- Page 1 GeoMax Zone60 HG User Manual Version 1.0 English...
- Page 2 Read carefully through the User Manual before you switch on the product. Product Identification The type and serial number of your product are indicated on the type plate. Always refer to this information when you need to contact your agency or GeoMax authorised service work- shop. Validity of this manual This manual applies to the Zone60 HG lasers.
-
Page 3: Table Of Contents
General 1.6.2 Zone60 HG Electromagnetic Compatibility EMC FCC Statement, Applicable in U.S. Description of the System System Components Zone60 HG Laser Components Case Components Setup Operation User Interface LCD Display Information Grade Entry Elevation (H.I.) Alert, Bump Alert and Smart Slope Functions... -
Page 4: Safety Directions
• Use after misappropriation. • Use of products with obvious damages or defects. • Use with accessories from other manufacturers without the prior explicit approval of GeoMax. • Inadequate safeguards at the working site. • Deliberate dazzling of third parties. -
Page 5: Limits Of Use
Responsibilities Manufacturer of the GeoMax AG, CH-9443 Widnau, hereinafter referred to as GeoMax, is responsible for supplying the product, product including the user manual and original accessories, in a safe condition. - Page 6 Using the product after incorrect attempts were made to carry out repairs Precautions: Do not open the product. Only GeoMax authorised service workshops are entitled to repair these products. If the product is improperly disposed of, the following can happen: WARNING •...
-
Page 7: Laser Classification
Electromagnetic radiation can cause disturbances in other equipment. WARNING Although the product meets the strict regulations and standards which are in force in this respect, GeoMax cannot completely exclude the possibility that other equipment may be disturbed. Zone60 HG | 7... -
Page 8: Fcc Statement, Applicable In U
Disturbances caused by electromagnetic radiation can result in erroneous measurements. CAUTION Although the product meets the strict regulations and standards which are in force in this respect, GeoMax cannot completely exclude the possibility that the product may be disturbed by intense electromagnetic radiation, for example, near radio transmitters, two-way radios or diesel generators. - Page 9 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 011243_001 Zone60 HG | 9 Safety Directions...
-
Page 10: Description Of The System
• Landscaping In Grade mode the Zone60 HG checks first the position of the beam at level, then adjusts to the desired grade input. If a single grade is entered, the cross axis will continue to self-level. Once the Zone60 HG has reached the desired grade, it does not self-level, but is monitored by Bump Alert and temperature change functions to ensure reliable grade values. -
Page 11: Case Components
Place the Zone60 HG on a stable ground. Ground vibration and extremely windy conditions can affect the operation of the Zone60 HG. • When working in a very dusty environment place the Zone60 HG up-wind so the dirt is blown away from the laser. Setting up on a Tripod -... -
Page 12: Operation
Tighten the screw on the underside of the tripod to secure the Zone60 HG on the tripod. • Attach the Zone60 HG securely to a tripod or laser trailer, or mount on a stable level surface. • Always check the tripod or laser trailer before attaching the Zone60 HG. Make sure all screws, bolts and nuts are tight. -
Page 13: Lcd Display Information
Main user screen The Main user screen show the grade input. 006039_001 The grade shown must be 0.00% to use the Zone60 HG in Level mode screen Level mode, for example for forms and footings. In Level mode, the Zone60 HG automatically levels to the horizontal plane. -
Page 14: Elevation (H.i.) Alert, Bump Alert And Smart Slope Functions
To restore the last set grade(s), press and hold the Grade button for 1.5 seconds. If after eight seconds no button is pressed, the Zone60 HG will accept the grade entered and will begin the grade setting process. Grade setting process... -
Page 15: Zone60 Hg Option Menu
Zone60 HG is used for grade. The Bump Alert function becomes active and monitors the movement of the Zone60 HG when it has completely levelled and the head starts rotating. If the Zone60 HG gets disturbed, the Bump Alert screen is displayed and the Zone60 HG beeps rapidly. - Page 16 If changing from Percent to Per mil, confirma- tion for the change is necessary. 006145 001 Confirm Percent 006054_001 Percent The Percent and Per mil screens to the left are equal. 006055_001 Per mil Zone60 HG | 16 Operation...
-
Page 17: Receivers
Receivers Description The Zone60 HG is sold with the ZRB35, ZRP105 or ZRD105 Receiver. ZRB35 Receiver Instrument components part 1 of 2 a) Level vial b) Keypad c) On-grade d) Laser Reception window e) LCD window 011190_001 Audio Speaker Component... -
Page 18: Zrp105 Receiver
Access to the battery compartment. Description of the Buttons a) Power b) Audio c) Bandwidth 011195_001 Button Function Power Press once to turn on the Receiver. Audio Press to change the audio output. Bandwidth Press to change detection bandwidth. Zone60 HG | 18 Receivers... -
Page 19: Zrd105, Digital Receiver
Press once to turn on the receiver. Press 1.5 seconds to turn off the receiver. Target Press to capture the digital reading. Bandwidth Press to change detection bandwidths. Audio Press to change the audio output. Zone60 HG | 19 Receivers... -
Page 20: Applications
1 + 2 011197_001 Step Description Set up the Zone60 HG on a tripod. Set up the tripod on a stable surface outside the working area. Attach the receiver to a rod. Turn on the Zone60 HG and the receiver. -
Page 21: Entering Grades
Press the Grade button to enter grade for the y-axis. Press the Grade button again to exit grade entry mode. Once grade is entered, the Zone60 HG will begin to adjust to grade. Do not disturb the Zone60 HG during this process. -
Page 22: Batteries
Low operating temperatures reduce the capacity that can be drawn; high operating temperatures reduce the service life of the battery. Battery for Zone60 HG Charging the Li-Ion The rechargeable Li-Ion battery pack on the Zone60 HG can be charged without removing the battery pack battery pack step-by- from the laser. step... - Page 23 Changing the Li-Ion With the rechargeable Li-Ion battery pack the battery indicator on the Zone60 HG LCD display shows when batteries step-by-step the battery pack is low and needs to be charged. The charge indicator LED on the Li-Ion battery pack indicates when the pack is being charged (flashing slowly) or fully charged (on, not flashing).
-
Page 24: Accuracy Adjustment
30 m (100 ft) Y— 011293_001 Align the second axis of the Zone60 HG by rotating it 90° so that this axis is square to the wall. Allow the Zone60 HG to self-level completely. Mark the position of the beam. -
Page 25: Adjusting The Level Accuracy
Turn off the power. Put the Zone60 HG in an upright position. Press and hold both the Up and Down Arrow buttons. Press the Power button. The X-axis calibration screen appears. The Zone60 HG is now in Cali- bration mode. ... - Page 26 007734_001 Step Description When the hour glass has disappeared, indicating that the Zone60 HG has levelled, check both sides of the Y-axis. Press the Up and Down Arrow Buttons to bring the plane of laser light to the specified level position.
-
Page 27: Troubleshooting
After two minutes in the alert condi- tion, the unit will shut off automati- cally. Servo Limit Alert The Zone60 HG is tipped too far to The Servo Limit Alert screen is shown. reach a level position. Re-level the Zone60 HG within the 6 degree self- levelling range. - Page 28 Zone60 HG to an authorised service centre for service. The laser receiver is not The head is not rotating. The Zone60 HG Check for proper operation of the working properly. may be levelling or in Elevation (H.I.) Zone60 HG.
-
Page 29: Care And Transport
Shipping When transporting the product by rail, air or sea, always use the complete original GeoMax packaging, transport container and cardboard box, or its equivalent, to protect against shock and vibration. -
Page 30: Technical Data
IATA Dangerous Goods Regulations. GeoMax has developed Guidelines on “How to carry GeoMax products” and “How to ship GeoMax products” with Lithium batteries. Before any transportation of a GeoMax product, we ask you to consult these guidelines on our web page (http://www.geomax-positioning.com/dgr) to ensure... - Page 31 12 V DC Output current: 3.0 A Polarity: Shaft: negative, Tip: positive Lithium-Ion battery Type: Li-Ion battery pack Input voltage: 12 V DC pack Input current: 2.5 A Charge time: 5 hours (maximum) at 20°C Zone60 HG | 31 Technical Data...
- Page 32 GeoMax Zone60 HG Series 841545-1.0.0en Original text © 2015 GeoMax AG, Widnau, Switzerland GeoMax AG www.geomax-positioning.com...
