INSTALLATION INSTRUCTIONS
73050T-7
Single Handle Lavatory Faucet - Side Handle
73159T-7
Tall Single Handle Lavatory Faucet - Side Handle
73054T-7
Super Tall Single Handle Lavatory Faucet - Side Handle
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. If possible, install this faucet before installing the lavatory.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
Lift the handle gently. Turn clockwise for cold water, turn counter-colckwise for hot water.
ROUGH-IN DIMENSIONS
73
43
Ø35
Ø51
Ø32~Ø38
G1/2˝
1249825-2A-A
COMPOSED
Ø58
Ø36.5
135
2°
176.5
151
Ø31.75
Ø68
27
Ø43
Ø38
73050T-7
1
