- Page 1 ИНСТРУКЦИЯ TECHNO-3 НАГРУЗКА для телевизоров LCD/LED кг 15"-40" РАССТОЯНИЕ 38 -102 Расстояние до стены мм НАКЛОН Угол наклона +8°-15° ПОВОРОТ Угол поворота 180° 75х75 100х100 200х100 200х200 НАКЛОННО-ПОВОРОТНЫЙ...
- Page 2 Dear Customer! Thank you for choosing our product. This user manual contains the information about assembling procedure and mounting instructions. Please care- fully learn it and follow the guidelines stated here in order to completely use all the advantages and convenience which our wall mounts give you.
- Page 3 · ВНИМАНИЕ TECHNO-3 bracket for wall mounting LCD / LED TV-sets with screen sizes 15“-40” inches (38-102 cm) and maxi- mum load for 20 kg. • The wall plate must be mounted on solid Concrete, concrete block mounting or wood stud with plaster thickness not more than 3 mm.
- Page 4 COMPLETE SET · КОМПЛЕКТАЦИЯ SCREW SET TO TV M4 *8mm x 4 M4*12mm x 4 M5 *8mm x 4 M5*12mm x 4 M6*8mm x 4 M6*12mm x 4 M8*8mm x 4 M8*12mm x 4 WALL MOUNTING SET 25*25 x 4 S=13 S=4 x 1 S=6 x 1...
- Page 5 ШАГ STEP Wood Stud Mounting - Attach vertically to the wall and mark the water level with a pencil strictly vertical line. - Using the bracket as a template, mark with a pencil three dots on a wall for drilling holes - Drill in the wall three holes of 4 mm diameter and at least 50 mm depth - Mount the wall plate to the wall and fasten it with a lag-bolt (A) - Don’t tighten the screws too hard...
- Page 6 ШАГ STEP Solid Concrete and Concrete Block Mounting - Attach vertically to the wall and mark the water level with a pencil strictly vertical line. - Using the bracket as a template, mark with a pencil three dots on a wall for drilling holes - Drill in the wall three holes of 8 mm diameter and at least 50 mm depth - Insert plastic anchors (B) in the holes and ensure they are fully wedged inside the wall - Mount the bracket to the wall and fasten it with a lag-bolt (A)
- Page 7 ШАГ STEP D/E/F/G/H/I/J/K - Please loosen the bolt in order to separate the wall plate and TV plate. - Select the mounting position for the TV fixed plate and the suitable bolts from the parts bag according to the size of TV and the thread holes at the back of the TV.
- Page 8 ШАГ STEP Cтена Hook the TV plate with TV onto the top of wall plate first as picture. Then slowly lower the bottom of the TV until the TV plate hold the wall plate completely. Finally, tighten of bolt on one side of TV plate. Note: 2 or more people requined for installation.
- Page 9 ШАГ STEP The TV can be adjusted to desire location by tilt and swivel. For the tilt, loosen the knob on wall plate, tilt the TV and tighten the knob when the TV is at the angle your choose. Loosen the knob again when you want to re-adjust the TV angle and tighten this knob again.
- Page 10 Company KROMAX grants 18 years producer guarantee on all welding and mechanical connections. In case of any defects detection the product will be repaired or replaced for free. If the model is out of production, the company KROMAX has the right to offer substitute of the similar price and functionality.
- Page 11 СХЕМА · SCHEME min 60 max 370 mm +8°-15° ±360° ±5° ±180° ±180°...
