- Page 1 INSTRUCTION MANUAL Angle Grinder 9556HNR 9557HNR 9558HNR DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: 9556HNR 9557HNR 9558HNR Applicable grinding wheel Max. wheel diameter 100 mm 115 mm 125 mm Max. wheel thickness 6.4 mm 7.2 mm Applicable cut-off wheel Max. wheel diameter 105 mm 115 mm 125 mm Max. wheel thickness 3.2 mm Applicable wire wheel brush Max. -
Page 3: Ec Declaration Of Conformity
Noise The typical A-weighted noise level determined according to EN62841-2-3: Model Sound pressure Sound power level Uncertainty (K) : level (L ) : (dB(A)) ) : (dB(A)) (dB(A)) 9557HNR 9558HNR NOTE: The declared noise emission value(s) has been measured in accordance with a standard test method and may be used for comparing one tool with another. -
Page 4: General Power Tool Safety Warnings
Personal safety SAFETY WARNINGS Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or General power tool safety warnings under the influence of drugs, alcohol or med- ication. -
Page 5: Grinder Safety Warnings
Power tool use and care Operations such as polishing are not to be performed with this power tool. Operations for Do not force the power tool. Use the correct which the power tool was not designed may create power tool for your application. The correct a hazard and cause personal injury. - Page 6 12. Position the cord clear of the spinning acces- Safety warnings specific for grinding and cutting-off sory. If you lose control, the cord may be cut or operations: snagged and your hand or arm may be pulled into Use only wheel types that are specified the spinning accessory.
- Page 7 Support panels or any oversized workpiece to Do not touch accessories immediately after minimize the risk of wheel pinching and kick- operation; it may be extremely hot and could back. Large workpieces tend to sag under their burn your skin. own weight.
-
Page 8: Functional Description
To stop the tool, press down the rear end of the slide FUNCTIONAL switch so that it returns to the “O (OFF)” position. DESCRIPTION CAUTION: Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Shaft lock WARNING: Never actuate the shaft lock when... - Page 9 Pull the lever in direction of the arrow. Then tighten the Installing or removing wheel guard wheel guard with fastening the screw. Be sure to tighten (For depressed center wheel, flap disc, the screw securely. The setting angle of the wheel flex wheel, wire wheel brush / abrasive guard can be adjusted with the lever.
- Page 10 Installing or removing depressed Installing or removing flex wheel center wheel or flap disc Optional accessory Optional accessory WARNING: Always use supplied guard when flex wheel is on the tool. Wheel can shatter during WARNING: When using a depressed center use and guard helps to reduce chances of personal wheel or flap disc, the wheel guard must be fitted injury.
- Page 11 Flange. Those flanges are so thick that the entire thread cannot be retained by the spindle. Mount inner flange, abrasive wheel and Ezynut onto the spindle so that Makita Logo on Ezynut faces outside. Fig.17 Fig.14 ► 1. Ezynut 2. Abrasive wheel 3. Inner flange 4.
- Page 12 When installing the diamond wheel: Installing abrasive cut-off / diamond wheel Optional accessory WARNING: When using an abrasive cut-off / diamond wheel, be sure to use only the special wheel guard designed for use with cut-off wheels. WARNING: NEVER use cut-off wheel for side grinding.
- Page 13 Installing wire cup brush Installing hole cutter Optional accessory Optional accessory Place the tool upside down to allow easy access to the CAUTION: Do not use brush that is damaged, spindle. or which is out of balance. Use of damaged brush Remove any accessories on the spindle.
-
Page 14: Operation
Operation with abrasive cut-off / OPERATION diamond wheel WARNING: It should never be necessary to Optional accessory force the tool. The weight of the tool applies ade- quate pressure. Forcing and excessive pressure WARNING: Do not "jam" the wheel or apply could cause dangerous wheel breakage. -
Page 15: Maintenance
To maintain product SAFETY and RELIABILITY, repairs, carbon breakage. brush inspection and replacement, any other maintenance or adjustment should be performed by Makita Authorized or Factory Usage example: operation with wire wheel brush Service Centers, always using Makita replacement parts. - Page 16 COMBINATION OF APPLICATIONS AND ACCESSORIES Optional accessory CAUTION: Using the tool with incorrect guards can cause risks as follows. When using a cut-off wheel guard for facial grinding, the wheel guard may interfere with the work- • piece causing poor control. When using a grinding wheel guard for cutting-off operations with bonded abrasive wheels and dia- •...
-
Page 17: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 20 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885464C223 www.makita.com 20221014...
