READ AND SAVE
THESE INSTRUCTIONS
INSTALLATION AND
OPERATION MANUAL
Reverse Osmosis system
ML RO 2000-3000 series.
Humidification and Evaporative Cooling

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML RO 2000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Condair ML RO 2000 Series

Summary of Contents for Condair ML RO 2000 Series

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION AND OPERATION MANUAL Reverse Osmosis system ML RO 2000-3000 series. Humidification and Evaporative Cooling...
  • Page 2 Condair A/S, except to the extent required for installation or maintenance of recipient's equipment. Liability Notice Condair A/S does not accept any liability due to incorrect installation or operation of the equipment or due to the use of parts/components/equipment that are not authorized by Condair A/S.

  • Page 3: Table Of Contents

    Mounting and installation work Safety notes on mounting and installation work Inspection of the delivery Warranty Storage and Transportation Requirements on siting and installation Positioning/mounting the Condair ML RO system components Water connection 4.7.1 Drain 4.7.2 Water connection Breathing filter and level sensor 4.8.1...
  • Page 4 Table of content Operation Prior to initial commissioning Initial commissioning Startup of the controller First startup and flushing (new membrane) Flushing Adjusting the reverse osmosis 6.2.1 Water quality 6.2.2 Adjustment points 6.2.3 Commissioning and adjusting Start-up sequence for daily operation Operation Cabinet overview Equipment protection Alarm and warning messages Controller menu Weekly inspection...

  • Page 5: General Information

    To ensure a safe, proper, and economical operation of the Condair ML RO pure water system, please observe and comply with all information and safety instructions contained in the present documentation...
  • Page 6 If the documentation gets misplaced, please contact your Condair representative. Language versions This manual is available in other languages. Please contact your Condair representative for informa- tion. General information...

  • Page 7: For Your Safety

    For your safety Health and safety Installation, maintenance, repair work or decommissioning should only be carried out by appropriately qualified and properly trained technical personnel. The users are responsible for ensuring their suit- ability. The customer is responsible for ensuring that the installation of the equipment complies with all local regulations.
  • Page 8 • Training and guidance *Condair uses a quick method for measuring bacterial activity in the water: the approved and patented BactiQuant. Once the water sample has been taken, we can read the bacteriological quality of the water within 30 minutes, and disinfect the system if necessary.

  • Page 9: Intended Use

    If used in another way, this will not be considered as intended usage. Condair A/S cannot be made liable for any damage or injury attributable to the inattentive, inappropriate, negligent or incorrect operation of the equipment, whether or not caused deliberately.

  • Page 10: Product Overview

    Product overview Model overview The MLRO 2000 and 3000 RO-system removes (>95%) of salts and minerals from the RAW water. The main system components are fitted on an ‘easy-to-place’ base frame (pump skid), the tank that holds 1000/265 liter/gal are placed the on a separate frame, and are normally placed beside the pump skid. There are two pumps on the pump skid: The RO pump which pumps the raw water through the RO membrane at and into the RO water tank.
  • Page 11 View Front 1. Inlet 1” RG 2. Filter 20", 25 μm 3. Inlet valve 4. Controller cabinet 5. Touch screen for the controller 6. Main switch 7. UV Power supply 8. RO pump outlet pressure gauge 9. RO pump 10. RO pump suction pressure 11.
  • Page 12 View Back 19. Permeate outlet for holding tank 20. Membrane housing 40x8” 21. UV lamp 22. Permeate outlet valve MV7 23. Digital water meter Product overview...

  • Page 13: Functional Description Ml Ro

    Functional description ML RO Osmosis is a natural phenomenon which can be defined as the movement of pure water through a semi permeable membrane from a low to a high concentration solution. The membrane is permeable to water and some ions but rejects almost all ions and dissolved solids. Reverse osmosis is a process which occurs when pressure, greater than the osmotic pressure, is applied to the concentrated solution.

  • Page 14: Mlro 2000 - Piping Diagram

    MLRO 2000 - Piping diagram Product overview...

  • Page 15: Mlro 2000 - Part Specification

    MLRO 2000 - Part specification Product overview...

  • Page 16: Mlro 3000 - Piping Diagram

    MLRO 3000 - Piping diagram Product overview...

  • Page 17: Mlro 3000 - Part Specification

    MLRO 3000 - Part specification Product overview...

  • Page 18: Available Options

    Pre-treatment: Stand-alone systems for improving the water quality in order to meet the inlet water quality requirements for the ML RO, e.g. booster pump, non-return valve, silt/pre-filter, carbon filter and softener. Ask your local Condair dealer for additional information on pre-treatment equipment. Preconditions:...

  • Page 19: System Overview

    System overview 1. Backflow preventer (optional) 2. Carbon filter (optional) 3. Prefilter (optional) 4. Softner 5. MLRO 2000/3000 6. Pressureless tank 1000 L Principal system layout MLRO Figure 1.2 Principal system layout water installation Product overview...

  • Page 20: Mounting And Installation Work

    DANGER! Danger of electric shock The Condair ML RO pure water unit as well as the Condair RS are mains powered. Live parts may be exposed when the units are open. Touching live parts may cause severe injury or danger to life.

  • Page 21: Inspection Of The Delivery

    Check packing slip to ensure all parts has been delivered. All material shortages are to be reported to your Condair supplier within 48 hours after receipt of the goods. Condair Ltd. assumes no responsibility for any material shortages beyond this period.

  • Page 22: Requirements On Siting And Installation

    (fitting) regulations from local utilities. • All Condair RO system components must be installed inside a building in a room which can be locked and which is accessible only to a limited number of people. The room must meet the following requirements: - The room temperature must be between +5 °C and +30 °C throughout the year.

  • Page 23: Positioning/Mounting The Condair Ml Ro System Components

    Position the external pure water tank for the MLRO Place the external pure water tank as near as possible to the Condair ML RO pure water unit on the floor. Turn external pure water tank in such a way that the water connector shows in the desired direction.
  • Page 24 DANGER! Danger of electric hazard! Do not connect Condair ML RO pure water unit to the mains yet. Position the external pure water tank for the MLRO Place the external pure water tank as near as possible to the MLRO on the floor.

  • Page 25: Water Connection

    Water connection 4.7.1 Drain Connect the ML RO to the floor drain with a tube or hose of a 1" RG female. 1" RG female drain connector. Remove protecting plug (yellow) from drain connector connector (let the preservation liquid drain (wind- screen wash).
  • Page 26 Unscrew the filter housing, remove plastic wrapping from the 20” filter elemet and insert it in the filter bowl. Make shure that the filter element is centered and the o-ring is in place, when the filter bowl is screwing back on the filter bowl.

  • Page 27: Breathing Filter And Level Sensor

    Breathing filter and level sensor Connect the permeat outlet to the RO tank, using the 1” steel braided hose supplied Connect the outlet of the RO tank, to the outlet pump using the 1” steel braided hose supplied. Permeate outlet (led to drain for startup flushing) Mounting and installation work...

  • Page 28: Breathing Filter

    4.8.1 Breathing filter Remove the cap from the breathing filter mounting . Remove the plastic wrapper from the breathing filter and moisten the o-rings with tap water. Push in the breathing filter firmly in place. 4.8.2 Level sensor The ultrasonic level sensor on top of the tank needs to be connected.
  • Page 29 Ultrasonic sensor with the M12 plug mounted. Mounting and installation work...

  • Page 30: Installing Membranes

    Installing membranes 4.9.1 Inserting the membranes in the membrane tube Unscrew the steel braided tubes (inlet) on the lefthand side of the RO tube (looking from behind of the RO pump skid). Loosen the clamp holding the endcap, and remove it and the rubber gasket underneath.
  • Page 31 Unpack the RO membrane and insert the RO adapter lubricate with dishwashing soap. The long end goes into the membrane. Mounting and installation work...
  • Page 32 Push in the membrane. Make sure that the flow direction are correct !!! Look for the arrow printed at the membrane, it should go in like shown on the photo. Mounting and installation work...
  • Page 33 Lubricate the RO membrane adaptor with dishwash- ing fluid. Place the RO membrane adaptor (short end) in the endcap. Push the endcap all the way in until the cap between the RO tube and the endcap are closed. it takes a firm push! Now put the gasket, clamp, and hoses back on.

  • Page 34: Electrical Installation

    All cables must be led into the devices, via appropriate cable strain relief or grommets. The cable for the optional leakage sensor can be led into the Condair ML RO pure water unit from the top via a cable grommet or from the bottom via the cable opening (fix cable with a clamp strap to the unit).

  • Page 35: Operation

    Service or trained service personnel authorized by Condair. The system owner must also have been instructed in the operation of the unit by Condair. Once commissioning and training in the operation of the unit is complete, the system owner must ensure that the system is operated only by trained person- nel.
  • Page 36 1.1.1 Pump rotation check Every time the system is powered up, you will see the pump rotation check screen. Verify that the pump rotation is correct. A technician pin will be required; 197 or higher A push on the Test rotation starts the high-pressure pump for 5 seconds, so that the rotation can be ob- served according to the arrows on the pump, always be sure that water is connected to the MLRO before...

  • Page 37: First Startup And Flushing (New Membrane)

    First startup and flushing (new membrane) Flushing New membranes is conserved with a 10% propylene glycol solution and a new MLRO is conserved from the factory with a mild Ethanol solution. Therefor a thorough rinsing is required before the water from the RO system can be used. Make sure the inlet water is connected, opened and the RO outlet are led to draining.
  • Page 38 While the flush sequence, is in progress, vent the RO pump (NB! the RO pump is not running under the flush sequence). Open the small center bleeding screw on the RO pump to fill the pump with water and vent any air. Close the valve again.

  • Page 39: Adjusting The Reverse Osmosis

    Adjusting the reverse osmosis Important! the system needs to be adjusted and continuously monitored, failing to do so will cause membrane failure and a quality drop of the permeate. Explanation of technical terminology Permeate: Processed, desalinated water coming out of the membranes Concentrate: The water led to the outlet.

  • Page 40: Water Quality

    2.5 bar and maximum 6 bar. Permeate/concentrate ratio: MLRO 2000 & 3000 1 °dH Approx. 75/25 Water quality (contact Condair for technical advice) Content Symptom Preventive action TOC, BOC and COD Can cause slimy as well as firm hard Can in some cases be micro-filtrated film.

  • Page 41: Adjustment Points

    6.2.2 Adjustment points Important! Read the entire chapter before starting. Tools needed: Conductivity meter, thermometer FM1; flowmeter m easures v olume r ecirculated over the RO membranes in GPM and l/min V2; Adjusting valve, regulates recirculation flow over membranes pressure over membranes.

  • Page 42: Commissioning And Adjusting

    WM; water meter, shows the total volume of permeate produced and the current flow l/min. The volume of the produced permeate is directly proportional to temperature and pressure on the front side of the membrane. Select the main measurement unit: Quarts (Qts), Pints (Pts), Litres (Lit), Gallons (Gal);...
  • Page 43 8. Adjust V3 until FM2 shows calculated drainage flow. 9. Use the inlet temperature measured earlier and find the rated permeate flow in table fig. 1.3 and 1.4 bellow Rated Permeate flow for MLRO 3000 at a given inlet temperature. °C °F lmin...
  • Page 44 10. Adjust V2 to match rated flow at the given inlet temperature (NB! Minimum recirculating: 80 l/min or 20 GPM) 11. Repeat step 7 and 8 for fine-tuning. 12. Measure the conductivity of the permeate. Is the quality is satisfactory for the application provided by the RO plant ?.

  • Page 45: Start-Up Sequence For Daily Operation

    The following description outlines the start-up procedure after an interruption of operation (e.g. after servicing the MLRO pure water system). It is assumed that first-time commissioning has been carried out properly by Condair Customer Service and the MLRO pure water system has been configured accordingly. DANGER! Systems with damaged components or installations may present danger to human life or cause severe damage to material assets.

  • Page 46: Operation

    All work described in this controller manual may only be carried out by properly trained personnel which is authorised by the customer. If you have questions after reading this documentation, please contact your Condair representative who will be happy to assist you.

  • Page 47: Alarm And Warning Messages

    Master Master (password 8599) as above + selectable options. Condair tech xxxx, as above + factory / service menu. When a password is required in order to change parameters, a screen will appear where the password can be entered. Parameters can be changed using the numerical keyboard (keys 0-9).

  • Page 48: Controller Menu

    Controller menu 1.0 Basic setup The Basic setup page provides access to pages and selectable functions: 1.1 Choice of language 1.2 Calibration of screen (follow the guide on screen) 1.3 Set time and date 1.6 General selections (settings) 1.7 Membrane flush 1.8 Version and change passwords (factory settings) 1.9 ML-System (factory settings) 1.11 Shows add-on boxes attached to the pump...
  • Page 49 1.6 General selections General selection between options and setups for the pump station. Please note that some of the options require hardware that has to be ordered together with the pump. Master pin will be required; 8599 Standard setting is the top choice in the drop-down menus.
  • Page 50 3.9 Pump setup Pressostat del Alarm delay for inlet pressure (PS1) < 1 bar. Default: 10 sec. UV monitoring UV set The pre-set number in the right value must be 50 % lower than the read out number in the left value. Press UV reset to start a new 365 period (after a UV bulbs change) 3.9.2 RoPa Press setup...

  • Page 51: Weekly Inspection

    Note produced permeate volume If the inspection reveals any irregularities (e.g. leakage, error indication) or any damaged components take the ML RO out of operation. Have a qualified specialist or Condair service technician correct the damage or malfunction. Fill in the ‘Service form for weekly monitoring of humidifying systems’ provided in the Appendix of this manual.

  • Page 52: Maintenance

    Maintenance Important notes on maintenance Qualification of personnel All maintenance work must only be carried out by qualified and trained personnel authorized by the owner. Maintenance and repair of the electrical installation of the ML RO must only be carried out by qualified personnel (e.g.

  • Page 53: Desinfection

    Legionella and E.coli. Please read the Maintenance section for more information on disinfection. If you are in any doubt about the suitability of water quality, please contact your Condair distributor who will be happy to support you. Maintenance...

  • Page 54: Maintenance Work

    Maintenance work To ensure safe, hygienic and economic operation of the ML RO, vital components must be checked and maintained periodically according to the table below. The maintenance intervals and maintenance work stated below are guideline values. Local conditions, quality of the water, etc. could influence the maintenance intervals.

  • Page 55: Wear And Spare Parts

    Wear and spare parts Maintenance...

  • Page 56: Weekly Check List

    Weekly check list Maintenance...

  • Page 57: Technical Specifications

    Technical specifications Specifications MLRO 2000 MLRO 3000 Capacity, (Inlet water temp 15°C / 59°F) 2600 l/h / 690 gal/h 3900 l/h / 1030 gal/h Capacity, (Inlet water temp 5°C / 41°F) 2000 l/h / 530 gal/h 3000 l/h / 795 gal/h Permeate quality (μS/cm) 5 <...
  • Page 58 Notes: Technical specifications...

  • Page 59: Warranty

    Warranty Declined – Response with justification will be provided to the customer. 3. In some cases, CONDAIR may request the part to be returned, freight prepaid by the customer, as part of the warranty acceptance or warranty determination process. Some reasons include: Part must be analyzed to determine the root cause of failure.
