INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
WARNING: Risk of electric shock. Disconnect power before servicing.
WARNING: Risk of electric shock:
Connect only to a properly grounded, grounding-type receptacle, which is protected by a 220~240 V, 50 Hz
Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device (RCD). Do not remove the grounding pin or use a
grounding adapter.
• Consult the online users guide at kohler.com for more information.
• Kohler Co. reserves the right to make revisions in the design of products without notice.
IMPORTANT INFORMATION
1. The product is composed of a mirrored cabinet and open shelf. They are separately packed. Please install
according to their installation instructions.
2. The product contains lighting and anti-fogging equipment. Please prearrange a power port of 220V/50Hz.
99932IN-*
Double Open Cabinet
TOOLS AND MATERIALS
Drill with Assorted Bits
1237009-IN2-B
Screwdrivers
Band Tape
99932IN-L-NA/99932IN-NA
99933IN-L-NA/99933IN-NA
99933IN-*
Single Open Cabinet
Levelling Ruler
Pencil
1
Plus:
Protective Material
Tape
Advertisement
Related Manuals for Kohler 99932IN-L-NA
Summary of Contents for Kohler 99932IN-L-NA
- Page 1 • Consult the online users guide at kohler.com for more information. • Kohler Co. reserves the right to make revisions in the design of products without notice. IMPORTANT INFORMATION 1. The product is composed of a mirrored cabinet and open shelf. They are separately packed. Please install according to their installation instructions.
- Page 2 99933IN-* Double Open Cabinet Single Open Cabinet Kohler reserves the right to change marked dimensions without prior notice. INSTALLATION NOTE: • We recommend installing the open shelf first. Make sure there must be at least 76 mm gap between the cabinet bottom and facet top.
- Page 3 1. Drill Ø6 holes and insert the wall anchors. 2. Install the wall bracket with ST3.5x35 pan head self-tapping screw. 3. Secure the cabinet onto the wall bracket. b. Avoid knocking the wall a. When installing the cabinet onto the with the sharp corner of wall bracket, please pay attention side mirror.
- Page 4 3. Kohler mirrored cabinets are dealt with strict procedures for damp-proof, whose good damp-proof function ensures good performance even in a bathroom of huge humidity. Yet do not splash and pour water directly on the mirrored cabinet.
