U-Line H-2275 Quick Start Manual

U-Line H-2275 Quick Start Manual

Brushed steel folded towel dispenser
Hide thumbs
1
2
3
4
5
6

Advertisement

Available languages

Available languages

Table of Contents

H-2275
BRUSHED STEEL FOLDED
TOWEL DISPENSER
TOOLS NEEDED
Drill
1/4" Drill Bit
Dispenser x 1
NOTE: Recommended mounting height is 50"
from the floor to bottom of dispenser.
NOTE: Ensure that proper mounting hardware
is used for appropriate wall composition as
enclosed hardware may not be compatible
with your wall surface.
1.
Insert the key into the lock opening on the top of
dispenser and turn to open cover. (See Figure 1)
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
Phillips Screwdriver
Level
Key x 1
MOUNTING INSTRUCTIONS
Side Lens
Tape Measure
PARTS
Wall Anchor x 4
2. Open dispenser cover and hold dispenser to ideal
mounting place on wall. (See Figure 2)
Figure 2
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Screw x 4
0821 IH-2275

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-2275 and is the answer not in the manual?

Questions and answers

Related Manuals for U-Line H-2275

Summary of Contents for U-Line H-2275

  • Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-2275 1-800-295-5510 uline.com BRUSHED STEEL FOLDED TOWEL DISPENSER TOOLS NEEDED Drill 1/4" Drill Bit Phillips Screwdriver Level Tape Measure PARTS Dispenser x 1 Key x 1 Wall Anchor x 4...

  • Page 2: Loading Instructions

    MOUNTING INSTRUCTIONS CONTINUED 3. Mark the four holes on the wall where screws will be 4. Drill into wall at four marked locations with 1/4" drill inserted. (See Figure 3) bit. (See Figure 4) Insert wall anchors if necessary. Figure 3 Figure 4 5.

  • Page 3: Herramientas Necesarias

    H-2275 800-295-5510 uline.mx DESPACHADOR DE ACERO CEPILLADO PARA TOALLAS DOBLADAS HERRAMIENTAS NECESARIAS Taladro 1/4" Broca Desarmador Nivel Cinta de Cruz de Medir PARTES 1 Despachador 1 Llave 4 Taquetes 4 Tornillos INSTRUCCIONES DE INSTALACIÓN 2. Abra la cubierta del despachador y sostenga el NOTA: La altura de instalación recomendada...

  • Page 4: Instrucciones De Carga

    CONTINUACIÓN DE INSTRUCCIONES DE INSTALACIÓN 3. Marque los cuatro orificios en la pared donde se 4. Taladre la pared con la broca de 1/4" en las cuatro instalarán los tornillos. (Vea Diagrama 3) ubicaciones marcadas. (Vea Diagrama 4) Si es necesario, inserte taquetes.

  • Page 5: Outils Requis

    H-2275 1-800-295-5510 uline.ca DISTRIBUTEUR DE SERVIETTES PLIÉES EN ACIER BROSSÉ OUTILS REQUIS Perceuse 1/4" Mèche Tournevis Niveau à Ruban à de perceuse cruciforme bulles mesurer PIÈCES Distributeur x 1 Clé x 1 Ancrage mural x 4 Vis x 4 INSTRUCTIONS DE MONTAGE 2.
  • Page 6 INSTRUCTIONS DE MONTAGE SUITE 3. Marquez les quatre trous sur le mur où les vis seront 4. Percez le mur aux quatre endroits marqués avec insérées. (Voir Figure 3) une mèche de forage de 1/4 po. (Voir Figure 4) Insérez les dispositifs d'ancrage au besoin. Figure 3 Figure 4 5.
