Installation Instructions
Model:
Description:
Part Number:
Assembly Time:
It is always best practice to disconnect your negative battery terminal prior to any electronics installations to avoid damaging the vehicle's
electrical system. Before you begin, read through these instructions and check that all parts are present.
This installation may require special skills and tools to complete and it may be necessary to seek a trained installation technician to
complete this installation. Please note that MB Quart cannot assume any responsibility for damage resulting from incorrect installation.
No.
1
Amplified Dual 10" Subwoofer Enclosure Assembly
2
M6 x 10mm Allen Head Bolt with Threadpatch
3
M6 x 20mm Hex Head Bolt with Threadpatch
4
M6 Speed Clip
5
M8 Flange Nut
6
M8 x 20mm Hex Head Bolt with Threadpatch
7
Mounting Bracket
8
A-Pillar Harness
9
Grommet
10
Wire Guide 200mm
11
Wire Guide 150mm
12
Subwoofer Signal Harness
13
Power Harness
14
Fuse Harness
15
Adhesive Zip Tie Mount
16
11" Zip Tie
17
Braided Split Nylon Tube
18
12ga Ring Terminal
1
Drill
2
T30 Torx Bit
3
Panel Removal Tool
4
4mm Allen Driver
5
Ratchet
6
10mm & 13mm Socket or Wrench
7
1/2" Drill Bit
8
Wire Crimpers
9
Heat Gun or Lighter
Can Am Defender, Defender Max, Defender 6x6
Amplified Dual 10" Subwoofer Enclosure Install
MBQD-SUBA-1
240 Min (4-Hours)
Parts List
Component Name
Tools Required
Page 1 of 11
Parts List
Qty
1
8
1
1
1
1
4
1
1
1
1
1
1
1
2
4
1
1
Advertisement
Related Manuals for MB QUART MBQD-SUBA-1
Summary of Contents for MB QUART MBQD-SUBA-1
- Page 1 This installation may require special skills and tools to complete and it may be necessary to seek a trained installation technician to complete this installation. Please note that MB Quart cannot assume any responsibility for damage resulting from incorrect installation.
- Page 2 Disassembly ● Four Door Model Only: Remove (3) push clips and (2) T30 screws from cover below drivers seat and then remove from vehicle. ● Four Door Model Only: Remove (1) speed clip and (1) T30 screw from floor and this screw will be used later.
- Page 3 Disassembly ● Remove passenger side battery cover by 1/4 turning the release clips. ● Four Door Model Only: Remove (3) push pins on rear passenger side rear center console. Then remove from vehicle. ● Four Door Model Only: Remove (3) push pins on rear passenger side front center console.
- Page 4 Disassembly ● Two Door Model Only: Install enclosure brackets as shown with supplied M6 x 10mm Allen Head screws using a 4mm Allen driver. ● Four Door Model Only: Install enclosure brackets as shown with supplied M6 x 10mm Allen Head screws using a 4mm Allen driver.
- Page 5 Assembly ● On driver side top bracket loosely install the M8 x 20 Hex Head bolt and nut. ● On Four Door Model loosely install (1) OEM T30 screw previously removed. ● On Two Door Model loosely install (2) OEM T30 screw previously removed.
- Page 6 Assembly ● Connect the signal and remote wire to the sub enclosure. Then route up driver side B-Pillar. ● Mount the 200mm wire guide to the B-Pillar and pass the signal and remote wire through the channel. ● Connect the signal and remote harness to the MBQD-STG4A-1 visor.
-
Page 7: Installation
Installation ● Install the 150mm wire guide on the center hump like pictured. Then pass the power harness through the channel ● Drill a 1/2” hole in the front passenger side center console behind the heatshield like pictured. ● Install grommet in hole and then pass power and ground wire through grommet. - Page 8 Installation ● Four Door Model Only: Install passenger front center console and secure with (3) push pins. ● Four Door Model Only: Secure the power and ground wires along the OEM wiring with the supplied zip ties. ● Four Door Model Only: Reinstall rear passenger center console and secure with (3) push pins previously removed.
- Page 9 Installation ● Two Door Model Only: Drill a 1/2” hole on the battery cover. Then install provided grommet and pass power and ground wire through. ● Crimp provided ring terminal onto the ground wire. Using a heatgun or lighter shrink the terminal covering onto the wire.
- Page 10 Installation ● Place the braided split tube over the speaker wires by the visor to give a clean look. Page 10 of 11...
-
Page 11: Fcc Notification
Maxxsonics, LLC. This warranty is limited to defective parts and specifically excludes any incidental or consequential damages connected therewith. To view the full warranty, please visit the website. MB Quart products are designed and engineered in the USA by www.maxxsonics.com...
