- Page 1 Technical Documentation QR code to access the Technical Documentation website VISY VISY-Command Web (English) Art. No. Version Edition 207218 2024-10 FAFNIR GmbH • Schnackenburgallee 149 c • 22525 Hamburg, Germany • T.: +49 /40 / 39 82 07- 0 • Web: www.fafnir.com...
-
Page 2: Table Of Contents
Table of Contents Overview ........................1 In this manual … ..........................1 Related and optional components ....................1 Requirements for technicians ......................3 Recommended tools ......................... 3 Safety instructions ....................4 VISY-Command Web ................... 5 Types ............................... 5 SECON-X functionality ........................6 Installation ...................... - Page 3 EC-Type Examination Certificate of VP-1, VP-2 and VP-4 ..........29 10.5 Instructions VP-… ..........................32 © Copyright: Reproduction and translation are permitted solely with the written consent of the FAFNIR GmbH. The FAFNIR GmbH reserves the right to make changes to products without prior notice. Table of contents...
-
Page 4: Overview
Overview VISY-Command Web is an evaluation unit of type VISY-Command with a SECON-Client display and web connection for local and remote display of data and alarms from the VISY-X and the optional VAPORIX system. The VISY-X system is used for data processing and evaluation of tanks with light liquids as well as for environmental monitoring. - Page 5 Filling level and environmental sensors: VISY-Stick VISY-Reed Art. no. 207194 VPS pressure sensors (optional) Art. no. 350204 VAPORIX Flow/Control (II) (optional) Art. no. 207083 (350251) Leakage detection with VIMS sensors (optional) from our system partner SGB: SGB GmbH, Hofstraße 10, 57076 Siegen, Germany, T.: +49 271 48964–0, F.: +49 271 48964–6, e-mail: sgb@sgb.de ...
-
Page 6: Requirements For Technicians
Operation of VISY-Command Web using the SECON-X software SECON-Server User Art. no. 350377 SECON-Client User local access Art. no. 350263 SECON-Client User remote access Art. no. 350175 Requirements for technicians The VISY-Command Web with the corresponding software VISY-Setup and SECON-X should only be installed by trained service technicians. -
Page 7: Safety Instructions
Safety instructions The system is used for data recording and evaluation from tank sensors, environmental sen- sors and optionally vapour recovery. Use the system exclusively for this purpose. The man- ufacturer accepts no liability for any form of damage resulting from improper use. The system devices have been developed, manufactured and tested in accordance with the latest good engineering practices and generally accepted safety standards. -
Page 8: Visy-Command Web
VISY-Command Web Types VISY-Command Web is an evaluation unit of type VISY-Command with display for show- ing the current tank data, delivery data and various alarms recorded by the VISY-X and op- tionally the VAPORIX system. The name of the VISY-Command Web depends on the number of sensor terminals, the model, or the transmission technology. -
Page 9: Secon-X Functionality
SECON-X functionality VISY-Command Web has an integrated SECON-Client user interface and can therefore be operated with the functionality of the SECON-X system. The SECON-X system is a universal hardware-software network system for the recording, evaluation and presentation of petrol station data with a worldwide data access, web inter- face, local and remote display, remote evaluation, and data backup. -
Page 10: Installation
Installation Mounting The VISY-Command Web must be installed outside of potentially explosive areas. The VISY-Command Web must be mounted inside a building. It is not suitable for outdoor installation. For installing and operating the VISY-Command Web evaluation unit, the regu- lations of Industrial Safety and Health Regulations and the Technical Rules for Operational Safety as well as the generally accepted rules of engineering and this manual must be observed. - Page 11 Display Printer (optional) Figure 4: VISY-Command Web housing door, interior view When the housing door of the VISY-Command is opened, there is a risk of electric shock on touching conductive parts! Since the evaluation unit is designed to be supplied from the mains, an overcur- rent protection device (fuses, circuit breakers, thermal releases, current-limiting impedances or similar devices) must be connected upstream.
-
Page 12: Connection Of The Visy Sensors
Connection of the VISY sensors 4.2.1 Connection cable The connection cable between the sensors and the VISY-Command Web must have the following properties: 4-core unshielded, oil-resistant cable • Cable cross-section (4 x 0.5 mm² up to 100 m or 4 x 1.0 mm² up to 200 m) •... -
Page 13: Connection Of The Vaporix System (Optional)
At each sensor terminal it is possible to connect up to three different VISY-Stick/Reed types of FAFNIR sensors (e.g. one VISY-Stick, one VISY-Stick Interstitial and one VISY-Reed Sump). The different sensor types can be connected to each other in parallel directly at the installa- tion point. -
Page 14: Connections And Settings Of The Vi-4 Board
Connections and settings of the VI-4 board 4.4.1 Interface connections Interface VI-4 Interface VI-4 -R xD H ost Display : R xD S ervice Status of the S tatus de r M ess w ertgebe r Sensors T xD S ervice S e r v ic e 2: Tx D V ISY -IC I... -
Page 15: Host Interface (Rs-232/Rs-485)
4.4.3 Host interface (RS-232/RS-485) The serial host interface (galvanically isolated) for communication with a higher-level sys- tem (e.g. POS) is available as RS-232 or RS-485 interface. Various protocols can be used for transferring data to the petrol station computers. The data protocol for the interface can be selected using the VISY-Setup software by entering a host code. -
Page 16: Expansion Interface (Rs-485)
4.4.4 Expansion interface (RS-485) The expansion interface is a galvanically isolated serial RS-485 interface by which the data can be transmitted to other system components (e.g. if the host interface is busy). The in- terface is unidirectional. This means that data is only sent from VISY-Command Web to the system components connected there. -
Page 17: Dip Switch S2 For Bias (Rs-485 Host/Extension)
4.4.5 DIP switch S2 for bias (RS-485 host/extension) With the DIP switch S2, the RS-485 host interface (2.1/2.2) and the RS-485 extension inter- face (2.3/2.4) can be biased when required, in order to achieve a significant improvement of communication security. DIP switch S2: RS-485 bias Function Bias off (factory setting) -
Page 18: Supply Voltage Connection
Supply voltage connection The supply of auxiliary power (electrical connection) must be carried out as a fixed installa- tion (no plug installation), and is ducted through the lower right cable gland, see Figure 5. Connect the supply voltage to the corresponding terminal blocks only after the VISY-Command Web has been completely wired. -
Page 19: Configuration With The Secon-X Software
Remove the RS-232 connector of the display from the VI-4 board, see chapter4.4.2 and set the DIP switch S1 to position OFF – OFF RS-232 connector DIP switch S1 Connect the VISY-Command Web to your PC/notebook via the RS-232 service in- terface Configure the VISY-Command Web with the VISY-Setup software on your PC/notebook... -
Page 20: Operation
Operation Applications The VISY-Command Web is operated via a touch-screen display and can be used with the VAPORIX application for monitoring the vapour recovery, with the LEVEL application for filling level measurement, and with the Environmental application including Oil separator monitoring, also see the following manuals: ... -
Page 21: Level Application
5.1.2 LEVEL application With the LEVEL application, the filling levels of the individual fuel tanks is monitored and evaluated, see the following figure: Figure 11: LEVEL application 5.1.3 Environmental application With the environmental application, leakages, drip trays (sumps) and oil separators are checked and monitored, see the following figure: Figure 12: Application of environmental sensors Operation... -
Page 22: Status Display Of The Vi-4 Board
Status display of the VI-4 board After switching on or resetting the VI… interface, the firmware checksum is initially checked. If an error in the firmware is detected, the display shows permanently SE (Signa- ture Error). Otherwise, the firmware version of the interface is displayed. This is shown in form of three numbers displayed in sequence, e. - Page 23 Status Message (in VISY-Setup) Possible cause Troubleshooting Description Probe running No measures required Probe not running If this status is displayed permanently, it can be assumed that the sensor is The measured values are no longer being defective.
- Page 24 Status Message (in VISY-Setup) Possible cause Troubleshooting Description Only for wireless operation: Dirty or damaged plug connection, RF transmitter does not receive any data connection cable defective, sensor or from the sensor. VISY-RFT transmitter defective Check the cable and plug connection, The VISY-RFT transmitter reports that the replace VISY-RFT transmitter, replace sensor is no longer responding.
- Page 25 Status Message (in VISY-Setup) Possible cause Troubleshooting Description the evaluation unit and of the sensor (e.g. number of floats or density mod- ule) available. Only for wireless operation: Data from the sensors is transmitted Waiting for first wireless transmission only at intervals.
-
Page 26: Maintenance
+49 / 40 / 39 82 07 – 0 Availability (CET) Mon. to Thu. 7:00 a.m. to 5:00 p.m., Fri. 7:00 a.m. to 4:00 p.m. The return of FAFNIR devices is only possible after approval (RMA) by the FAF- NIR customer service. Page 23/34 Maintenance... -
Page 27: Technical Data
Technical data ∼ 230 VAC ± 10 %; 50 Hz; 20 VA Supply connection: Sensors connection: Only for connection of certified sensors according to EN 60079 (observe operating instructions) Ambient temperature: 0 °C to +55 °C (without printer) 0 °C to +50 °C (with printer) Relative humidity: 20% to 90% (without printer) 30% to 85% (with printer) -
Page 35: Instructions Vp
11.4.1 Instructions VP-… TÜV 98 ATEX 1380 X Instructions in accordance with Directive 2014/34/EU Isolating amplifier VP-… Edition: 08.2017 Range of application The isolating amplifiers VP-… are primarily used to supply electronic fill level sensors and forward the measured data to a superordinate evaluation system. Standards The isolating amplifier is designed in accordance with the following European standards EN 60079-0:2012 + A11:2013... - Page 36 III.f … maintenance (servicing and emergency repair) The isolation amplifier generally is maintenance-free. In case of a defect, it must be send back to FAFNIR or one of its representations. There is consistency with the requirements for the dielectric strength (according to EN 60079-11, clause 6.3.13) between the intrinsically safe sensor circuits and the auxiliary energy as well as the communica-...
- Page 37 Technical data The auxiliary power for the isolating amplifier depends on the model: 24 V /115 V /230 V ± 10 %, 50 Hz … 60 Hz 2 VA ≈ 36 V@24 V / 138 V@115 V / 253 V@230 V The electric circuits of the sensors have "Intrinsic safety"...
- Page 38 Blank Page...
- Page 39 Blank Page...
- Page 40 QR code to access the Technical Documentation website FAFNIR GmbH Schnackenburgallee 149 c 22525 Hamburg, Germany Tel.: +49 / 40 / 39 82 07 - 0 E-mail: info@fafnir.com Web: www.fafnir.com...
