KIT TERMOSTATO DI SICUREZZA
BASSA TEMPERATURA
Cod. 3.013794
IL PRESENTE FOGLIO È DA LASCIARE ALL'UTENTE
ABBINATO AL LIBRETTO ISTRUZIONI DELL'APPARECCHIO
AVVERTENZE GENERALI.
Tutti i prodotti sono protetti con idoneo imballaggio da trasporto.
Il materiale deve essere immagazzinato in ambienti asciutti ed
al riparo dalle intemperie. Il presente foglio istruzioni contiene
informazioni tecniche relative all'installazione del kit. Per quanto
concerne le altre tematiche correlate all'installazione del kit stesso
(a titolo esemplificativo: sicurezza sui luoghi di lavoro, salvaguardia
dell' a mbiente, prevenzioni degli infortuni), è necessario rispettare i
dettami della normativa vigente ed i principi della buona tecnica.
L'installazione o il montaggio improprio dell' a pparecchio e/o dei
componenti, accessori, kit e dispositivi potrebbe dare luogo a proble-
matiche non prevedibili a priori nei confronti di persone, animali,
cose. Leggere attentamente le istruzioni a corredo del prodotto per
una corretta installazione dello stesso. L'installazione e la manu-
tenzione devono essere effettuate in ottemperanza alle normative
vigenti, secondo le istruzioni del costruttore e da parte di personale
abilitato nonché professionalmente qualificato, intendendo per tale
quello avente specifica competenza tecnica nel settore degli impianti,
come previsto dalla Legge.
ELENCO APPARECCHI ABBINABILI.
• Hercules Mini Condensing 32 ErP
• Hercules 26 Condensing ErP
• Hercules 32 Condensing ErP
• Hercules 32 ABT Condensing ErP
• Hercules Solar 200 Condensing ErP
• Hercules 25
• Hercules 35
• Hercules 35 ABT
• Hercules Mini 35
• Hercules Solar 25
• Gaudium Solar V2 - 2 zone
• Gaudium Solar Plus V2 - 2 zone
• DIM
V2
• Kit 2 zone miscelate, kit 2 zone miscelate e 1 diretta
DESCRIZIONE.
Con il generatore funzionante in Bassa Temperatura diretta
(nessun controllo a valle della caldaia e nessuna miscelazione
sul DIM
), occorre inserire una sicurezza che eviti, in caso di
V2
anomalia del generatore, il superamento della temperatura limite
di 55 °C che potrebbe determinare inconvenienti all'impianto di
Bassa Temperatura.
Se il fenomeno si verifica frequentemente occorre chiamare un
tecnico abilitato (ad esempio il servizio Assistenza Immergas).
Cod. 1.050922 - rev. ST.008965/000 - 01/25
THIS SHEET MUST BE LEFT WITH THE USER ALONG WITH
IT
THE APPLIANCE INSTRUCTION BOOKLET
GENERAL WARNINGS.
All products are protected with suitable transport packaging.
The material must be stored in dry environments and protected
against weathering. This instruction manual provides technical
information for installing the kit. As for the other issues related to
kit installation (e.g. safety in the work site, environment protection,
injury prevention), it is necessary to comply with the provisions
specified in the regulations in force and principles of good practice.
Improper installation or assembly of the appliance and/or compo-
nents, accessories, kit and devices can cause unexpected problems
to people, animals and objects. Read the instructions provided
with the product carefully to ensure a proper installation. Installa-
tion and maintenance must be performed in compliance with the
regulations in force, according to the manufacturer's instructions
and by authorised professionally qualified staff, intending staff with
specific technical skills in the plant sector, as envisioned by the Law.
LIST OF COMPATIBLE APPLIANCES.
• Hercules Mini Condensing 32 ErP
• Hercules 26 Condensing ErP
• Hercules 32 Condensing ErP
• Hercules 32 ABT Condensing ErP
• Hercules Solar 200 Condensing ErP
• Hercules 25
• Hercules 35
• Hercules 35 ABT
• Hercules Mini 35
• Hercules Solar 25
• Gaudium Solar V2 - 2 zones
• Gaudium Solar Plus V2 - 2 zones
• DIM
• 2 mixed zones kit, 2 mixed zones and 1 direct zone kit
DESCRIPTION.
With the generator operating at direct Low Temperature (no
control downstream of the boiler and no mixing on DIM
safety device must be inserted which, in case of generator failure,
prevents the limit temperature of 55°C from being exceeded which
could cause problems to the Low Temperature system.
If this issue occurs frequently, you must contact a qualified techni-
cian for assistance (e.g. Immergas After-Sales Assistance Service).
Cod. 3.013794 - 1.050922 - ST.008965/000 - 01/25
LOW TEMPERATURE SAFETY
THERMOSTAT KIT
Cod. 3.013794
V2
IE
), a
V2
1
