Manufactured for Rooms To Go
Thanks for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come
loose inside the carton during shipment. Identify and count all parts and compare with the Hardware List below
PARTS LIST
Item
A
B
C
D
E
Description
Qty
Table Top
1
4
Table Leg
Leg Collecting
1
Ring
Bolt
4
(5/16-18*1.18")
Bolt
4
(5/16-18*1.38")
ASSEMBLY INSTRUCTIONS
ABOL CARINA 30" ROUND BISTRO TABLE
SKU 74000438
Item
F
G
H
I
J
K
L
Description Qty
Flat Washer
8
Lock Washer
8
Nut
4
Nut Cover
4
4
Bolt Cover
1
Wrench
1
Allan Wrench
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO PATIO CARINA 74000438
Summary of Contents for ROOMS TO GO PATIO CARINA 74000438
- Page 1 ASSEMBLY INSTRUCTIONS ABOL CARINA 30" ROUND BISTRO TABLE Manufactured for Rooms To Go SKU 74000438 Thanks for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all parts and compare with the Hardware List below...
- Page 2 1. Place the table top (A) upside down on a non-abrasive flat surface. Align the holes in table legs (B) with the holes in the table top (A), Loosely secure table legs (B) to the table top (A) with the short bolt (D) through flat washer (F), lock washer (G) and nut (H).
