Sealey WORKSAFE SSP146.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
REFER TO INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. INTRODUCTION
Heavy-duty traditional leather welding apron protects body parts, clothing and upper legs when welding. Manufactured from split cow hide
leather. SSP146 also features quick release buckles and a front hook and loop pocket. Conforms to EN ISO 11611
Notified Body: 2575
Type Examination Certificate Number: ITASLNB22002556
Carried Out By: INTERTEK ITALIA Spa
2. SAFETY
In the event of accidental splashes of Chemical or Flammable liquids on clothing, the wearer should withdraw and carefully remove the
9
garments, ensuring the chemical or liquid does not come into contact with any part of the skin. Clothing should be cleaned or removed
from service.
The level of protection against flame will be reduced if the welders' protective clothing is contaminated with flammable materials.
9
An increase in the oxygen content of the air will considerably reduce the protection. Care should be taken when welding in confined
spaces, e.g. if it is possible that the atmosphere may become enriched with oxygen.
The electrical insulation provided by clothing will be reduced when the clothing is wet, dirty or soaked with sweat.
9
For two-piece protective clothing, both items must be worn together to provide the specified level of protection.
9
This garment is intended for use in addition to protective clothing providing protection against welding hazards.
9
This clothing is intended to protect against flames, molten metal splatter, radiant heat and short-term, accidental electrical contact.
9
A1 classification provides resistance to flaming ignition from flames against the face of the leather.
9
For operational reasons not all welding voltages carrying parts of arc welding installations can be protected against direct contact.
9
This garment is only intended to protect against brief inadvertent contact with live parts of an arc welding circuit. Additional electrical
9
insulation layers will be required where there is an increased risk of electric shock.
Garments are designed to provide protection against short term accidental contact with live electric conductors at voltages up to
9
approximately 100V DC.
Garments should be fastened and worn correctly for protection.
9
When using these additional protective garments, they must be worn over a suit meeting at least Class 1 of EN 11611:2015. When
9
wearing these items, if you experience sunburn-like symptoms, UVB is penetrating. In this case, the garment should be repaired (if
practical) or replaced and consideration given to the use of additional, more resistant, protective layers in the future.
3. APPLICABLE STANDARDS
EN 11611:2015
Class 2 A1
© Jack Sealey Limited
HEAVY-DUTY LEATHER WELDING APRON
MODEL NO'S:
Type of Selection criteria relating to the process:
welders'
clothing:
Class 1 Manual welding techniques with light formation
of spatter:
- Gas welding
- TIG welding
- MIG welding
- Micro plasma welding
- Brazing
- Spot welding
- MMA welding (with rutile-covered electrode)
Class 2
Manual welding techniques with heavy
formation of spatters:
- MMA welding (with basic or cellulose-covered
electrode)
- MAG welding (with CO2 or mixed gases)
- MIG welding (with high current)
- Self-shielded flux cored arc welding
- Plasma cutting
- Gouging
- Oxygen cutting
- Thermal spraying
Original Language Version
SSP146.V2, SSP/LWA.V2
Selection criteria relating to the
environment conditions:
Operation of machines, e.g.:
- Oxygen cutting machines
- Plasma cutting machines
- Resistance welding machines
- Machines for thermal spraying
- Bench welding
Operation of machines, e.g.:
- In confined spaces
- At overhead welding/cutting or in comparable
constrained positions.
SSP146.V2, SSP/LWA.V2 Issue 1 17/12/24
