- Page 1 MAG Series LCD Monitor MAG 244C (3BB3) User Guide...
- Page 2 Contents Getting Started ........................3 Package Contents ..................... 3 Installing the Monitor Stand ..................4 Adjusting the Monitor ....................5 Monitor Overview ..................... 6 Connecting the Monitor to PC .................. 8 OSD Setup ........................9 Navi Key ........................9 Hot Key ........................9 OSD Menus ........................10 Gaming ........................
- Page 3 This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents Monitor MAG 244C Documentation Quick Start Guide Accessories Stand...
- Page 4 Installing the Monitor Stand 1. Leave the monitor in its protective packaging. Align and gently push the stand bracket towards the monitor groove until it locks in place. 2. Align and gently push the cable organizer towards the stand until it locks in place. 3.
- Page 5 Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. Important ⚠ Avoid touching the display panel when adjusting the monitor.
- Page 6 Monitor Overview...
- Page 7 Power LED Lit in white after the monitor is turned on. If no signal input, the LED will turn into orange. Lit in orange when the monitor is in Stand-by mode. Power Button & Navi Key HDMI™ Connector Supports HDMI™ CEC, 1920x1080@180Hz as specified in HDMI™ 2.0b. Important ⚠...
- Page 8 Connecting the Monitor to PC 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Assemble the external power supply & power cord. (Figure A) 4. Connect the external power supply to the monitor power jack. (Figure B) 5.
- Page 9 OSD Setup This chapter provides you with essential information on OSD Setup. Important ⚠ All information is subject to change without prior notice. Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu. Up/ Down/ Left/ Right: ●...
- Page 10 OSD Menus Important ⚠ The following settings will be grayed out when HDR signals are received: Night Vision Brightness ● ● AI Vision Contrast ● ● MPRT Color Temperature ● ● Low Blue Light sRGB ● ● HDCR ●...
- Page 11 Gaming 1st Level Menu 2nd/3rd Level Menu Description Game Mode User ● Use Up or Down Button to select and preview mode effects. ● Press the OK Button to confirm and apply your Racing mode type. Night Vision ● This function optimizes background brightness and is recommended for FPS games.
- Page 12 1st Level Menu 2nd/3rd Level Menu Description Alarm Clock Location Left Top ● After setting the time, press the OK Button to activate the timer. Right Top ● Users have to manually restore their preset Left Bottom Alarm Clock after any AC power loss and reconnection.
- Page 13 Professional 1st Level Menu 2nd Level Menu Description Pro Mode ● Use Up or Down Button to select and preview mode effects. User ● Press the OK Button to confirm and apply your mode Anti-Blue type. ● Activating sRGB will affect: Movie Affected Function Function Status...
- Page 14 Image 1st Level Menu 2nd/3rd Level Menu Description Brightness 0-100 ● Properly adjust Brightness according to the surrounding lighting. Contrast 0-100 ● Properly adjust Contrast to relax your eyes. Sharpness ● Sharpness improves clarity and details of images. Color Temperature Cool ●...
- Page 15 Navi Key 1st Level Menu 2nd Level Menu Description ● All Navi Key items can be adjusted via OSD Menus. Down Brightness Left Game Mode Right Screen Assistance Alarm Clock Input Source Refresh Rate Info. On Screen Night Vision Settings 1st Level Menu 2nd Level Menu Description...
- Page 16 1st Level Menu 2nd Level Menu Description Info. On Screen ● The information of the monitor status will be shown on the right side of the screen. HDMI™ CEC ● HDMI™ CEC (Consumer Electronics Control) supports Sony PlayStation®, Nintendo® Switch™, Xbox Series X|S consoles and various audio-visual devices that are CEC-capable.
- Page 17 Specifications Monitor MAG 244C Size 23.6 inch Curvature 1500R Panel Type Resolution 1920x1080 (FHD) Aspect Ratio 16:9 SDR Brightness (nits) Contrast Ratio 3000:1 Refresh Rate 180Hz Response Time ● 1ms (MPRT) ● 4ms (GTG) ● 1 x DisplayPort ● 1 x HDMI™ Connector ●...
- Page 18 Monitor MAG 244C VESA Mounting ● Plate Type: 100 x 100 mm ● Screw Type: M4 x 10 mm ● Thread Diameter: 4 mm ● Thread Pitch: 0.7 mm ● Thread Length: 10 mm Dimension (W x H x D) 537.44 x 396.55 x 220.01 mm...
- Page 19 Preset Display Modes Important ⚠ All information is subject to change without prior notice. ● HDMI™ VRR (Variable Refresh Rate) synchronizes with Adaptive-Sync (ON/ OFF). For ● VRR ON/OFF status, please check Adaptive-Sync. Standard Resolution HDMI™ 640x480 @60Hz @67Hz @72Hz @75Hz SVGA 800x600...
- Page 20 Troubleshooting The power LED is off. ● Press the monitor power button again. ● Check if the monitor power cable is properly connected. No image. ● Check if the computer graphics card is properly installed. ● Check if the computer and monitor are connected to electrical outlets and are turned on.
- Page 21 ● Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ● If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device.
- Page 22 ● If any of the following situations arises, get the device checked by service personnel: ● The power cord or plug is damaged. ● Liquid has penetrated into the device. ● The device has been exposed to moisture. ● The device does not work well or you can not get it working according to the User Guide.
- Page 23 TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light.
- Page 24 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com...
- Page 25 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
- Page 26 Copyright and Trademarks Notice Copyright © Micro-Star Int’ l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’ l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
