Summary of Contents for TP-Link Tapo C320WS2K
- Page 1 User Guide Outdoor Security Wi-Fi Camera Tapo C310/TC65 ©2022 TP-Link 1910013161 REV2.0.1...
-
Page 2: Table Of Contents
Contents About This Guide ··········································································· 1 Introduction ······················································································ 2 Appearance ······················································································ 3 Set Up Your Camera ····································································· 5 Set Up Using Amazon Frustration-Free Setup ·············· 7 Install a microSD Card ······························································ 11 Mount Your Camera··································································· 12 Install Waterproof Items ·························································· 13 Main Camera Controls ·····························································... -
Page 3: About This Guide
Note: More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. • The setup video and waterproof cable attachments video can be found at https://www.tp-link.com/support/setup-video/. -
Page 4: Introduction
Introduction Tapo C310/TC65 is a full-featured weatherproof security camera that you can access from anywhere. Receive instant notifications and check feeds when the motion is detected. Moreover, the automatic siren system will trigger light and sound to frighten away unwanted visitors after the camera detects motion. -
Page 5: Appearance
Appearance Front Panel Bottom Panel MicroSD Card Slot Insert a microSD card for local recording RESET Hold for 5s to reset Wi-Fi or 10s to factory reset camera Speaker IR LED System LED DC Power Connector Used to connect to a 9V DC power adapter Ethernet Port Used to connect to a... - Page 6 Ready for setup (for Wi-Fi setup) Blinking red slowly Connecting to Wi-Fi (for Wi-Fi setup) Connected to Wi-Fi or Solid amber wired network Connected to TP-Link Solid green Cloud server Blinking red quickly Camera resetting Blinking green quickly Camera updating...
-
Page 7: Set Up Your Camera
Set Up Your Camera Follow the steps below to get started with your new camera, or you can follow the setup video at https://www.tp-link.com/support/setup-video/. Step 1. Download Tapo App Step 2. Log In Step 3. Add Your Camera Get the... - Page 8 Step 4. Configure Camera Follow app instructions to set up your camera via wired or wireless connection (for setup only), and add it to your home network. After setup, you can use your camera via wired connection or wirelessly. Note: For Wireless setup, if your camera is connected to your router via an Ethernet cable, please unplug the cable first.
-
Page 9: Set Up Using Amazon Frustration-Free Setup
Set Up Using Amazon Frustration-Free Setup What is Amazon Frustration-Free Setup? Amazon Frustration-Free Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi password on each device. To use this feature, confirm the following: ●... - Page 10 How to use Amazon Frustration-Free Setup with Tapo devices 1. Open the Amazon Alexa app. Then tap More and select Skills & 2. Enter Tapo in the search bar and choose Tapo. Games.
- Page 11 3. Tap the ENABLE TO USE button. 4. Log in with your TP-Link ID that has bound to your Tapo device, and tap Authorize. After authorized successfully, the message Tapo has been successfully linked will come up.
- Page 12 5. Plug in your Tapo device and the setup will complete automatically in two minutes. For setting up more Tapo devices, just plug in and enjoy! Done! If this device displays on the Home page in the Tapo app, it indicates this device has been successfully associated with your Amazon account and joined your Wi-Fi network automatically.
-
Page 13: Install A Microsd Card
Install a microSD Card Follow the steps below to install the microSD card for local recording, or follow the installation video at https://www.tp-link.com/support/setup-video/. You can go to Camera Settings > microSD Card in the Tapo app to check the card status or format your card. -
Page 14: Mount Your Camera
When you finish adding your camera in the Tapo app, you can place your camera on a flat surface, or mount it on a wall or ceiling with the provided mounting template and screws. Follow the steps below to mount your new camera, or follow the setup video at https://www.tp-link.com/support/setup-video/. Step 1. Drill Holes Stick the mounting template to the desired mounting place. -
Page 15: Install Waterproof Items
When the camera is installed outdoors, please install waterproof items to waterproof your camera. Make sure each part is securely attached and the water-proofing rings are flush to keep out water. Follow the steps below to install waterproof items, or follow the installation video at https://www.tp-link.com/support/setup-video/. Install Waterproof Cable Attachments Install the waterproof cable attachments for the network interface when the camera is installed outdoors. -
Page 16: Main Camera Controls
Main Camera Controls After you successfully set up the camera, you will see your camera listed on the home page. You can view and manage your camera from anywhere at any time with the Tapo app. Home Page Live View This page lists all your cameras you've added and you can view them Talk Voice... - Page 17 Camera Settings On this page, you can edit your account, quickly check the memorable Live View page, tap to enter the Camera Settings page. You can moments you saved, or find the FAQs of using smart camera and basic change the settings of your camera to meet various needs, such as info related to the Tapo app.
-
Page 18: Camera Detection & Alerts
Camera Detection & Alerts Receive notifications and check feeds when the camera detects a motion, or when someone crosses a boundary, enters an area you've set, or obstructs the camera. Insert a microSD card to record the clips when activity detected. Otherwise, you can only receive the notifications. Note: Initialize the SD card on the Tapo app before using it. - Page 19 Line-Crossing Detection Area Intrusion Detection Add one or more lines that should not be crossed, then if the set line is Add one or more activity zones, then when the camera detects someone crossed, the camera will send you notifications or even sound an alarm. enters the set zones, the camera will send you notifications or even You can also set the crossing direction and detection schedule.
- Page 20 Camera Tampering Detection Step 2: Turn On Activity Notifications When the camera view is blocked, it will send you notifications or even Turn on Activity Notifications to get instant alerts when your camera sound an alarm. You can adjust the detection sensitivity. Increased detects activities.
- Page 21 Step 3: Customize Alarm Settings Step 4: Set Recording Schedule Customize Camera Alarm settings to trigger a light/sound alarm to After editing the detection settings for the camera, you can set the frighten away unwanted visitors when your camera detects activities. You Recording Schedule for Detection Recording.
- Page 22 Step 5: Check Recordings On the Live View page, tap to find all recordings. Tap the colored sections or the video clips below to check the activity detected. Note: The microSD card is needed for recordings. Initialize the SD card on the app before using it.
-
Page 23: 24-Hour Recordings
24-hour Recordings The microSD card is needed for 24-hour recording and it’s suggested to initialize the SD card on the app before using it. 2. Toggle on to enable the microSD Recording function and set the 1. On the Live View page, tap to enter the Camera Settings... - Page 24 3. On the Live View page, tap to find all recordings. Tap the colored sections or the video clips below to check the activity detected. Note: The microSD card is needed for recordings. Initialize the SD card on the app before using it.
-
Page 25: Privacy Mode
Privacy Mode On the Live View page, tap to enable the Privacy Mode. When enabled, streaming and recording functions will be temporarily disabled to protect your privacy. You can tap Disable Privacy Mode to exit Privacy Mode and the camera will be back to work. -
Page 26: How To Reset Your Camera
How to Reset Your Camera Follow the steps below to reset your camera via the Reset button, or follow the installation video at https://www.tp-link.com/support/setup-video/. You can also go to Camera Settings in the Tapo app and tap Remove Device at the bottom to factory reset your camera. -
Page 27: Authentication
Product Name: Outdoor Security Wi-Fi Camera Model Number: Tapo C310/TC65 Component Name Model AC ADAPTER T090060-2B1 Responsible Party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: sales.usa@tp-link.com This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 28 We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
- Page 29 We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
- Page 30 UKCA Mark UK Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tapo.com/support/ukca/.
- Page 31 Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
- Page 32 低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 安全諮詢及注意事項 • 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 • 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 • 注意防潮，請勿將水或其他液體潑灑到本產品上。 • 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 • 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 • 請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此項工作。 限用物質含有情況標示聲明書 設備名稱：Outdoor Security Wi-Fi Camera 型號（型式）：Tapo C310/TC65 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 多溴二苯醚 鉛 汞 鎘 六價鉻 多溴聯苯 Unit Polybrominated diphenyl ethers Lead...
- Page 33 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值 Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition. 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.
- Page 34 Storage Temperature: -40ºC~70ºC (-40°F ~ 158°F ) Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk. Explanation of the symbols on the product label Symbol Explanation...
