IN THE BOX

Active Imaging HD (Thru-Hull, Single)

A
B
C
D
E
F
A
2x M10 nut
B
1x M10 nylon washer
C
1x small isolation sleeve
D
1x fairing block
E
1x anti-rotation stud
F
1x transducer with 1.83 m (6 ft) cable
attached
*Used to mount the fairing block to timber temporarily for cutting.
G
H
I
J
K
G
1x stem nut
H
1x set screw for stem nut
I
1x M30 nylon washer
J
1x large isolation sleeve
K
2x self-tapping screws*
