OWNER'S GUIDE & SERVICE MANUAL
M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N
Model: MPNP415-IS81A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPNP415-IS81A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marvel MPNP415-IS81A

Summary of Contents for Marvel MPNP415-IS81A

  • Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MPNP415-IS81A...

  • Page 2: Warranty Registration

    Got a Marvelous Design? located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed prod- uct at marketing@marvelrefrigeration.com, and we might...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety R600a Specifications Important Safety Instructions System Diagnosis Guide Control Operation - Service Installation Defrost Unpacking Your Appliance Remove Fan and Cover Electrical Warranty Cutout & Product Dimensions Installing Your Appliance Side-by-Side &...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating this appliance. Recognize Safety Symbols, Words and Labels WARNING...

  • Page 5: Unpacking Your Appliance

    UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the Use two or more people to move product. appliance to sit upright for a period of at least 24 hours Failure to do so can result in personal injury.

  • Page 6: Electrical Connection

    ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be Do not remove plugged into a mating grounding type receptacle in ground prong accordance with the National Electrical Code and applicable local codes and ordinances.

  • Page 7: Cutout & Product Dimensions

    CUTOUT & PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS “A” “B” “C” “D” “E” “F” “G” “H” “J” 15” 34” to 35” 24” 14 7/8” 33 3/4” to 34 3/4” 22 7/8” 38 7/8” (38.1 cm) (86.4 cm to 88.9 cm) (61 cm) (37.8 cm) (85.7 cm to 88.3 cm)
  • Page 8 CUTOUT & PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUITEMENTS # WEIGHT 105 lbs 115V/60Hz/15A (47.6 kg) “H” “D” “F” “E” Glass Door 21 1/2” 3 1/2” (8.9 cm) (54.6 cm) Shown Minimum Minimum rough-in opening is required to be larger than the adjusted height of the cabinet.

  • Page 9: Leveling Information

    INSTALLING YOUR APPLIANCE Leveling Information Installation 1. Use a level to confirm if the 1. Plug in the power/electrical cord. unit is level. Level should be 2. Gently push the unit into position. Be careful not to placed along top edge and entangle the cord or water and drain lines, if applicable.

  • Page 10: Side-By-Side & Stacking Installations

    SIDE-BY-SIDE & STACKING INSTALLATION Side-by-Side Installation Stainless steel models which include the standard stainless handle will require 4 9/16” (116 mm) to allow both doors to Other Site Requirements open to 90° at the same time. Units must operate from separate, properly grounded elec- trical receptacles places according to each unit’s electrical 4 9/16”...

  • Page 11: Anti-Tip Bracket

    INSTALLING THE ANTI-TIP DEVICE Anti-Tip Bracket Use one of the methods below to secure the unit. Cabinet.Counter Anti-Tip Installation (For built-in applications) 1. Slide unit out so screws on front of unit are easily accessible. 2. Remove the two screws from the front of the unit. 7 5/8”...

  • Page 12: Door Reversing Instructions

    DOOR REVERSAL Door Reversing Instructions 1. Open door. 2. Loosen screw #1 and #2 using a Philips Screwdriver on top and bottom hinge. Slide door and remove the door from the unit. 3. Once door is removed, using a Philips Screwdriver, remove screws from magnet actuator located on inside and bottom of door (On integrated models, magnet actuator will be located on bottom of door.

  • Page 13: Integrated Panel Dimensions

    INTEGRATED PANEL DIMENSIONS NOTE Due to differences in surrounding cabinetry, the panel may not perfectly align with the door. The procedure below is designed to provide a finished overlay panel that seamlessly integrates with surrounding cabinetry. The door panel must not weigh more than 20 lbs (10 kg). It is important to ensure that all drilled holes are drilles to the correct depth in order to avoid splits in the wood when hardware is installed.

  • Page 14: Integrated Panel Installation

    A channel. robust tape may also be used. Marvel recommends the use of 4. Upon removal, lay gasket down on a flat surface. bar clamps to secure the panel 5. Partially loosen the 3 screws, securing the top hinge to to the door.
  • Page 15 INTEGRATED PANEL INSTALLATION 12. Using a Phillips screwdriver, place one screw into each of the 6 pilot holes and screw down. Do not overtighten screws. 13. Be sure the screws force their way past the opening on the gasket channel and sit flish against the bottom of the channel.

  • Page 16: Using Your Electronic Control

    USING YOUR ELECTRONIC CONTROL Control Function Guide Function Command Notes ON/OFF Press and release. Unit will immediately turn ON or OFF. Option Open Door Closed Door White White Hold and press and release . Press Adjust Light Color scroll through lighting options. BrightShield®...
  • Page 17 USING YOUR ELECTRONIC CONTROL BrightShield® This model includes BrightShield® with Vyv™ Antimicrobial Light Technology. BrightShield® • Kills* and prevents the growth of viruses, bacteria, fungi, yeasts, mold, and mildew • Provides continuous antimicrobial action to keep surfaces clean • Is approved for continuous use around people, pets, & plants •...

  • Page 18: Water Hookup

    • Water Treatment Options • TDS level of 200 ppm or higher and/or a hardness of 12-19 gpg can be treated by Marvel’s in-line water filter accessories available at marvelrefrigeration.com: • S41016343-ACCY — Standard • S41016345-ACCY — Filter head 3/8”...
  • Page 19 INSTALLING THE WATER SUPPLY Water Hookup Based upon the TDS measurement, see the below table to determine the correct filter required to protect the ice 1. Turn off water supply and disconnect electrical supply machine. to product prior to attempting installation. 2.

  • Page 20: Drain Connection

    2. Connect to your local plumbing per the local code. CAUTION 3. If necessary, insulate drain line to prevent condensation. If your Marvel unit did not come with a factory installed CAUTION drain pump you must use a gravity style drain connection.
  • Page 21 INSTALLING THE DRAIN PLUMBING NOTE The maximum lift for the P60 drain pump is 10 feet. This must be done as close to the rear of the unit as possible.

  • Page 22: Ice Maker Operation

    The factory default ice setting is 0, which produces a firm and compact ice nugget. Marvel’s ice adjustability allows you to choose five levels of density from 0 to -5. At -5 the ice is soft.

  • Page 23: Care And Cleaning

    CARE & CLEANING Cleaning CAUTION Exterior Cleaning Do not use any solvent-based or abrasive cleaners. These types of cleaners may transfer taste and/or odor to the Stainless steel can discolor when exposed to chlorine gas, interior products and damage or discolor the interior. pool chemicals, saltwater or cleaners with bleach.
  • Page 24 Vent Tube • SafeCLEAN Plus™ Cleaner Cleaning Tube 1-8oz. bottle included with unit. and Funnel Need more cleaner? Call Marvel Customer Service at 616.754.5601 Dispenser Tube CAUTION Use only SafeCLEAN Plus™ Cleaner. Use of any other Press and release cleaner may damage the finish of the evaporator and will a.

  • Page 25: Cleaning Condenser

    CARE & CLEANING 7. 06 will appear in the display Cleaning Condenser a. Reinstall shield and close door. b. The machine will circulate water and perform a Interval - Every Six Months series of final rinses for approximately 15 minutes. c.

  • Page 26: Service

    3. After water is drained, reinstall the drain pump and reattach all connections. For questions regarding winterization, please call Marvel at 616-754-5601. CAUTION Damage caused by freezing temperatures is not covered...

  • Page 27: If Service Is Required

    OBTAINING SERVICE If Service is Required: • If the product is within the first year warranty period please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. •...

  • Page 28: Before Calling For Service

    • Compressor: The compressor makes a hum or pulsing- sound that may be heard when it operates. If you think your Marvel product is malfunctioning, read the • Evaporator: Refrigerant flowing through an evaporator- Control Operation section to clearly understand the may sound like boiling liquid.

  • Page 29: Wire Diagram

    WIRE DIAGRAM White light Blue light Cond. Fan Bin temp Low water sensor Auger Water dispenser Water shuto Open Door switch Yellow Blue Pump Resevoir Valve Purple 115 V Black/Yellow Dump Valve 11 22 Orange Water Dispens. Gray Black Open Main Water White Pump...

  • Page 30: Product Liability

    The part that caused the damage must be returned to Marvel in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part.

  • Page 31: Warranty Claims

    Final billing - Remodel • 60 day submittal deadline from date of completed service Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial • Only one repair or unit per warranty claim number, part number and part description.

  • Page 32: Ordering Replacement Parts

    Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information.

  • Page 33: R600A Specifications

    R-600a is heavier than air, do not allow any leakage/migra- tion to low areas such as basements and stairs. Never use a torch on a fully charged refrigeration system. Never substitute Marvel OEM replacement parts or methods of construction. R-600a must be stored and transported in approved...
  • Page 34 R600A SPECIFICATIONS R-600A Specifications/Labeling WARNING R-600a equipped products are labeled (both the unit and the compressor). Only skilled and well trained service technicians R-600a is colorless and odorless. permitted to service R-600a equipped products. R-600a is considered non-toxic, but is flammable when All tools and equipment must be approved for use with mixed with air.

  • Page 35: Leak Detection

    R600A SPECIFICATIONS Evacuate/reclaim via the piecing pliers to ensure the When re-brazing, the system must be purged with system is empty of R-600a before any system work is nitrogen and at least one access point open to the performed. atmosphere. When re-brazing, proper ventilation is required along with constant monitoring for the presence of R600a refrigerant.
  • Page 36 R600A SPECIFICATIONS The low side of the refrigeration system (evaporator, compressor and suction line) must be leak tested with the compressor off (equalized pressure). Recharging No air is ever to be allowed inside the refrigeration system (R-600a refrigerant or dry nitrogen only). Never use a torch on a fully charged refrigeration system.

  • Page 37: System Diagnosis Guide

    SYSTEM DIAGNOSIS GUIDE Refrigeration System Diagnosis Guide System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold...

  • Page 38: Control Operation-Service

    CONTROL OPERATION-SERVICE UI Button Layout Control Function Guide Function Command Display/Options ON/OFF Press Unit will immediately release turn ON or OFF 1. Hidden Button Sabbath Mode See "Sabbath -Access Service Menu Mode" section -No LED directly above. All LEDs turn on with button 2.

  • Page 39: Defrost

    DEFROST Defrost This unit defrosts every 4 hours of compressor runtime for 45 minutes. If you have verified that the unit does not have an ambient air leak, utilize the Control Operation - Service section and adjust unit to defrost every 3 hours for 60 min- utes.

  • Page 40: Convection Cooling

    REMOVE FAN & COVER Convection Cooling This unit is equipped with an advanced convection cooling system. Convection cooling stabilizes cabinet temperature, cools product faster and increases energy efficiency. Evaporator Fan The evaporator fan is responsible for circulating warm air from the refrigeration zone, past the evaporator and back into the refrigerated zone.
  • Page 41 REMOVE FAN & COVER NOTE Fan must be oriented to pull air in through lower evaporator cover vents and push air out at fan mounting location. 13. Installation is the reverse of removal. 14. Care must be taken to assure the bottom of the evaporator cover is reinstalled behind the front edge of the train trough.

  • Page 42: Warranty

    For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
  • Page 43 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
