Sealey BJ10LE.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
The user shall work only in accordance with this instruction manual.
9
The operator shall be provided with all necessary information about training and about pumping and translating forces.
9
Ensure the jack is in sound condition and good working order. Take action for immediate repair or replacement of damaged parts. Use
9
genuine parts only. DO NOT modify the jack. The use of non-genuine parts may be dangerous and will invalidate the warranty.
Locate the jack in a suitable, well lit working area.
9
Keep working area clean and tidy and free from unrelated materials. Use jack on level and solid ground, preferably concrete. Avoid
9
tarmacadam as jack may sink in.
Chock wheels of vehicle.
9
Ensure the vehicle handbrake is engaged, engine is switched off and transmission is in gear (or "PARK" if automatic).
9
Ensure minimum distance of 0.5m between vehicle and static objects such as doors, walls, etc. to allow for vehicle tilting.
9
Ensure all non-essential persons keep a safe distance whilst the jack is in use.
9
Ensure there are no passengers in the vehicle.
9
It is necessary that the operator can watch the lifting device and the load during all movements.
9
Place jack under only those lifting points recommended by vehicle manufacturer (see vehicle handbook).
9
Check that the lifting point is stable and centred on the jack saddle.
9
▲ DANGER: Use the jack for lifting only, NOT for supporting the lifted load.
Ensure there are no persons or obstructions beneath the vehicle before lowering.
9
It is not allowed to work under the raised load until it is secured by suitable means. Use suitable axle stands under the vehicle before
9
proceeding with any task.
Use a qualified person to lubricate and maintain the jack.
9
Ensure that only hydraulic jack oil is used in the jack.
9
DO NOT operate the jack if damaged.
8
DO NOT allow untrained persons to operate the jack.
8
DO NOT operate the jack when tired or under the influence of drugs, alcohol or intoxicating medication.
8
DO NOT exceed the rated capacity of the jack.
8
DO NOT allow the vehicle to move during lifting or lowering, or use the jack to move the vehicle.
8
DO NOT jack vehicle if there is a risk of spillage of fuel, battery acid, or other dangerous substances.
8
DO NOT work under the vehicle until appropriately rated axle
8
stands have been correctly positioned.
DO NOT use the jack for purposes other than that for which it is
8
intended.
DO NOT top up hydraulic system with brake fluid. Use hydraulic
8
jack oil only. (Sealey Part No: HJO500MLS or HJO5LS)
DO NOT adjust the safety overload valve.
8
When not in use store jack, fully lowered, in a safe, dry, childproof
9
area.
If more than 400N of effort is generated in lifting, the efforts shall
9
be lowered by an additional person.
2. INTRODUCTION
Fitted with overload valve. Base and reservoir machine welded
for increased strength and reduced chance of leakage. Threaded
pump assembly allows for easy disassembly and maintenance.
Supplied with 4-piece operating handle. Fitted with carrying handle.
Service kit readily available.
IMPORTANT SAFETY WARNING: ALWAYS USE AXLE STANDS
Please remember a jack is a lifting device and is not designed to
support a load. Never get underneath a vehicle supported only by a
jack - your life is at risk. We stock a comprehensive range of axle stands - please see relative section for full details.
© Jack Sealey Limited
10 TONNE TELESCOPIC LOW PROFILE BOTTLE
JACK
BJ10LE.V2
MODEL NO:
fig.1
Original Language Version BJ10LE.V2 Issue 1 31/07/23
