  • Page 1 T535 DVD / SACD Player...

  • Page 2: Table Of Contents

    SECTION 1 SUMMARY CONTENTS PRODUCT SAFETY SERVICING GUIDELINES..................1-2 SERVICING PRECAUTIONS ........................1-3 * General Servicing Precautions * Insulation checking prodedure * Electrostatically Sensitive Devices SPECIFICATIONS ............................1-4 DISASSEMBLY .............................. 1-5 PRINCIPAL PART LOCATION ........................1-6 EXPLODED VIEW (C) ........................... 1-7 EXPLODED VIEW (AH)..........................

  • Page 3: Product Safety Servicing Guidelines

    PRODUCT SAFETY SERVICING GUIDELINES CAUTION : DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN VOLTAGE MEASURE MUST NOT EXCEED 75 VOLTS R.M.S. ANY WAY. NEVER PERFORM CUSTOMIZED INSTALLATIONS THIS CORRESPONDS TO 0.5 MILLIAMP AC ANY VALUE WITHOUT MANUFACTURER’S APPROVAL. UNAUTHORIZED EXCEEDING THIS LIMIT CONSTITUTES A POTENTIAL MODIFICATIONS WILL NOT ONLY VOID THE WARRANTY, BUT SHOCK HAZARD AND MUST BE CORRECTED IMMEDIATELY.

  • Page 4: Servicing Precautions

    SERVICING PRECAUTIONS CAUTION : Before servicing the A/V Receiver covered by this Electrostatically Sensitive (ES) Devices service data and its supplements and addends, read and follow the Some semiconductor (solid state) devices can be damaged easily by SAFETY PRECAUTIONS. NOTE : if unforeseen circumstances static electricity.

  • Page 5: Specifications

    SPECIFICATIONS SYSTEM Signal system PAL/NTSC Laser Two wavelength laser diode Wavelength 790nm Wavelength 650nm Frequency response -1dB (Ref. 20Hz-44KHz, DVD) -3dB (Ref. 20Hz-50KHz, SACD) Signal-to-noise ratio (audio) >95dBA (A-WTD) Dynamic range (audio) >90dBA (A-WTD) Total Harmonic Distortion <0.002% OUTPUT Video out 1Vp-p/75 ohms S-video (Y signal) 1Vp-p/75 ohms...

  • Page 6: Disassembly

    DISASSEMBLY...

  • Page 7: Principal Part Location

    PRINCIPAL PARTS LOCATION...
  • Page 8 T535C/CT EXPLODED VIEW PARTS LIST...

  • Page 9: Exploded View (Ah)

    EXPLODED VIEW (T535C/CT)
  • Page 10 T535A/AHT EXPLODED VIEW PARTS LIST 1-10...
  • Page 11 EXPLODED VIEW (T535AH/AHT) 1-11 1-12...
  • Page 12 REGULATOR IC ..........................2-35 ..........................2-37 ........................2-39 ......................2-53...

  • Page 13: Factory Reset

    SOFT RESET METHOD 1. FACTORY RESET - Power On - Tray OPEN - Press the Remote Control Key "Clear"+"2"+"5"+"8"+"0"+"ZOOM" 2. VERSION DISPLAY - Power On - Tray OPEN - Press the Remote Control Key "Clear"+"2"+"5"+"8"+"0"+"Clear" - Then, Service Mode Displayed.

  • Page 14: Block Diagram

    FLASH MEMORY (M29W160ET : IC12) BLOCK DIAGRAM PIN DESCRIPTION A0-A19 Address Inputs DQ0-DQ7 Data Inputs/Outputs V CC DQ8-DQ14 Data Inputs/Outputs DQ15A–1 Data Input/Output or Address Input A0-A19 DQ0-DQ14 Chip Enable DQ15A–1 Output Enable M29W160ET Write Enable M29W160EB Reset/Block Temporary Unprotect Ready/Busy Output BYTE BYTE...

  • Page 15: Pin Description

    SDRAM for MPEG/SACD (M12L64164 : IC13, IC21) BLOCK DIAGRAM Clock Generator Bank D Bank C Bank B Address Address Buffer Bank A Mode & Register Refresh Counter Sense Amplifier L(U)DQM Column Column Decoder Address Buffer & Refresh Counter Data Control Circuit PIN DESCRIPTION System Clock Active on the positive going edge to sample all inputs...
  • Page 16 RS-232 TRANSCEIVER (ST202 : IC31) BLOCK DIAGRAM +5V INPUT +10V +5V TO +10V VOLTAGE DOUBLER -10V +10V TO -10V VOLTAGE INVERTER RS 232 OUTPUTS TTL / CMOS INPUTS RS 232 INPUTS TTL / CMOS OUTPUTS Note 1: C capacitors can even be 1 F ones. Note 2: C can be common or biased capacitors.
  • Page 17 VIDEO ENCODER (ADV7320 : IC51) BLOCK DIAGRAM PIN DESCRIPTION Pin No. Mnemonic Input/Output Description 11, 57 DGND Digital Ground. AGND Analog Ground. CLKIN_A Pixel Clock Input for HD (74.25 MHz Only, PS Only (27 MHz), SD Only (27 MHz). CLKIN_B Pixel Clock Input.
  • Page 18 PIN DESCRIPTION Pin No. Mnemonic Input/Output Description 62–58, S9 to S0 SD or Progressive Scan/HDTV Input Port for Cr[Red/V] Data in 4:4:4 Input Mode. LSB is set up 55–51 on Pin S0. For 8-bit data input, LSB is set up on S2. RESET This input resets the on-chip timing generator and sets the ADV7320/ADV7321 into default register setting.
  • Page 19 PIN DESCRIPTION Pin Name DESCRIPTION The system clock input. All other inputs are registered to the Clock SDRAM on the rising edge of CLK. Controls internal clock signal and when deactivated, the SDRAM will Clock Enable be one of the states among power down, suspend or self refresh Chip Select Enables or disables all inputs except CLK, CKE and DQM Selects bank to be activated during RAS activity...
  • Page 20 PIN DESCRIPTION PIN No Pin Name Function VINFC Input for focus driver TRB_1 Connect to external transistor base REGO2 Regulator voltage output, connect to external transistor collector VINSL+ Input for the sled driver REGO1 Regulator voltage output, connect to external transistor collector Tray driver forward input Tray driver reverse input Vcc1...
  • Page 21 DATA SELECTOR (74LVC157 : IC86) FUNCTION TABLE INPUTS OUTPUT DATA SELECT logic diagram (positive logic) 2-10...

  • Page 22: Pin Assignment

    BUFFER (54AHCT541 : IC63) FUNCTION TABLE (each buffer/driver) INPUTS OUTPUT To Seven Other Channels BUFFER (74HCT7007 : IC55) PIN ASSIGNMENT PIN ASSIGNMENT 2-11...

  • Page 23: Logic Diagram

    AUDIO OPERATIONAL AMPLIFIERS (OPA2134 : IC82, IC83, IC84, IC85) OPA134 Offset Trim Offset Trim –In Output V– 8-Pin DIP, SO-8 AND GATE (7SZ08FU : IC98) AND GATE (7SH08FU : IC15, IC27, IC78, IC90) PIN CONNECTION (TOP VIEW) LOGIC DIAGRAM LOGIC DIAGRAM SWITCHER (7S66FU : IC28, IC87) LOGIC DIAGRAM PIN CONNECTION (TOP VIEW)
  • Page 24 2-13...
  • Page 25 2-14...
  • Page 26 2-15...
  • Page 27 x Nz BLOCK DIAGRAM to host host_sel HOST INTERFACE REGISTER HOST INTERFACE MEMORY FRONT- PSP-KEY MANAGER DECODER INTERFACE PI-bus control 8-CHANNEL data-bus DECRYPTION/ DSD2PCM SECTOR CONVERSION DEMUX PROCESSOR SACD 2, 5 or 6-channel SPEAKER SETUP PI-BUS AUDIO LOSSLESS VOLUME CONTROL DSD/PCM CONTROL SWITCH...
  • Page 28 I/P UPSCALAR (FLI2310 : IC61) BLOCK DIAGRAM PIN DESCRIPTION 2-17...
  • Page 29 2-18...
  • Page 30 2-19...
  • Page 31 2-20...
  • Page 32 2-21...
  • Page 33 VIDEO DRIVER (BH7862FS : IC52) BLOCK DIAGRAM CTRAP COUT 75Ω MUTE1 TEST MUTE1 TEST 1.5-6M 75Ω MIXOUT MIXFB YTRAP CLAMP CLAMP PYIN 75Ω YOUT PYTRAP PYOUT 75Ω PYFB PbIN PbOUT PrIN 75Ω N.C. MUTE2 MUTE2 PrOUT PrTRAP 75Ω 2-22...
  • Page 34 PIN DESCRIPTION Pin No. Pin name Input/output equivalent circuit Pin description Signal input terminal. Input terminal for chroma signal and color-difference PbIN signal. PrIN Bias type input. The input impedance is 20kΩ. Signal input terminal. PYIN Input terminal for luminance signal. Di clamp input.
  • Page 35 Pin No. Pin name Input/output equivalent circuit Pin description Signal output terminal. PYFB PYOUT Output terminal for luminance signal (progressive type). Signal output terminal. PrOUT PbOUT Output terminal for color-difference signal. CTPAP YTRAP Terminal for LC resonance. PYTRAP PrTRAP Power supply voltage. is separated into 6 pin and 11 pin.
  • Page 36 Pin No. Pin name Input/output equivalent circuit Pin description Mute control terminal. MUTE2 PY, Pb and PR are muted simultaneously by setting MUTE to "L". Test terminal. TEST Usually, short-circuit this terminal to GND when using it. − N.C. 2-25...
  • Page 37 VIDEO DRIVER (BA7660FS : IC53) BLOCK DIAGRAM MUTE OUTA1 75Ω OUTA2 OUTB1 75Ω OUTB2 N.C. N.C. MUTE (1pin) OUTC1 75Ω 3ch MUTE OUTC2 NORMAL 2-26...
  • Page 38 PIN DESCRIPTION Reference Pin. No Pin name Equivalent circuit Function voltage Muting control MUTE — — If MUTE (pin 1) is set to HIGH, muting is carried out simultaneously on all three channels. Signal input Input signals consist of composite video signals, Y signals, C signals, —...
  • Page 39 HOST MICOM (ST72F321R9 : IC41) BLOCK DIAGRAM 8-BIT CORE PROGRAM MEMORY (16K - 60K Bytes) RESET CONTROL (512 - 2048 Bytes) WATCHDOG OSC1 OSC2 PA7:0 MCC/RTC/BEEP (8-bits) PORT A PORT F PORT B PF7:0 PB7:0 (8-bits) (8-bits) TIMER A PWM ART BEEP PORT C PORT E...
  • Page 40 PIN DESCRIPTION SYMBOL FUNCTION SYMBOL FUNCTION PE4(HS) RS-232C_RTS VDD_0 U+5V PE5(HS) RS-232C_CTS VSS_0 PE6(HS) VFD RESET PC0/OCMP2_B/AIN12 PE7(HS) PC1/OCMP1_B/AIN13 PB0/PWM3 Ext. Remote IN #1 PC2(HS)/ICAP2_B PB1/PWM2 Ext. Remote IN #2 PC3(HS)/ICAP1_B PB2/PWM1 PC4/MISO/ICCDATA ICCDATA PB3/PWM0 PC5/MOSI/AIN4 PB4(HS)/ARTCLK PC6/SCK/ICCCLK ICCCLK PB5/ARTIC1 HDMI Detect PC7/SS/AIN15 PB6/ARTIC2...
  • Page 41 AUDIO DAC (CS4382 : IC81) BLOCK DIAGRAM PIN DESCRIPTION 2-30...
  • Page 42 2-31...
  • Page 43 SMPS CURRENT MODE CONTROLLER (ICE3B0365J : IC91) BLOCK DIAGRAM Typical Application Converter Snubber DC Output 85 ... 270 VAC Bulk Drain Startup Cell Power Management PWM Controller Depl. Current Mode CoolMOS™ Precise Low Tolerance Peak Current Limitation Sense Active Burst Mode Control Unit SoftS...
  • Page 44 EEPROM (BR24C16 : IC14) 2-33...
  • Page 45 ITEM OUTPUT VOLTAGE (V) PACKAGE KIA1117S/F00 Adjustable (1.25~10V) KIA1117S/F15 KIA1117S/F18 S : SOT-223 KIA1117S/F25 F : DPAK KIA1117S/F28 2.85 KIA1117S/F33 MILLIMETERS 6.5 0.2 KIA1117S/F50 3.5 0.2 1.8 MAX 0.7+0.15/-0.1 7 0.3 2.3 TYP 0.26+0.09/-0.02 1. COMMOIN (ADJ.) 3.0+0.15/-0.1 2. OUTPUT 1.75 0.25 3.
  • Page 46 BLOCK DIAGRAM 2-35 2-36...

  • Page 47: Wiring Diagram

    WIRING DIAGRAM 2-37 2-38...

  • Page 48: Front Schematic Diagram

    FRONT SCHEMATIC DIAGRAM 2-39 2-40...

  • Page 49: Main Schematic Diagram

    MAIN SCHEMATIC DIAGRAM 1 2-41 2-42...
  • Page 50 MAIN SCHEMATIC DIAGRAM 2 2-43 2-44...
  • Page 51 MAIN SCHEMATIC DIAGRAM 3 2-45 2-46...
  • Page 52 MAIN SCHEMATIC DIAGRAM 4 2-47 2-48...
  • Page 53 MAIN SCHEMATIC DIAGRAM 5 2-49 2-50...

  • Page 54: Smps Schematic Diagram

    SMPS SCHEMATIC DIAGRAM 2-51 2-52...
  • Page 55 FRONT PCB (CUP11991Y) 2-53 2-54...
  • Page 56 MAIN PCB (CUP11992Y) : TOP VIEW 2-55 2-56...
  • Page 57 MAIN PCB (CUP11992Y) : BOTTOM VIEW 2-57 2-58...
  • Page 58 SMPS PCB (CUP11993Z) 2-59 2-60...

  • Page 59: Electrical Parts List

    SECTION 3 ELECTRICAL PARTS LIST REF NO. PART NO DESCRIPTION REMARK FRONT PCB ASS'Y (COP11991B) CUP11991Y PCB, FRONT T535 330X163, FR-1 0.2 EA C101 HCBS1H104ZFT CAP , CERAMIC C102 HCBS1H470JT CAP , CERAMIC C103 HCBS1H470JT CAP , CERAMIC C104 HCBS1H104ZFT...
  • Page 60 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) CUP11992Y PCB , MAIN T535 FR-4, 296X229MM CIP11992BBSMD MAIN PCB SMD BOTTOM ASS'Y T535 C110 CCUS1H330JA CAP , CHIP C117 CCUS1H104KC CAP , CHIP C121 CCUS1H104KC...
  • Page 61 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) C218 CCUS1H104KC CAP , CHIP C219 CCUS1H104KC CAP , CHIP C220 CCUS1H104KC CAP , CHIP C222 CCUS1H104KC CAP , CHIP C223 CCUS1H104KC CAP , CHIP C228 CCUS1H104KC CAP , CHIP C248...
  • Page 62 1608 SIZE R159 CRJ10DJ472T RES , CHIP 1608 SIZE R471 CRJ10DJ0R0T RES , CHIP 1608 SIZE CIP11992BTSMD MAIN PCB SMD TOP ASS'Y T535 EU CN11 CJP24GA195ZM SMT FFC/FPC WAFER(0.5MM PITCH) 52559-2472 (PB FREE) C101 CCUS1H104KC CAP , CHIP C102 CCUS1H102KC...
  • Page 63 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) C142 CCUS1H102KC CAP , CHIP C143 CCUS1H102KC CAP , CHIP C145 CCUS1H102KC CAP , CHIP C146 CCUS1H102KC CAP , CHIP C148 CCUS1H272KC CAP , CHIP C149 CCUS1H273KC CAP , CHIP 0.02...
  • Page 64 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) C538 CCUS1H220JA CAP , CHIP C547 CCUS1H560JA CAP , CHIP C550 CCUS1H104KC CAP , CHIP C551 CCUS1H104KC CAP , CHIP C552 CCUS1H470JA CAP , CHIP C553 CCUS1H470JA CAP , CHIP C554...
  • Page 65 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) C884 CCUS1H104KC CAP , CHIP C886 CCUS1H104KC CAP , CHIP C888 CCUS1H104KC CAP , CHIP C898 CCUS1H104KC CAP , CHIP C900 CCUS1H104KC CAP , CHIP C902 CCUS1H104KC CAP , CHIP C903...
  • Page 66 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) IC53 HVIBA7660FS IC , R.G.B DRIVER BA7660FS IC54 HVIBU2098F IC , I2C BUS ROHM IC55 HVITC74HCT7007F TC74HC7007AFEL IC61 CVIFLI2310LFCF I/P CONVERTER, FLI2310-LF-CF FLI2310-LF-CF IC62 CVI57V643220TP6 I.C , 64M SDRAM, 6nS,86P TSOP HY57V643220B 6NS IC63 HVISN74AHC541PW...
  • Page 67 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) L515 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L516 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L601 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L603 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L604 HLZ9R001Z...
  • Page 68 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) Q816 HVTKTD1304T T.R , CHIP (MUTE) KTD1304 Q817 HVTKTD1304T T.R , CHIP (MUTE) KTD1304 Q818 HVTKTD1304T T.R , CHIP (MUTE) KTD1304 Q819 HVTKTD1304T T.R , CHIP (MUTE) KTD1304 Q820 HVTKTD1304T...
  • Page 69 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R109 CRJ10DJ113T RES , CHIP 1608 SIZE R110 CRJ10DJ103T RES , CHIP 1608 SIZE R111 CRJ10DJ105T RES , CHIP 1608 SIZE R112 CRJ10DJ223T RES , CHIP 1608 SIZE R113 CRJ10DJ223T...
  • Page 70 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R181 CRJ10DJ0R0T RES , CHIP 1608 SIZE R182 CRJ10DJ750T RES , CHIP 1608 SIZE R183 CRJ10DJ750T RES , CHIP 1608 SIZE R184 CRJ10DJ471T RES , CHIP 1608 SIZE R185 CRJ10DJ330T...
  • Page 71 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R423 CRJ10DJ220T RES , CHIP 1608 SIZE R424 CRJ10DJ220T RES , CHIP 1608 SIZE R425 CRJ10DJ100T RES , CHIP 1608 SIZE R426 CRJ10DJ103T RES , CHIP 1608 SIZE R427 CRJ10DJ103T...
  • Page 72 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R566 CRJ10DJ102T RES , CHIP 1608 SIZE R567 CRJ10DJ471T RES , CHIP 1608 SIZE R568 CRJ10DJ471T RES , CHIP 1608 SIZE R569 CRJ10DJ223T RES , CHIP 1608 SIZE R570 CRJ10DJ102T...
  • Page 73 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R639 CRJ10DJ330T RES , CHIP 1608 SIZE R644 CRJ10DJ330T RES , CHIP 1608 SIZE R645 CRJ10DJ330T RES , CHIP 1608 SIZE R646 CRJ10DJ472T RES , CHIP 1608 SIZE R647 CRJ10DJ330T...
  • Page 74 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R816 CRJ10DJ0R0T RES , CHIP 1608 SIZE R817 CRJ10DJ132T RES , CHIP 1608 SIZE R818 CRJ10DJ132T RES , CHIP 1608 SIZE R819 CRJ10DJ132T RES , CHIP 1608 SIZE R820 CRJ10DJ132T...
  • Page 75 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R879 CRJ10DJ132T RES , CHIP 1608 SIZE R880 CRJ10DJ132T RES , CHIP 1608 SIZE R881 CRJ10DJ332T RES , CHIP 1608 SIZE R882 CRJ10DJ332T RES , CHIP 1608 SIZE R883 CRJ10DJ102T...
  • Page 76 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) R952 CRJ10DJ151T RES , CHIP 1608 SIZE R980 CRJ10DJ0R0T RES , CHIP 1608 SIZE R981 CRJ10DJ0R0T RES , CHIP 1608 SIZE R996 CRJ10DJ0R0T RES , CHIP 1608 SIZE R997 CRJ10DJ0R0T...
  • Page 77 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) C543 CCEA1HH220T CAP , ELECT 22UF 50V C544 CCEA1CH101T CAP , ELECT 100UF 16V C545 CCEA1HH220T CAP , ELECT 22UF 50V C546 CCEA1CH101T CAP , ELECT 100UF 16V C548 CCEA1CH101T...
  • Page 78 DESCRIPTION REF NO. PART NO REMARK C / CT Version MAIN PCB ASS'Y (COP11992B) C861 HCQI1H222JZT CAP , MYLAR C862 HCQI1H222JZT CAP , MYLAR C866 CCEA1CH221T CAP , ELECT 220UF 16V C867 HCEA1CR470T ELECT , CAP (ELNA/ROS) C873 CCEA1CH221T CAP , ELECT 220UF 16V C875 CCEA1CH221T...
  • Page 79 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) CUP11992Y PCB , MAIN T535 FR-4, 296X229MM CIP11992CBSMD MAIN PCB SMD BOTTOM ASS'Y T535 C110 CCUS1H330JA CAP , CHIP C117 CCUS1H104KC CAP , CHIP C121 CCUS1H104KC...
  • Page 80 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) C218 CCUS1H104KC CAP , CHIP C219 CCUS1H104KC CAP , CHIP C220 CCUS1H104KC CAP , CHIP C222 CCUS1H104KC CAP , CHIP C223 CCUS1H104KC CAP , CHIP C228 CCUS1H104KC CAP , CHIP C248...
  • Page 81 1608 SIZE R159 CRJ10DJ472T RES , CHIP 1608 SIZE R471 CRJ10DJ0R0T RES , CHIP 1608 SIZE CIP11992CTSMD MAIN PCB SMD TOP ASS'Y T535 US CN11 CJP24GA195ZM SMT FFC/FPC WAFER(0.5MM PITCH) 52559-2472 (PB FREE) C101 CCUS1H104KC CAP , CHIP C102 CCUS1H102KC...
  • Page 82 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) C142 CCUS1H102KC CAP , CHIP C143 CCUS1H102KC CAP , CHIP C145 CCUS1H102KC CAP , CHIP C146 CCUS1H102KC CAP , CHIP C148 CCUS1H272KC CAP , CHIP C149 CCUS1H273KC CAP , CHIP 0.02...
  • Page 83 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) C538 CCUS1H220JA CAP , CHIP C547 CCUS1H560JA CAP , CHIP C550 CCUS1H104KC CAP , CHIP C551 CCUS1H104KC CAP , CHIP C552 CCUS1H470JA CAP , CHIP C553 CCUS1H470JA CAP , CHIP C554...
  • Page 84 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) C900 CCUS1H104KC CAP , CHIP C902 CCUS1H104KC CAP , CHIP C903 CCUS1H102KC CAP , CHIP C923 CCSJA1C100B CAP , CHIP TANTAL(A TYPE, 10uF C924 CCUS1H104KC CAP , CHIP C925 CCUS1H104KC CAP , CHIP...
  • Page 85 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) IC81 HVICS4382-KQ I.C , DAC CS4382-KQ IC82 HVIOPA2134UA I.C , OP AMP IC83 HVIOPA2134UA I.C , OP AMP IC84 HVIOPA2134UA I.C , OP AMP IC85 HVIOPA2134UA I.C , OP AMP IC86 HVI74LVC157ADBR...
  • Page 86 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) L611 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L801 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L802 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L811 HLZ9R001Z FB, 2012(0805)600E, 1.5A,POWER 600E, 1.5A L812 HLZ9R001Z...
  • Page 87 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) RN07 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 RN08 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 RN09 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 RN10 CRJ104DJ101T RES , CHIP NETWORK(1/16W, 100o 100R (1608) RN11...
  • Page 88 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R123 CRJ10DJ273T RES , CHIP R124 CRJ10DJ562T RES , CHIP 1608 SIZE R125 CRJ10DJ562T RES , CHIP 1608 SIZE R126 CRJ10DJ562T RES , CHIP 1608 SIZE R127 CRJ10DF4700T RES, CHIP 470 OHM/1608/1%...
  • Page 89 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R195 CRJ10DJ0R0T RES , CHIP 1608 SIZE R196 CRJ10DJ121T RES , CHIP 1608 SIZE R197 CRJ10DJ121T RES , CHIP 1608 SIZE R198 CRJ10DJ121T RES , CHIP 1608 SIZE R199 CRJ10DJ121T...
  • Page 90 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R501 CRJ10DJ472T RES , CHIP 1608 SIZE R503 CRJ10DJ330T RES , CHIP 1608 SIZE R504 CRJ10DJ330T RES , CHIP 1608 SIZE R505 CRJ10DJ0R0T RES , CHIP 1608 SIZE R506 CRJ10DJ472T...
  • Page 91 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R590 CRJ10DJ472T RES , CHIP 1608 SIZE R591 CRJ10DJ0R0T RES , CHIP 1608 SIZE R592 CRJ10DJ220T RES , CHIP 1608 SIZE R593 CRJ10DJ220T RES , CHIP 1608 SIZE R594 CRJ10DJ0R0T...
  • Page 92 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R775 CRJ10DJ101T RES , CHIP 1608 SIZE R776 CRJ10DJ221T RES , CHIP 1608 SIZE R777 CRJ10DJ474T RES , CHIP 1608 SIZE R778 CRJ10DJ223T RES , CHIP 1608 SIZE R779 CRJ10DJ224T...
  • Page 93 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R841 CRJ10DJ332T RES , CHIP 1608 SIZE R842 CRJ10DJ332T RES , CHIP 1608 SIZE R843 CRJ10DJ102T RES , CHIP 1608 SIZE R844 CRJ10DJ102T RES , CHIP 1608 SIZE R845 CRJ10DJ221T...
  • Page 94 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) R904 CRJ10DJ330T RES , CHIP 1608 SIZE R905 CRJ10DJ330T RES , CHIP 1608 SIZE R906 CRJ10DJ330T RES , CHIP 1608 SIZE R907 CRJ10DJ330T RES , CHIP 1608 SIZE R908 CRJ10DJ330T...
  • Page 95 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) C257 CCEA1EH470T CAP , ELECT 47UF 25V C258 CCEA1EH470T CAP , ELECT 47UF 25V C259 CCEA1EH470T CAP , ELECT 47UF 25V C260 CCEA1EH470T CAP , ELECT 47UF 25V C261 CCEA1EH470T...
  • Page 96 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) C804 CCEA1HH100T CAP , ELECT 10UF 50V C807 CCEA1EH470T CAP , ELECT 47UF 25V C809 CCEA1HH1R0T CAP , ELECT 1UF 50V C810 CCEA1CH101T CAP , ELECT 100UF 16V C812 HCQI1H222JZT...
  • Page 97 DESCRIPTION REF NO. PART NO REMARK AH / AHT Version MAIN PCB ASS'Y (COP11992C) JK51 CJJ9N006Z JACK (S-VIDEO + CVBS) GOLD, 2P JK52 CJJ4S014Z JACK , IN/OUT (R.G.B) RCA-305AG-06 JK55 CJJ2D008Z JACK , STEREO JK81 CJJ4P019Y JACK , BOARD GOLD , PLATE JK82 CJJ4P019Y JACK , BOARD...
  • Page 98 DESCRIPTION REF NO. PART NO REMARK SMPS PCB ASS'Y (COP11993B) CUP11993Z PCB , SMPS T535 CEM-1, 197X230MM, 0.5EA C902 CCEA1HH220TS CAP , ELECT 50V/22UF/105'C C904 CCEA1HH1R0TS CAP , ELECT 50V/1.0UF/105'C C906 CCEA1HH220TS CAP , ELECT 50V/22UF/105'C C907 CCEA1HH220TS CAP , ELECT...
  • Page 99 DESCRIPTION REF NO. PART NO REMARK SMPS PCB ASS'Y (COP11993B) R904 CRD20TJ470T RES , CARBON 47 OHM 1/5W J R907 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R909 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R911 CRD25TJ330T RES , CARBON 33 OHM 1/4W J R912 CRD20TJ273T...
  • Page 100 DESCRIPTION REF NO. PART NO REMARK SMPS PCB ASS'Y (COP11993B) IC91 CVIICE3B0365J IC, CooLSET ICE3B0365J ICE3B0365J DIP-8P IC92 BVISG6842JLDZ IC , PWM IC93 CVICEF04N7ZA FET HEAT SINK ASS'Y (CEF04N7) LF91 CLZ9Z072Z LINE FILTER (DVD-S1700) L901 HLZ93001Z CORE , BEAD L921 CLZ9Z074Z COIL , CHOKE(20uH) L922...
  • Page 101 © NAD 2007 NAD ELECTRONICS INTERNATIONAL TORONTO...
