DEN4822WD
WRITING DESK
ASSEMBLY INSTRUCTIONS
WARNING
1. Do not use unless all bolts, screws and knobs are
securely tightened.
2. Check that all bolts, screws and knobs are tight every three
months or as needed.
3. Dispose of packing material properly. Do not use plastic cover
as head covering. It may cause suffocation.
4. Do not use as a stepladder.
5. Use for its intended purpose only.
6. Use mild detergent only for cleaning.
1
, by Fax 1-909-930-5629, or
®
Products October 2021
