- Page 1 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English ES-A21200Y-1...
-
Page 2: Important Safety Instructions
Important Safety Instructions ▐ Important Notice Paragraphs beginning with the symbol indicate important instructions, tips or conditions for the following settings. For your own safety and the optimal performance of your TV, ensure to read the safety instructions before performing any installation. Compatibility with 3rd party products, software and services are not guaranteed. - Page 3 Important Safety Instructions The intended use and ambient conditions for this TV This TV is intended for the rendering of video and audio signals, on a table-top or wall- mounted, in a home or office environment. It must not be used in rooms with a high level of humidity or dust concentration.
- Page 4 Important Safety Instructions „ Moving/Transportation „ Power plug and power cable Before moving this TV, disconnect all - Do not touch the power plug with wet cables and move in the vertical position hands. only. Grasp the device on the upper and - Do not place heavy objects on the lower edges of the frame.
- Page 5 Important Safety Instructions „ Air ventilation and high Prevent small items from getting into the interior of the device through the ventilation temperatures slots. Such objects may cause short circuits, Install your TV only where there is proper which may cause fire. ventilation, and ensure that there is at least If something should get inside the unit, 10 cm free space on the sides and 20 cm...
- Page 6 Important Safety Instructions If you have a cardiac pacemaker, keep a „ Supervision distance of at least 22 cm from the TV. Radio - Do not let children play unsupervised waves may interfere with the operation of a close to the TV. It could tip over, be pacemaker.
- Page 7 Important Safety Instructions „ Cleaning and care swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. CAUTION: Unplug the power cord prior to cleaning „ Modification the TV. Clean the TV, the screen, and the remote Do not attempt to modify this product control with a soft, moist, clean and in any way.
-
Page 8: Table Of Contents
/ ERF3B80H / ERF3C80H / ERF3D80H / ERF3E80H / ERF3H80H / ERF3I80H / ERF3F90H / ERF3M80H / ERF3N80H / 43A7GQ / 43A70GQ / 43A71GQ / 43A72GQ / 43A71GQCH / 43A72GQCH / 43A78GQNE / 43A76GQ / 43A77GQ / 43A78GQ / 43A79GQ / 43A78GQCH / 43A79GQCH / 43A79GQNE / 43A7GQTUK / 43A70GQTUK / 43A71GQTUK / 43A72GQTUK / 43A76GQTUK / 43A77GQTUK] is in compliance with Directive 2014/53/EU. -
Page 9: Installing The Stand Or Wall Mount Bracket
Installing the Stand or Wall mount bracket CAUTION Be sure to disconnect the AC power cord before installing a stand or wall mount brackets. The display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard objects or from pressure. - Page 10 Installing the Stand or Wall mount bracket Installing the wall mount bracket Before mounting the TV, remove the TV stand if you have already attached it, and make sure the wall mount bracket supports the weight of your TV. CAUTION When mounting the TV on a wall, follow instructions provided with the wall mount bracket.
-
Page 11: Tv Front
TV Front TV Front Remote sensor/Power indicator/Single button (Standby/Source) Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is red in standby mode. Press the single button when in standby mode, and the TV will be turned on. -
Page 12: Tv Rear
TV Rear TV Rear AC INPUT DIGITAL AUDIO OUT NOTES ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any connections. Loose connections can result in image or colour problems. Make sure that all connections are tight and secure. -
Page 13: Making Connections
Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · It is recommended to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP). - Page 14 Making Connections Outdoor Antenna Cable ANT OUT ANT 1 DVB-T/T2/C Antenna Cable (75Ω) (not included) VHF/UHF Antenna ANT 2 DVB-S/S2 (not included) 13/18V 0.5A Satellite antenna Audio Amplifier/Speaker DIGITAL DIGITAL AUDIO OUT AUDIO OUT DIGITAL AUDIO cable (not included) Audio Amplifier/Speaker HDMI (eARC) HDMI...
- Page 15 Making Connections CAM CARD SMART CARD NOTES Before you insert/remove the CI+ module, ensure that the TV is switched off. Then insert the CI card into the CI+ module in accordance with the Service Provider's instructions. COMMON Do not repeatedly insert or remove the Common Access INTERFACE Module as this may damage the interface and cause a malfunction.
-
Page 16: Remote Control
Remote Control INPUT: Select input sources POWER: Switch the TV on or into standby mode Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Program Guide (DTV mode) CH.LIST: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <... - Page 17 Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Program Guide (DTV mode) CH.List: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons / <...
- Page 18 Remote Control POWER: Switch the TV on or into standby mode TXT: Turn on/off the teletext function INPUT: Select input sources Number button: Direct channel selection or numbers input GUIDE: Display the Electronic Program Guide (DTV mode) CH.List: Display the Channel List on the screen Special function buttons : Display the Quick setup menu : Media content control function buttons...
- Page 19 Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources MIC: Activate the microphone : Media content control function buttons Enter Channels / input numbers and special function buttons (Red/Green/Yellow/Blue) / < / >: Allow you to navigate the on- screen menus and adjust the system settings to your preference OK: Confirm the selection in the on-screen...
-
Page 20: Installing Batteries In The Remote Control
Remote Control Installing Batteries in the Remote Control NOTE: Check information according to the actual remote control in the accessory bag. 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment. -
Page 21: Remote Control Operation Range
Remote Control Pairing the Remote Control (only for Bluetooth remote control) Pair the remote to the TV after you power it on. Keep the remote control within 3 metres from the TV. Press any button (except power and mic button) to pair. NOTES In special cases, press and hold [ ] button to pair. -
Page 22: Turning The Tv On For The First Time
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. 3. -
Page 23: Specifications
Specifications Features, appearance and specifications are subject to change without notice. Item 43" 37.9 × 22.0 × 3.4 inches Without Stand (962 × 560 × 86 mm) Dimension (W × H × D) 37.9 × 24.3 × 7.6 inches With Stand (962 ×... - Page 24 Specifications RGB / 60Hz (640×480, 800×600, 1024×768) YUV / 60Hz (480i, 480p, 720p, 1080i, 1080p) YUV / 50Hz (576i, 576p, 720p, 1080i, 1080p) HDMI Input 3840×2160 / 24Hz, 3840×2160 / 25Hz 3840×2160 / 30Hz, 3840×2160 / 50Hz, 3840×2160 / 60Hz...
-
Page 25: Other Information
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. - Page 26 Other Information EPREL Registration Information Model identifier Eprel registration number Model identifier Eprel registration number ４３Ａ７ＧＱ ７１７２６８ ４３Ａ７９ＧＱ ７１７６６５ ４３Ａ７０ＧＱ ７１７３２０ ４３Ａ７８ＧＱＣＨ ７１７６６６ ４３Ａ７１ＧＱ ７１７３２２ ４３Ａ７９ＧＱＣＨ ７１７６６８ ４３Ａ７２ＧＱ ７１７３２４ ４３Ａ７９ＧＱＮＥ ７１７６６７ ４３Ａ７１ＧＱＣＨ ７１７６５７ ４３Ａ７ＧＱＴＵＫ ７１７６６９ ４３Ａ７２ＧＱＣＨ ７１７６５９ ４３Ａ７０ＧＱＴＵＫ ７１７６７０ ４３Ａ７８ＧＱＮＥ ７１７６６０...
