Current NXP2 Series Installation Instructions Manual

Lighting control panel

Advertisement

INSTALLATION OVERVIEW
The installation instructions contained in this document are provided as a guide for proper and reliable installation. The mounting
location should be selected and prepared based on the application. All electrical wiring and mounting hardware (i.e. electrical
mounting box, conduit, etc.) should be prepared with consideration of the requirements outlined in the wiring and mounting
diagrams included in this document.
These instructions include information as follows:
Precautions
Description
Product Configurations
Enclosure Mounting
Installing Individual Relays
Connecting Panel Power
Connecting Lighting Loads
Using the NX Panel for Control of Emergency Lighting
Connecting NX Devices
Connecting Low Voltage Inputs & Dry Contact Outputs
Connecting to Panel Using NX Lighting Controls mobile app and NX Bluetooth® Radio Bridge with Real Time Clock
Connecting Panel to NX Lighting Controls Network
Troubleshooting
Panel Specifications
Panel Load Schedule Form
Wiring Diagrams
PRECAUTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
CAUTION - RISK OF ELECTRICAL SHOCK. To prevent electrical shock, turn off power at the circuit breaker before installing
or servicing unit. Never wire energized electrical components.
NOTICE: For installation by a licensed electrician in accordance with national and/or local Electrical Codes and the
following instructions.
CAUTION: USE COPPER CONDUCTOR ONLY.
CAUTION: This equipment provides more than one power supply output source. To reduce the risk of electric shock
disconnect both normal and emergency sources within this unit before servicing any equipment connected to this unit.
Be sure to read and understand all instructions before installing or servicing unit.
For Indoor use only. Do not use outdoors.
Do not mount near gas or electric heaters.
Disconnect switch or a circuit breaker must be provided and marked as the disconnecting device.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
Confirm that device ratings are suitable for application prior to installation.
No user serviceable parts contained inside unit. Refer all service-related questions to the factory.
currentlighting.com/nx-lighting-controls
© 2024 HLI Solutions, Inc. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
NX Lighting Control Panel (NXP2 Series)
INSTALLATION INSTRUCTIONS
Download the NX Lighting Controls mobile app
72-00668G
Page 1 of 10
Rev 03/20/24
3482B_NXP_Install_R03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NXP2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Current NXP2 Series

  • Page 1 NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS Download the NX Lighting Controls mobile app INSTALLATION OVERVIEW The installation instructions contained in this document are provided as a guide for proper and reliable installation. The mounting location should be selected and prepared based on the application. All electrical wiring and mounting hardware (i.e. electrical mounting box, conduit, etc.) should be prepared with consideration of the requirements outlined in the wiring and mounting...
  • Page 2 NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS • All servicing shall be performed by qualified service personnel. • Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel.
  • Page 3 NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS DESCRIPTION The NX Panel is a configurable lighting control panel consisting of single and/or double pole relays, 0-10V dimming channels, low voltage inputs, dry contact outputs, NX SmartPORTs™ for NX Occupancy Sensors, Daylight Sensors and Smart Wall Stations, and an optional UL924 Emergency Interface .
  • Page 4: Enclosure Mounting

    NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS ENCLOSURE MOUNTING The NX Panel is typically installed near the circuit breaker panel. Select an appropriate location that meets the environmental conditions listed in the specification section of this document. The panel interior is divided into high voltage and low voltage areas as shown in Figure 1 below.
  • Page 5 NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS Blue Input Screw Blue Lead Single Pole Relay Relay Connector Load (to lighting system) Line I/O control (from Circuit Breaker) Card Header (Polarized) Red Lead Red Input Screw Blue Input Screw Blue Lead...
  • Page 6 NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS USING THE NX PANEL FOR CONTROL OF EMERGENCY LIGHTING The NX Panel's optional UL924 support comes pre-installed at the factory. When installed, the NX Panel is suitable for control of emergency lighting circuits. Upon loss of normal power, all relays will automatically go to the closed (ON) position and all dimming channels will go to 100% light output.
  • Page 7: Troubleshooting

    NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS CONNECTING TO PANEL USING NX LIGHTING CONTROLS MOBILE APP AND NX BLUETOOTH® RADIO BRIDGE WITH REAL TIME CLOCK The NX Panel is designed to operate as a standalone panel that can be programmed using a NX Bluetooth Radio Bridge with Real Time Clock and the NX Lighting Controls mobile app available in Android™...
  • Page 8: Operation

    NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS • NX Networked Ethernet Ports (Continued): • Speed LED (Yellow) • Off = 10Mbit connection • On = 100Mbit connection • Low Voltage Input LEDs (Red) • Closed = On • Open = Off •...
  • Page 9: Operating Environment

    NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS PANEL SPECIFICATIONS (CONTINUED) OPERATION (CONTINUED) CERTIFICATIONS WARRANTY • Programmable via web-browser • UL 916, CAN/CSA C22.2 No. 205 • 5 year limited warranty user interface** • UL 924, CAN/CSA C22.2 No. 141...
  • Page 10: Battery Statement

    NX Lighting Control Panel (NXP2 Series) INSTALLATION INSTRUCTIONS NX NETWORKED NX NETWORKED NX NETWORKED Networked Panel Programmed Using the NX Area Controller BATTERY STATEMENT Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate.
