Overview of the Device

1.1

Basic Unit

Overview
Kopiervorlage Bilderrahmen
Kopiervorlagen diverse
1 Table
2 Non-slip feet (4 x)
3 Grip recess (on both sides)
Kopiervorlage Bilderrahmen
4 Casing with magnetic drive
5 Flat-ribbon cable
6 Operating panel
Function
Operation
20.12.2023
Kopiervorlagen diverse Kopiervorlagen diverse
6 5
Kopiervorlage Bilderrahmen Kopiervorlage Bilderrahmen
Celltron is a bench-top shaker developed specifically for use in CO
incubators. The basic unit consists of an anti-microbially coated casing
with a magnetic drive. The table is connected to the drive hub by
means of four hexagonal socket screws. To affix the cultivation vessels,
various trays are available for mounting on the table.
The table moves in circles at speeds of 20 to 200 min
the devices's stability, the devices stands on four non-slip feet. For
transporting the device, there are grip recesses on both sides.
The devices is operated using an operating panel which is connected
to the shaker using a flat-ribbon cable. The operating panel consists of
a square plastic casing with a glass cover. If necessary, the operating
panel can be installed on the outer wall or a door of a CO
affix the operating panel, it features four magnets on the back. On the
casing of the operating panel, there is also a wire stand that can be
folded out if necessary.
