Summary of Contents for Moes ZS-EUB
- Page 1 HOME,SMART MOES HOME Instruction Manual ZigBee Smart Switch ZigBee English...
- Page 2 Bitte scannen Sie den QR-Code, um dasdeutsche Handbuch, das Installationsvideo und die Funktionsein -führung zu erhalten Escanee el código QR para obtener el manual en español, el video de instalación y la introducción de la función Veuillez scanner le code QR pour obtenir le manuel en français, la vidéo d'installation et l'introduction des fonctions Отсканируйте...
-
Page 3: Safety Information
Transportation 1.The products shall be free from severe vibration, impact, exposure to rain, dumping and other problems during transportation, and shall comply with the provi- sions of the marks on the packing boxes. 2. This product has no waterproof and dustproof function. -
Page 4: Installation
Smart Life/Tuya App,and all controlling modes work without any interference.Its design is suitable for different decoration styles with its best value. Technical Parameters: Model: ZS-EUB Rated Voltage: 90-250V AC 50/60Hz Max. Load: 600W(INC)/220V; 300W(INC)/110V 120W(LED/CFL)/220V/110V Min. Load: 3W(INC/LED/CFL)/220V/110V (for single live switch) Wireless Protocol: ZigBee 3.0... - Page 5 Wire,please try another location at your home or call a professional electrician to install the switch. The wire colors indicated in this manual are the usual colors and may differ in some houses. Ensure the wire conductors are securely fastened to each wire.
- Page 6 Step 2 Remove the old switch Step 3 Remove the switch and pull it away from the wall. Identify Line/Load Wire(Note:The color of your wire may be different from the color shown on the manual.) Verify power is off We recommend you remove the faceplate from the old switch and use an electrical tester to test all wires connected to the switch to ensure there is no voltage in the circuit.
- Page 7 Step 4 Take pictures of the wiring Follow the wiring diagram to connect the switch wires to the wires in the wall box with the wire conductors. (Option) Light 3 Light 2 Light 1 English...
- Page 8 Step 5 Open the switch panel from the bottom of the switch with a screwdriver Screwdriver Mount the switch with the provided screws and snap the wall plate on it. Step 6 Turn the power back on at the circuit breaker and then switch the light on.
- Page 9 Download The MOES APP 1. Download MOES App on App store or scan the QR code MOES App is upgraded as much morecompatibility than Tuya Smart/Smart LifeApp, functional well for scene controlled bySiri, widget and scene recommen- dations asthe fully new customized service.(Note: Tuva Smart/Smart Life App still works.but MOES App is...
- Page 10 Steps for connecting the APP to the device Ensure the device is within the effective signal coverage of your smart ZigBee gateway for successful connection into the ZigBee gateway in Smart Life APP. Method One： Scan the QR code to configure the network guide. Make sure your Smart Life/Tuya Smart APP has successfully connected to a Zigbee gateway.
- Page 11 Method Two： 1. Make sure your Smart Life/Tuya Smart APP has successfully connected to a Zigbee gateway. 2.Press and hold the button for about 7 seconds,until the indicator on the switch flash fast after 3seconds. Repair is successful. English...
- Page 12 3.Enter the gateway.Please follow the picture below to finish as “Add subdevice→LED already blink,and the connecting will take about 10-120 secondsto complete depending on your network condition. English...
- Page 13 4.Add the device successfully, you can edit the name of the device to enter the device page by click “Done”. 5.Click“Done”to enter the device page to enjoy your smart life with home automation. English...
- Page 14 How to Reset/Re-pair ZigBee code Press and hold the button for about 7 seconds,until the indicator on the switch flash fast after 3 seconds.Re- set/Re-pair is successful. How to achieve multi-control association (only for N+L wire) Note:Please confirm you have successfully finished the link method above for adding this switch to your Smart Life App before the association.
- Page 15 2.Then you will see two devices in the app and click the main switch(as one gang switch as below)by entering into the next operation. New Added Switch Main Switch 3.Click in the upper right corner and choose “Multi-Con- trol Association, and then click “+” in the right corner. English...
- Page 16 4.Choose the switch that you want to associate to and then choose the switch button that you want to control the same light.Then go back to previous page,you will see two itemsin the page,one is your main switch,the other is the oneyou associate just now.
- Page 17 6.If you want to add another third or more smart switches to control your light,just repeat the steps above.And you will see the result as below when you associate another new switch. Main Switch Associated 1 Associated 2 English...
- Page 18 Enter MOES Skill in Alexa APP 1. Complete product networking configuration in the App Complete the device's networking configuration according to the prompts in the App. Note: In the App, change the name of the device to an easily identifiable name such as Alexa; names are usually in English, such as “bed light”.
- Page 19 3.Key step —— Link Skill ① Tap on“Skills" in the Alexa App menu. ② Then search for “MOES". Tap “Enable" to enable the Skill. ③ Enter the App account and password, then tap “Link Now" to link your App account to enable the Skill. Now you can start your smart home journey 4.Common commands...
-
Page 20: Troubleshooting
Troubleshooting 1. Why does the device fail to link to the APP? a. ZigBee products work with the MOES/TUYA ZigBee gateway needed; b. Check whether the router connected to the gateway is connected to the external network. Ensure that the Wi-Fi signal of the gateway is good and try to connect the gateway again . - Page 21 device close as recommended,where the distance should be moderate (less than 5 m). d. Check whether the device enters the network distribution mode. 2. After the device is installed, why does the light not respond when I click the switch button? Please cut off...
-
Page 22: Recycling Information
RECYCLING INFORMATION All products marked with the symbol for separate collection of waste electrical and electronic equipment (WEEE Direc- tive 2012/19 / EU) must be disposed of separately from unsorted municipal waste. To protect your health and the environment, this equipment must be disposed of at desig- nated collection points for electrical and electronic equipment designated by... -
Page 23: Warranty Card
WARRANTY CARD Product Information Product Name______________________________________ Product Type______________________________________ Purchase date______________________________________ Warranty Period____________________________________ Dealer Information__________________________________ Customer's Name__________________________________ Customer Phone___________________________________ Customer Address__________________________________ ___________________________________________________ Maintenance Records Failure date Cause Of Issue Fault Content Principal English... - Page 24 Thank you for your support and purchase at we MOES, we are always here for your complete satisfaction, just feel free to share your great shopping experience with us. If you have any other need, please do not hesitate to contact us first, we will try to meet your demand.
- Page 25 EVATOST CONSULTING LTD Address: Suite 11, First Floor, Moy Road Business Centre, Taffs Well, Cardiff, Wales, CF15 7QR Tel: +44-292-1680945 Email: contact@evatmaster.com AMZLAB GmbH Laubenhof 23, 45326 Essen Made In China Manufacturer: WENZHOU NOVA NEW ENERGY CO.,LTD Address: 3th Floor, Building 2, Power Science and Technology Innovation Center, NO.
