ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A
Enhanced
INSTALLATION & USE MANUAL
LZ
Series Bottle Filling Stations & Coolers
™
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
Page 1
2000002197 (Rev. B - 02/25)
Advertisement
Table of Contents
Related Manuals for Elkay ENLZS8WSAP 1A Series
Summary of Contents for Elkay ENLZS8WSAP 1A Series
- Page 1 Enhanced INSTALLATION & USE MANUAL Series Bottle Filling Stations & Coolers ™ Patent zurn-elkay.com/patents WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov Page 1...
- Page 2 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A Fig. 1 2000002197 (Rev. B - 02/25) Page 2...
- Page 3 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A INSTRUCTIONS FOR REMOVING WRAPPER Fig. B(ii) Fig. B(i) 1) Remove the two security screws (size T25) from the front panel. (see Fig B(i)) NOTE: SCREW THREADS INTO BUSHING WHILE ANGLED. DO NOT ATTEMPT TO THREAD SCREW INTO BUSHING HORIZONTALLY. 2) Gently pull the wrapper down and rotate the wrapper to a downward position (see Fig B(ii)).
-
Page 4: Bottle Filler Installation
7) Connect electrical power by plugging in unit’s power cord. 8) Turn on water supply and flush filter to purge air and fine carbon particles from filter before use. Visit elkay.com/filtration for additional details. Also run water through bottle filler until all air is removed and water flow is clear. - Page 5 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A FIG. 2 FIG. 3 Secure cooler frame to wall by installing (2) screws and washers (not supplied). Fig. 4 Lay gasket along back of bottle filler mounting plate. Align BF and lay on cooler basin. Fig.
-
Page 6: Wall Mounting Plate
ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A Fig. 6 Fig. 7 Connect the bottle filler electrical harness. (Gasket removed from bottle filler for clarity) MOUNTING BOLT HOLES (6) WALL MOUNTING PLATE Fig. 8 BOTTLE FILLING UNIT 2000002197 (Rev. B - 02/25) Page 6... - Page 7 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A 115V Refrigerated Wiring Diagram with Alpha/Numeric Display LZS8WSAP LZS8WSAP-PF LZS8WSMP LZS8WSMP-PF LZS8WSSP-PF Fig. 9 WARNING • INGESTION HAZARD: This product contains a button cell or coin battery. • DEATH or serious injury can occur if ingested. •...
- Page 8 3/8” Water Inlet 1 or 2 or 3 Scan for trouble shooting and to sign up for auto replen- ishment of authentic Elkay filters. Fig. 14 WATERSENTRY Filter Detail ® WATERSENTRY FILTER PARTS LIST ®...
- Page 9 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, Remove two (2) screws from front of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube.
- Page 10 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A 2000002197 (Rev. B - 02/25) Page 10...
-
Page 11: Error Description
ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A Enhanced EZH2O Error Codes Error Error Description Corrective Action Code Bottle filler area obstructed • Remove obstruction. • Clean lens on IR sensor • Unplug unit for at least 30 seconds and restart • If error repeats, replace IR sensor E013 Missing or Incompatible Filter •... -
Page 12: Filter Location
ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A Pictured is unit only without bottle filler. Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Uses HFC-134A refrigerant Filter Location See Fig. 12 12 or 13 See Fig. 15 21, 24 Fig. 16 2000002197 (Rev. - Page 13 Kit - Hardware & Waterway (BF) 1000004573 Kit - Solenoid 120V (BF) 1000004573 Kit - Solenoid 120V (BF) 2000002090 Nameplate - Elkay Filtered (AW) 2000002089 Nameplate - Elkay Filtered (MB) 2000002072 Kit - Top Cover Assy (BF) (AW) 2000002071 Kit - Top Cover Assy (BF) (MB)
- Page 14 ENLZS8WSAP_1A, ENLZS8WSAP-PF_1A, ENLZS8WSMP_1A, ENLZS8WSMP-PF_1A, ENLZS8WSSP-PF_1A ATTENTION: If the product serial number is before 190424189, please refer to archived documents section of Elkay.com for the most accurate parts list. (www.elkay.com/archived-documents) 115V PARTS LIST FOR LZS8WSSP-PF BOTTLE FILLER REPLACEMENT PART KITS PART...
