- Page 4 (NEC Art 250, Part H) from antenna NEC - National Electrical Code to TV 1 to TV 2 (not included) Televes USA LLC. Norfolk Tech Center 16596 E. 2nd Avenue Aurora, CO 80011 televes.usa@televes.com www.televes.com 2023 © Copyright, Televés S.A.U.
