SHINDAIWA OWNER'S/OPERATOR'S MANUAL
MULTIPURPOSE POLE
PRUNER TOOL 78702
Minimize the risk of injury to yourself and others!
Read this manual and familiarize yourself with the
contents. Always wear eye and hearing protection
when operating this unit.
WARNING!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 78702 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shindaiwa 78702

Summary of Contents for Shindaiwa 78702

  • Page 1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL MULTIPURPOSE POLE PRUNER TOOL 78702 Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection when operating this unit. WARNING! X7502880702 10/10...

  • Page 2: Table Of Contents

    “IMPORTANT” is one that possesses stand something in this manual, your pruner! special significance. Shindaiwa dealer will be glad to assist you. NOTE: You may also contact Shindaiwa at the This product conducts electricity. Keep...

  • Page 3: Operating Precautions

     Never modify or disable any of the pruner’s safety devices.  Always use genuine Shindaiwa parts and accessories when repairing or maintaining this machine.  Do not make unauthorized modifications to the pole pruner.  When transporting the pole pruner in a vehicle, tie it down securely to prevent fuel spillage or damage to the machine.

  • Page 4: Safety Labels

    Shindaiwa dealer. Operating the Pruner Always wear eye and hearing protection. WARNING! Shindaiwa recommends wearing a face shield as additional face and eye protection. To avoid the chance of serious injury or death, follow these safety precautions Keep bystanders at least 50 feet (15 meters) away...

  • Page 5: Product Description

    Product Description Gearcase/ Cutting Head Prior To Assembly Scabbard Familiarize yourself with the Shindaiwa pole pruner tool and its various compo- Saw Chain nents. Understanding your machine helps ensure top performance, longer service life, and safer operation. Before assembling, make sure you have all...

  • Page 6: Specifications

    Specifications Length ..............222 mm (8.7 in) Chain Type........ 3/8" pitch Micro Lite™,.043" gauge Width ..............74 mm (2.9 in) Sprockets ..............3/8-inch, fixed spur Height ..............116 mm (4.6 in) Gearcase Ratio................1.06 : 1 Dry Weight (Tool only)without bar and chain..0.7 kg (1.5 lbs) Chain Lubrication ........Automatic adjustable oiler Guide Bar..

  • Page 7: Installing And Adjusting The Bar And Chain

    Installing and Adjusting the Bar and Chain Installing The Chain WARNING! Never attempt to install, replace, or adjust the chain with the engine running. WARNING! The saw chain is very sharp. Wear gloves to protect your hands when handling. NOTE: For the longest chain life, let new or replacement chain loops soak in oil overnight before installation.

  • Page 8: Filling The Chain Oiler Reservoir

    Adjusting the Chain WARNING! Never attempt to install, replace, or adjust the chain with the engine running. WARNING! The saw chain is very sharp. Wear gloves to protect your hands when handling. CAUTION! A loose chain can jump off the guide bar causing damage to the chain and associated equipment.

  • Page 9: Using The Pole Pruner

    Adjusting Oil Flow Rate NOTE: The automatic oiler is preset to deliver a sufficient oil discharge volume during normal operating conditions. During heavy or dry cutting conditions, the oil discharge volume may be increased to assure adequate lubrication. If oil is leaking from the bar cover area, reduce the oil discharge volume.

  • Page 10: Maintenance

    If it has been lost or make sure the engine and cutting cause damage and lead to personal misplaced, contact Shindaiwa for a attachment are completely stopped. injury. replacement. Disconnect the spark plug wire...

  • Page 11: Sharpening The Chain

    50-hour Maintenance Every 50 hours of operation (more frequently in dusty or dirty conditions):  Lubricate the gearcase. To perform this operation, first remove the gearcase from the upper outer tube as follows. CAUTION! Do not remove the D-shaped shim washer from the gearcase clamp! The shim washer prevents damage from overtightening the tube clamp screw.
  • Page 12 Sharpening Instructions IMPORTANT! 30° File all the cutters to the same angle and depth! Unequal filing may cause the saw to vibrate or cut erratically! 1. Using a 4.5 mm round file, sharpen all cutters to a 30° angle. Make sure that one fifth (20%) of the file’s diameter is always held above the cutter’s top plate.

  • Page 13: Troubleshooting Guide

    Inspect and replace as necessary. Inspect and reinstall as required. Shaft not installed in powerhead or gearcase. Broken shaft. Consult with an authorized Shindaiwa servicing Chain will not rotate. dealer. Damaged gearcase. Adjust idle. Check Specifi cations page for correct idle Engine idle too high.
  • Page 14 NOTES...
  • Page 15 NOTES...

  • Page 16: Servicing Information

    Genuine Shindaiwa Parts and Assemblies for your Shindaiwa products are available only from an Authorized Shindaiwa Dealer. When you do need to buy parts always have the Model Number, Type and Serial Number of the unit with you. You can find these numbers on the engine. For future reference, write them in the space provided below.
