  • Page 1 Installation Manual UbiquiSTAT Commercial BACnet Controller 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com 202501...
  • Page 2: Table Of Contents

    Touch Screen Interface.........................8 Model Number Definitions – A Key to Understanding UbiquiSTAT Series Model Versions TCS offers 16 different UbiquiSTAT versions based on four models: the US4010, US4020, US4040, and US4050 (refer to UbiquiSTAT Product Data sheet for more information on the specific features of each model).
  • Page 3: Introduction

    BACnet Explorer to edit the device's BACnet programming objects directly. If you have any questions regarding your UbiquiSTAT room controller, do not hesitate to contact TCS Technical Support at 800-288-9383, ext. 2. Our Technical Support Department hours are Monday – Friday, 7:00 a.m. to 7:00 p.m. (CST).
  • Page 4: Ubiquistat Wiring Connections

    Installation UbiquiSTAT Wiring Connections The input/output terminals on the UbiquiSTAT utilize de-pluggable terminal blocks, with either two or three poles. Refer to the color-coded diagram below, which indicates which terminations are active on the various models. Packaged Unit Time Clock Analog Terminations Output...
  • Page 5: Power

    Connect the power source using 18AWG two-wire twisted, stranded copper wire. NOTE: Do not connect to 120VAC. When multiple TCS/Basys Controls devices are using a single transformer, be sure to maintain the polarity of the power wiring. All TCS devices are half-wave rectified and have common return paths.
  • Page 6: Packaged Unit Terminations

    Installation Packaged Unit Terminations Packaged unit signals may be up to 28VAC from the equipment terminations. W1 W2 AO1 AO2 GND – DI3 GND +P AI1 AI2 GND W1 W2 W1 W2 4X2X 4X4X 4X5X 4X1X Time Clock Output The Time Clock Output is an unpowered, isolated pair of relay contacts. Connect an external device that operates with a schedule based on room occupancy, such as an outdoor air damper, exhaust fan, or a dehumidification/reheat unit.
  • Page 7: Digital Inputs

    Installation Digital Inputs Digital inputs are used to receive status signals such as filter status, fan status, etc. Use unpowered dry contacts only with 18AWG two-wire twisted, stranded shielded or unshielded wire. DI1 DI2 DI3 GND W1 W2 AO1 AO2 GND –...
  • Page 8: Assembling The Ubiquistat

    Installation Assembling the UbiquiSTAT Before assembly, check that no wiring interferes with the cover, and no bare wires are exposed. Follow the instructions below. You can also refer to a video illustrating the assembly process by clicking here. STEP 1 Match the orientation of the internal connectors.
