Summary of Contents for CDA VK905
- Page 1 VK905 Compact combination microwave oven Installation, use and maintenance www.cda.co.uk...
-
Page 2: Table Of Contents
Contents: Important information Before first use Control panel Using touch controls Switching the appliance on and off Setting the clock Setting the minute minder Functions Selecting microwave functions Selecting oven functions Pausing and alterinng functions Stopping functions Auxilliary functions and settings Safety key lock Interior lighting Operating time limiter... - Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
-
Page 4: Important Information
(EMC) 2014/30/EU. Parts intended to come into contact with food conform to 1935/2004/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services. -
Page 5: Before First Use
• Do not cover the pans, grids or the oven walls with aluminium foil. • Do not use the oven tray for roasting. • Do not perform maintenance or cleaning of the oven without first switching off the electricity supply. If the oven has recently been used, allow to cool. - Page 6 will switch on automatically when the oven switches on. It is normal for the cooling fan to run for an hour or more after use, depending on the duration, temperature and type of cooking programme used. • The oven light remains on for every cooking function for 1 minute then will go out.
-
Page 7: Control Panel
Control Panel Function SensorsT ime/Temperature display Auxiliary Functions Function Indicators Adjustment Sensors Plus sensor Time sensor Minus sensor Interior light sensor Start/Pause sensor Minute minder indicator Temperature sensor Duration indicator Rapid preheating End of cooking indicator sensor Safety key lock indicator Function active indicator... -
Page 8: Using Touch Controls
Using the touch controls beforeThe touch controls should be used with the flat of your finger, rather than the fingertip. Switching the appliance on and off To switch the applicance on Touch and hold the “On/Off” sensor for approximately 3 seconds until the appliance beeps. -
Page 9: Setting The Minute Minder
the setting. • the hours of the display wil now be flashing. Use to set the hours. Touch the OK sensor to confirm the setting. Note: The clock can only be set in a 24 hour format Setting the minute minder Select a function and touch the sensor until the minder indicator flashes. -
Page 10: Functions
Functions Below is a table of functions for the appliance including any adjustable settings: Adjustable Preset Microwave Preset Adjustable Microwave power Power temperature T ime Icon Function power Minute minder temperature range range ˚ C （ ） （） （ ） 1740 W 100 - 900W Microwave... -
Page 11: Pausing And Alterinng Functions
• Once you ar happy with the settings, press the sensor to begin cooking. The display will show the duration left on the cooking function and the Duration indicator and the Function active indicator will both be illuminated. Selecting a function and beginning cooking (oven functions) •... -
Page 12: Stopping Functions
Note: Opening the appliance door will also temporarily pause the function. Closing the door will resume the function automatically. Stopping a function Simply press and hold the on/off sensor for approximately 1 second. Auxilliary functions This appliance features a number of preset functions which create the ideal cooking environment (time, temperature etc.) for certain dishes. -
Page 13: Safety Key Lock
If the bulb in your appliance should fail, please contact CDA Customer Care to arrange a service visit. The bulb and appliance must not be serviced by anyone except a CDA authorised service... -
Page 14: Operating Time Limiter
Operating time limiter Each temperature, when used outside of semi and automatic cooking, has an operating time limiter to help to prevent damage to the internal components of this appliance. After a certain working time at given temperatures the appliance will switch the function off automatically. -
Page 15: Automatic Cooking
touch the OK sensor to confirm the setting. or alternatively wait 5 seconds and the duration will automatically set • To clear the duration setting, either cycle down the minutes using sensors until the display shows 0:00 or touch the sensor and you will return to standby mode and you can begin the function again. - Page 16 display and the end time will also be shown • Use the sensors to adjust the end time and touch OK to confirm the setting. • To clear the duration setting, either cycle down the minutes using sensors until the display shows 0:00 or touch the sensor and you will return to standby mode and you can begin the function again.
-
Page 17: Care And Maintenance
Care and maintenance It is important, before carrying out any cleaning or maintenance, that you disconnect or switch off the appliance at the power supply. If the oven has been in use, let the cavity and any elements cool down sufficiently before attempting any cleaning or maintenance. - Page 18 Replacing the appliance door Hold the door to the appliance in the closed position and manoeuvre the hinges so that the part of the hinge, highlighted by the star in fig. 2, inserts into the hinge slot in the cavity frame. Next, ensure the notch on the Fig.
- Page 19 Removing the side racks and ceramic hooks To remove the side racks, first, turn them 90 degrees up. Then lift the side rack to the top of the ceramic hook. Finally slide the side racks sideways out of the cramic hooks. To remove the ceramic hooks, first, lift them up to the top of the slots they rest in.
-
Page 20: Cleaning
Cleaning IMPORTANT • Before any maintenance is started involving electrical parts, the appliance must be disconnected from the power supply. • If the oven has been in use, let the oven cavity and the heating elements cool down before attempting any maintenance. •... -
Page 21: Installation
recommend a clean microfibre cloth for cleaning stainless steel surfaces. Grill When used regularly, the grill element does not need cleaning as the intense heat will burn off any splashes. The interior ceiling may need regular cleaning, which should be done with warm water, detergent and a sponge. - Page 22 the holes provided on the side panels. If the appliance is to be installed under a worktop, ensure the top rail has been removed to provide free airflow around the product. Do not use your appliance immediately after moving it from a cold location, as condensation may cause a malfunction.
- Page 23 Min 3 Min 458 Min 450 Min 3 >520 >570 Fig. 4 Min 460 >520 >570 Fig. 5...
-
Page 24: Mains Electrical Connection
Mains electrical connection Warning! This appliance must be earthed This appliance is supplied with a 3 core mains cable; the wires are in accordance with the following code: Green and Yellow = Earth Blue = Neutral Brown = Live Output L Input L Input N Output N... - Page 25 Please note: The mains cable must only be replaced by a qualified electrician or service engineer and must be of equivalent or better rating (i.e. 1.5mm HO5RR-F). The current rating of the fuse or DOUBLE POLE SWITCHED FUSED SPUR OUTLET circuit breaker protecting this appliance should be marked on the outlet (13A).
- Page 26 01949 862 012 or email customer.care@cda. co.uk For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.co.uk Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 01949 862 003 customer.care@cda.co.uk...
