Scanner User's Guide
MobileOffice

Advertisement

loading
Need help?

Need help?

Do you have a question about the MobileOffice S602 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Plustek MobileOffice S602

Summary of Contents for Plustek MobileOffice S602

  • Page 1 Scanner User’s Guide MobileOffice...
  • Page 2 © 2021. All rights are reserved. No portion of this document may be reproduced without permission. Plustek is a registered trademark of Plustek Inc. OCR processing by ABBYY® FineReader®, © 2021 ABBYY. ABBYY and FineReader are trademarks of ABBYY Software, Ltd. which may be registered in some jurisdictions.

  • Page 3: Table Of Contents

    Table of Contents ....................1 NTRODUCTION How to Use This Guide ..................... 1 A Note about Icons ....................2 Safety Precautions....................2 System Requirements....................3 Box Contents ......................3 Scanner Overview..................... 4 I. I ..............5 HAPTER NSTALLING THE CANNER Software Installation Requirements................

  • Page 4: Introduction

    Introduction Welcome to the world of Plustek scanners – the ultimate in computer imaging. Your new scanner will improve the professionalism of your day-to-day computing tasks by allowing you to input images and electronic text into your computer system. Like all of our products, your new scanner is thoroughly tested and backed by our reputation for unsurpassed dependability and customer satisfaction.

  • Page 5: A Note About Icons

    A Note about Icons This guide uses the following icons to point out information that deserves special attention. A procedure that must be followed carefully to prevent injury, or accidents. Warning Instructions that are important to remember and may prevent mistakes.

  • Page 6: System Requirements

    System Requirements  Pentium® IV 2.4 GHz processor  DVD-ROM Drive  One available USB 2.0 Port  1GB RAM (2GB or higher recommended)  2GB free HDD space (3GB or larger recommended)  Operating System: Windows 7 / 8 / 10 Box Contents 1.

  • Page 7: Scanner Overview

    Scanner Overview 1. USB port: It connects the scanner to a USB port on your computer by the included USB cable. 2. Page feed slot: Feed the document into the scanner from this direction. You can feel the document being grabbed by the scanner. 3.

  • Page 8: Chapter I. Installing The Scanner

    Chapter I. Installing the Scanner Before installing your scanner, please verify that you have all of the proper components. A list of the package contents is provided in the Box Contents section of this guide. Software Installation Requirements Your scanner comes with the OCR software (ABBYY FineReader Sprint), business card recognition software (NewSoft Presto! BizCard), the scanner’s driver and DocAction.

  • Page 9: Installing And Setting Up The Scanner

    Installing and Setting up the Scanner Please follow the step-by-step procedures described below to install the Plustek scanner. Step 1. Connecting the Scanner to Your Computer 1. Plug the square end of the included USB cable to the USB port of the scanner.

  • Page 10: Step 2. Installing The Software

    Step 2. Installing the Software 1. If the USB components on your computer are functioning correctly, they will automatically detect the scanner causing the “Add New Hardware Wizard” or “Found New Hardware Wizard” to be launched. Note: If your computer was off when you connected the scanner, the “Add New Hardware Wizard”...

  • Page 11: Step 3. Testing The Scanner

    After the software is installed, you will be prompted to perform the scanner calibration. 6. Insert the special calibration sheet, included with the scanner, face up into the page feed of the scanner. 7. Follow the on-screen instructions to complete the scanner calibration. 8.

  • Page 12: Software Setup Troubleshooting

    2. Do one of the following to open the Button Configuration window:  Double-click the DocAction icon in the Windows system tray.  Right-click the DocAction icon in the Windows system tray, and then choose Button Configuration… in the pop-up menu that opens. 3.

  • Page 13: Chapter Ii. Usage And Maintenance

    Chapter II. Usage and Maintenance Operating the Scanner Your scanner accepts documents as small as business cards and as large as 4”x6” photographs. However, some software programs have limitations as to the information they can handle. The capacity of the computer’s memory and free space on your hard drive can also limit the physical size of the document that you scan.

  • Page 14: Using The Scanner Buttons

    The DocAction program, seamlessly integrating the operation of your scanner with your computer and other peripherals, provides a quick and convenient way to perform various scanning functions. With DocAction, you don't need to adjust settings every time you scan. Simply press any button on the scanner's front panel or click any scanning menu item of DocAction on the screen.

  • Page 15: Scanning Methods

    3. Press the SCAN button on the scanner. The scanning starts immediately. 4. If you have the “Continuous Scan” option checked, follow the on-screen instructions to insert another document or image until you have scanned all. 5. When the scan completes, the scanned images will be sent to the business card recognition software.

  • Page 16: Scanning Via Twain Interface

    Scanning via TWAIN Interface The TWAIN program is a very important piece of software that comes with your scanner. This program acts as an interface between the scanner hardware and the image-editing software you are using to view and edit images. The TWAIN program allows you to adjust a number of settings to define the quality of the scanned image.

  • Page 17: Scanning From The Scanner's Panel Or On-Screen Docaction's Execute Menu

    4. Adjust the scanning settings (Paper Size: Automatic Size, Resolution: 300). 5. Load one business card. 6. Click the Scan button. 7. The scanned images are displayed in the Presto! BizCard main window, and you may proceed OCR to convert images into editable text formats. Click the Help button within the TWAIN window for more information about the settings.
  • Page 18 Configure Button Settings Before performing your first scan via scanner buttons, you are recommended to configure the button settings to your needs and preferences first. There are two ways to configure or view the button settings of DocAction:  Double-click the icon in the Windows system tray.

  • Page 19: Scanning From The Icon In The Left Side Of The Docaction Window

    2. Do one of the following to start scanning:  Press the button from the scanner's panel.  Right-click the icon in the Windows system tray, and then choose Execute in the pop-up menu that opens. Click the desired button function item in the pop-up menu.
  • Page 20 2. Check current button settings by viewing the Button Configuration window. If needed, you may also modify settings to meet your current needs. 3. Double-clicking the desired icon in the left side of the DocAction window. The scanner starts to scan immediately and carry out the corresponding action according to settings you have set up in the Button Configuration window.

  • Page 21: Status Indicator

    Status Indicator The green LED indicator (located beside Custom Button) indicates the status of the scanner, as described below: Light Status The scanner is connected with the computer, ready to scan images. Flashing The scanner is busy scanning. The scanner is off, either because of disconnection with the computer, or because the computer being turned off.

  • Page 22: Cleaning The Scanner

    Please insert the special calibration sheet included with the scanner. Alternatively you may also use any plain white sheet of paper sized in A6 (105 x 148 mm) instead; however, the calibration effect may be less good than the special Attention calibration sheet.

  • Page 23: Power Save

     Do use the cleaning paper included in our package box. Remember to replace the cleaning paper in a safe and clean place when you finish using it.  Do not use anything other than our cleaning paper to Attention clean your scanner.

  • Page 24: Appendix A: Troubleshooting

    Appendix A: Troubleshooting Scanning Problems Most problems are easily solved, and some of the most common questions and their recommended solutions are listed below. Symptom: After following the installation instructions, my computer cannot find the scanner. Cause 1: Your software may have not been successfully installed. Solution 1: Please insert the DVD-ROM and reinstall the scanner software.
  • Page 25 Symptom: The scanner scans very slowly. Cause 1: You are running other applications in the background. Solution1: Close all the other applications that are running in the background. Cause 2: You are scanning at a high resolution (DPI). Solution 2: Reduce the resolution.
  • Page 26 Symptom: The scanned image takes too long to be sent with an email message. Cause1: The image was scanned at a high resolution or is physically large. Solution1: Scan at a lower resolution (DPI). Cause 2: The Internet might be congested. Solution 2: Try sending the message at a later time.
  • Page 27 Solution 1: Make sure the document or photo is properly inserted into the page feed of the scanner. Solution 2: The paper may be too think or too thick. Cause 2: The thickness of the paper is out of scanner specifications. Symptom: The document or photo got jammed while getting fed into the scanner.

  • Page 28: Appendix B: Specifications

    Appendix B: Specifications Image Sensor Light Source Optical Resolution 1200 dpi Hardware Resolution 1200 x 1200 dpi Color: 48-bit input, 24-bit output Scan Modes Grayscale: 16-bit input, 8-bit output B/W: 1-bit output Scanning Speed 5.5 sec (Color Mode, 300 dpi, A6) Maximum: 104.9 x 500 mm (4.13"...

  • Page 29: Appendix C: Customer Service And Warranty

    If you encounter problems with your scanner, please review the installation instructions and troubleshooting suggestions contained in this guide. Visit our website www.plustek.com for more customer service information. To avoid delays, please have the following information available:  Scanner name and model number ...

  • Page 30: Statement Of Limited Warranty

    Statement of Limited Warranty This Statement of Limited Warranty applies only to the options you originally purchase for your use, and not for resale, from an authorized reseller. The manufacturer warranty includes all parts and labor, and is not valid without the receipt of original purchase.

  • Page 31: Fcc Radio Frequency Statement

    Some jurisdictions do not allow the exclusion or limitations of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This Limited Warranty gives you specific legal rights, and you may also have other rights that vary from jurisdiction to jurisdiction. FCC Radio Frequency Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
