Installation Guide
Outdoor Full-Color Bullet Network Camera
*Images may differ from actual products.
EasyCam C320 is used for demonstration in this guide.
©2024 TP-Link 7106511904 REV1.0.0
2. Mount Camera
Option 1
1
A
Φ6 mm
Optional
B
Φ25 mm
Φ3 mm
2
Refer to 3. Waterproof Cable as necessary
3
3. Waterproof Cable (Optional)
1. Get Ready
Option 2
1
A
Φ6 mm
Optional
B
Φ25 mm
Φ3 mm
2
Refer to 3. Waterproof Cable as necessary
3
Usage Tip
Box
RJ45 Network Interface
(supports PoE)
Option 3
1
2
3
Keep the protective film during
installation and remove it before use.
Pole Mounting Accessories
(optional)
Built-in Microphone
Lens
Integrated
Infrared-White LED
Refer to 3. Waterproof Cable as necessary
