Power Pruner
The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Read and understand all provided literature before
use. Failure to do so could result in serious injury.
Note: This product complies with CAN ICES-2/NMB-2.
X7532342100
© 09/24 ECHO Incorporated
Operator's
Manual
PT262
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Pruner PT262 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shindaiwa Power Pruner PT262

Summary of Contents for Shindaiwa Power Pruner PT262

  • Page 1 Operator’s Manual PT262 ® Power Pruner The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Read and understand all provided literature before use. Failure to do so could result in serious injury. Note: This product complies with CAN ICES-2/NMB-2.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PT262 TABLE OF CONTENTS Introduction ....................3 Servicing Information .................. 4 Parts and Serial Number..............4 Service ....................4 Consumer Product Support ..............4 Product Registration ................4 Additional Literature ................4 Safety ......................5 Manual Safety Symbols and Important Information ......5 International Symbols ................

  • Page 3: Introduction

    Scan QR codes for more information. For additional literature, including safety manuals where applicable, or questions regarding terms used in this manual, visit: https://www.echo-usa.com/manuals https://www.shindaiwa-usa.com/manuals X7532342100 © 09/24 ECHO Incorporated...

  • Page 4: Servicing Information

    Service Service of this product during the warranty period must be performed by an Authorized Shindaiwa Service Dealer. For the name and address of the Authorized Shindaiwa Service Dealer nearest you, ask your retailer or call: 1-877-986-7783. Dealer information is also available on www.shindaiwa- usa.com.

  • Page 5: Safety

    PT262 SAFETY SAFETY Manual Safety Symbols and Important Information Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.

  • Page 6: International Symbols

    SAFETY PT262 International Symbols Symbol Description Symbol Description Warning, See Carburetor Operator’s Adjustment - High Manual Speed Mixture Wear Eye, Ear Carburetor and Head Adjustment - Idle Protection Speed Carburetor Wear Hand and Adjustment - Low Foot Protection Speed Mixture Safety/Alert Stop STOP...
  • Page 7 PT262 SAFETY Symbol Description Symbol Description DO NOT Allow Ignition Flames or Ignition ON / OFF Sparks Near Fuel DO NOT Smoke Purge Bulb Near Fuel Choke Control Choke Control “COLD START” “RUN” Position Position (Choke (Choke Open) Closed) Wear Slip Resistant Footwear Chain Lubrication...

  • Page 8: Personal Condition And Safety Equipment

    SAFETY PT262 Personal Condition and Safety Equipment Cancer and Reproductive Harm www.P65Warnings.ca.gov The muffler or catalytic muffler and surrounding cover may become extremely hot. If unit is equipped with muffler, always keep clear of exhaust and muffler area, otherwise serious personal injury might occur. Users of this product risk injury to themselves and others if the unit is used improperly and/or safety precautions are not followed.

  • Page 9: Hand Protection

    PT262 SAFETY Hand Protection Wear sturdy, no-slip, rubber work gloves to improve your grip on the handles. Gloves also provide protection against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your hands. Hearing and Ear Protection ECHO recommends wearing personal protective equipment whenever unit is used.
  • Page 10 SAFETY PT262 The components of this machine generate an electromagnetic field during operation, which can interfere with some pacemakers. To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine.
  • Page 11 PT262 SAFETY Repetitive Stress Injuries (RSI) It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).
  • Page 12 SAFETY PT262 Read the Manuals • Provide all users of this equipment with the Operator’s Manual and Safety Manual for instructions on Safe Operation. Clear the Work Area • Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 15 m (50 ft.) while the unit is in use.

  • Page 13: Kickback

    PT262 SAFETY Kickback Kickback can lead to dangerous loss of control of the Power ® Pruner and result in serious injury to the operator or any one ® standing close by. Hold the Power Pruner firmly with both hands with thumbs and fingers encircling the front and rear handles.

  • Page 14: Equipment

    SAFETY PT262 Equipment Use only ECHO attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO Incorporated will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.
  • Page 15 PT262 SAFETY Periodically check fuel system (fuel lines, vent, grommet, fuel tank, and fuel cap) for leaks especially if the unit is dropped. If damage or leaks are found, do not use unit, otherwise serious personal injury or property damage may occur. Have unit repaired by an authorized servicing dealer before using.

  • Page 16: Emission Control (Exhaust & Evaporative)

    PT262 EMISSION CONTROL (EXHAUST & EVAPORATIVE) EPA Emissions Control Information The emission control system for EMISSION CONTROL INFORMATION the engine is EM (engine ENGINE FAMILY: XEHXS.0214KO DISPLACEMENT: 21.2 cc modification) and, if the second to EMISSION COMPLIANCE PERIOD: 300 Hours last character of the Engine Family THIS ENGINE MEETS U.S.EPA EXH/EVP EMISSION on the Emission Control...

  • Page 17: Description

    PT262 DESCRIPTION DESCRIPTION Locate the safety decal(s) or etching(s) on your unit. Make sure they are legible, and that you understand and follow the instructions. If any cannot be read, replacements can be ordered from your Shindiawa dealer. Images shown below are for example only. Those on your unit might appear slightly different.
  • Page 18 DESCRIPTION PT262 Power head Throttle handle - for right hand Throttle trigger lockout Stop switch Strap hook Lower shaft tube Cutting attachment Automatic oiler assembly Guide bar 10. Saw chain 11. Cutting shoe 12. Throttle trigger 13. Shoulder harness 14. Recoil starter handle 15.

  • Page 19: Contents

    PT262 CONTENTS CONTENTS The Shindiawa product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or Shindiawa Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 20: Cutting Attachment To Drive Shaft Installation

    ASSEMBLY PT262 Cutting Attachment to Drive Shaft Installation Saw chain is sharp! Always wear gloves when handling assembly, otherwise serious personal injury may result. Loosen the two (2) screws (A) and remove locator screw (B) on cutting attachment. Loosen clamp knob (E) turning counterclockwise.
  • Page 21 PT262 ASSEMBLY Slide together, aligning locator hole in cutting attachment with locating hole in upper tube (I). Install and tighten locator screw (B). Tighten two (2) cutting attachment screws (A). Extend upper tube (F) to desired length. Tighten clamp knob (E) turning clockwise. X7532342100 ©...

  • Page 22: Saw Chain Adjustment

    ASSEMBLY PT262 Saw Chain Adjustment Always disconnect spark plug wire before servicing cutting attachment. Wear gloves when handling saw chain, otherwise serious personal injury may result. Saw Chain Adjustment Move stop switch to STOP position. Disconnect spark plug lead. Loosen two guide bar nuts (A) until finger tight.

  • Page 23: Operation

    OPERATION Fuel Diesel fuels and alternative fuels, such as E15 (15% ethanol), E85 (85% ethanol) or any fuels not meeting Shindaiwa requirements are NOT approved for use in Shindaiwa two- stroke or hybrid four-stroke gasoline engines. Use of diesel or...
  • Page 24 NOT approved. Use of ECHO branded fuel is recommended to extend engine life in all air-cooled two-stroke and two or four-stroke hybrid engines. Two-Stroke Oil - A two-stroke engine oil, such as Shindaiwa branded two- stroke oils, meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD Standards must be used.
  • Page 25 PT262 OPERATION Handling Fuel Fuel is flammable. Use extreme care when mixing, storing or handling, or serious personal injury may result. Use an approved fuel container.  DO NOT smoke near fuel.  DO NOT allow flames or sparks near fuel. ...
  • Page 26 OPERATION PT262 Mixing Instructions Fuel to Oil Mix – 50:1 Ratio Fill an approved fuel container Metric with half of the required amount of gasoline. Add the proper amount of gal. fl. oz. engine oil to gasoline. Close container and shake to mix oil with gasoline.

  • Page 27: Lubricating The Guide Bar And Saw Chain

    PT262 OPERATION Lubricating the Guide Bar and Saw Chain Automatic Oiling System To prevent plastic deterioration, do not use synthetic or silicone based oil. Wipe debris from around oil fill cap. Remove oil fill cap and fill reservoir with a quality, low viscosity guide bar and saw chain oil.

  • Page 28: Starting Cold Engine

    OPERATION PT262 Starting Cold Engine The attachment will operate immediately when the engine starts, and could result in possible serious injury. Keep movable parts of the attachment away from objects that could become entangled or thrown, and surfaces that could cause loss of control.
  • Page 29 PT262 OPERATION Recoil Starter Lay the unit on a flat area and keep movable attachment parts clear of all obstacles. Firmly grasp throttle handle and throttle trigger lockout with left hand and fully depress throttle trigger to wide open position. Rapidly pull recoil starter handle/rope (D) until engine fires (or maximum five [5] pulls).

  • Page 30: Starting Warm Engine

    OPERATION PT262 Starting Warm Engine The starting procedure is the same as Cold Start except DO NOT close the choke, and do not hold throttle trigger fully depressed. The attachment should not move at idle, otherwise serious personal injury may result. Note: If attachment moves, readjust carburetor according to “Carburetor Adjustment”...

  • Page 31: Stopping Engine

    PT262 OPERATION Recoil Starter Lay the unit on a flat area and keep movable attachment parts clear of all obstacles. Firmly grip throttle handle and throttle trigger lockout with left hand. Rapidly pull recoil starter handle/rope (D) until engine fires. Note: If engine does not start after 5 pulls, use Cold Start Procedure.

  • Page 32: Pruning Techniques

    OPERATION PT262 Pruning Techniques Shoulder Harness (if included) Loosen the harness clamp bolt (A). Put the harness on and attach it to the clamp ring (B). Adjust harness for comfortable operation. Tighten harness clamp bolt (A). ® The Power Pruner attachment is designed for light to medium trimming of limbs and branches up...

  • Page 33: Maintenance

    PT262 MAINTENANCE • Look out for branches Not Correct immediately behind the branch being cut. If saw chain hits a rear branch damage to the saw chain and guide bar may occur. • Accelerate to full speed. Cutting shoe away from branch •...

  • Page 34: Skill Levels

    Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. Level 3 = See your dealer. Click HERE or go to http://www.echo-usa.com/products/maintenance-kit https://www.shindaiwa-usa.com/you-can.aspx X7532342100 © 09/24 ECHO Incorporated...

  • Page 35: Maintenance Intervals

    PT262 MAINTENANCE Maintenance Intervals SKILL COMPONENT/SYSTEM MAINTENANCE PROCEDURE LEVEL Daily or Before Use Air Filter Inspect/Clean* Choke Shutter Inspect/Clean* Fuel System Inspect Cooling System Inspect/Clean Recoil Starter Rope Inspect/Clean* Screws/Nuts/Bolts Inspect/Tighten/Replace* Guide Bar/Sprocket Nose Inspect/Clean/Lubricate* Saw Chain Inspect/Sharpen/Replace/Tension* Every Refuel Fuel System Inspect Guide Bar/Sprocket Nose...

  • Page 36: Air Filter

    MAINTENANCE PT262 Low evaporative fuel tanks DO NOT require regular maintenance to maintain emission integrity. * Replacement is recommended based on the finding of damage or wear during inspection. Air Filter Level 1 Parts required: Tune-up kit. Close choke (COLD START position). This prevents dirt from entering the carburetor throat when the air filter is removed.

  • Page 37: Fuel Filter

    PT262 MAINTENANCE Ensure air filter is assembled with pleats oriented vertically. Fuel Filter Level 1. Parts required: Tune-up kit. Fuel is flammable. Use extreme care when mixing, storing or handling, or serious personal injury may result. Do not damage fuel line while removing fuel filter from tank. Use a clean rag to remove loose dirt from around fuel cap and then empty fuel tank.

  • Page 38: Spark Plug

    MAINTENANCE PT262 When the inside of the fuel tank is dirty, rinse the tank out with gasoline to clean it. Note: Federal EPA regulations require all model year 2012 and later gasoline powered engines produced for sale in the United States to be equipped with a special low permeation fuel supply hose between the carburetor and fuel tank.

  • Page 39: Cooling System

    PT262 MAINTENANCE Cooling System Level 2. To maintain proper engine operating temperatures, cooling air must pass freely through the cylinder fin area. This flow of air carries combustion heat away from the engine. Overheating and engine seizure can occur when: •...

  • Page 40: Exhaust System

    MAINTENANCE PT262 Use brush to remove dirt from the cylinder fins. Remove the air filter cover. Remove grass and leaves from the grid (C) between the recoil starter and fuel tank. Assemble components in reverse order. Exhaust System Spark Arrester Screen Level 2.

  • Page 41: Exhaust Port Cleaning

    PT262 MAINTENANCE Exhaust Port Cleaning Level 2. Parts required: Heat shield (as required). Remove spark plug lead from spark plug, and remove muffler cover. Place piston at top dead center. Remove muffler (A) and heat shield (B). Use a wood or plastic scraping tool to clean deposits from cylinder exhaust port (C).

  • Page 42: Carburetor Adjustment

    MAINTENANCE PT262 Carburetor Adjustment Level 2. When carburetor adjustment is completed, the cutting attachment should not move at idle, otherwise serious personal injury may result. Engine Break-In New engines must be operated a minimum duration of two tanks of fuel break-in before carburetor adjustments can be made.

  • Page 43: Lubrication

    PT262 MAINTENANCE Check idle speed and reset if necessary. If a tachometer is available, idle speed screw (A) should be set to the specifications found on “Specifications” page of this manual. Turn idle screw (A) clockwise to increase idle speed; counterclockwise to decrease idle speed.

  • Page 44: Guide Bar And Saw Chain Replacement

    MAINTENANCE PT262 Guide Bar and Saw Chain Replacement Never try to replace or adjust guide bar and saw chain with engine running. Always disconnect spark plug wire before servicing guide bar and saw chain. This saw chain is VERY sharp, wear heavy gloves to protect your hands when handling it.

  • Page 45: Guide Bar Cover Cleaning

    PT262 MAINTENANCE Guide Bar Cover Cleaning Remove two guide bar nuts (A) and guide bar cover screw (B). Remove guide bar cover (D). Gently brush debris from inside guide bar cover and from around sprocket. Hold the bar nose up. Install guide bar cover (D).

  • Page 46: Filing Standard Saw Chain

    MAINTENANCE PT262 Filing Standard Saw Chain Level 2 ® Power Pruner Bar and Chain Combinations CHAIN BAR P/N CHAIN P/N LINKS PITCH GAUGE TYPE 305 mm (12 in.) 80TXL 0.325 in. 0.025 in. S12A4CD3251 ® Check bar part number on your Power Pruner .
  • Page 47 PT262 MAINTENANCE • Hold the file at a 10° angle as shown.. 10° • Place depth gauge tool firmly on Depth Gauge Tool guide bar so that depth gauge protrudes. Then file top of depth gauge with the flat file until flat with top of the depth gauge tool.
  • Page 48 MAINTENANCE PT262 • Properly filed cutters are 70° shown in illustration. • When setting of the chain is finished, soak it in oil and wash away filings completely 25° before using. Top plate Side plate angle • When chain has been filed on filing angle the bar, supply sufficient oil to it, move the chain slowly to...

  • Page 49: Troubleshooting

    PT262 TROUBLESHOOTING TROUBLESHOOTING ENGINE PROBLEM TROUBLESHOOTING CHART Problem Check Status Cause Remedy Fuel strainer or Clean or replace Fuel at No fuel at fuel line carburetor carburetor See your dealer obstructed No fuel at Carburetor See your dealer cylinder OPEN choke Engine Fuel at Clean or replace...

  • Page 50: Storage

    STORAGE PT262 ENGINE PROBLEM TROUBLESHOOTING CHART Problem Check Status Cause Remedy Plug dirty or Clean and adjust Spark plug Normal wear Engine worn or replace runs, but Improper Carburetor Vibration Adjust dies adjustment Extended Cooling Cooling operation in system dirty Clean system dirty or dusty...
  • Page 51 PT262 STORAGE Do not store in enclosure where fuel fumes may accumulate or reach an open flame or spark. Place the stop switch in the “OFF” position. Remove accumulation of grease, oil, dirt and debris from exterior of unit. Some tree sap and resins are corrosive. Thoroughly wash the guide bar and sprocket areas after each use, then coat metal parts with light oil.

  • Page 52: Specifications

    SPECIFICATIONS PT262 SPECIFICATIONS Model PT262 Length (standard) 2,703 mm (106 in.) Length (extended) 3,691 mm (145 in.) Width 273 mm (10.7 in.) Height 260 mm (10.2 in.) Weight (dry) 7.9 kg (17.4 lb.) Engine Type Air-cooled, two-stroke, single cylinder gasoline engine Bore 34 mm (1.34 in.) Stroke...
  • Page 53 PT262 SPECIFICATIONS Model PT262 Oiling System Automatic Chain Oil Capacity 0.2 L (6.76 US fl. oz) Right hand grip with throttle trigger and throttle trigger Handles lockout Shoulder Harness Standard Idle Speed 3,000 RPM Clutch Engagement 3,970 RPM Speed Wide Open Throttle 11,290 RPM Speed Guide Bar and Saw...

  • Page 54: Product Registration

    PRODUCT REGISTRATION Thank you for choosing Shindaiwa Power Equipment Please go to http://www.shindaiwa-usa.com to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 55 PT262 PRODUCT REGISTRATION X7532342100 © 09/24 ECHO Incorporated...
  • Page 56 U95412001001 - U95412999999 U95513001001 - U95513999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 -usa www.shindaiwa .com...
