CF-53MAW03ZZ
Model No.
© Panasonic Corporation 2012.
Unauthorized copying and distribution is a violation of law.
ORDER NO.
Notebook Computer
This is the Service Manual for
Global Customer configuration base model.
CPD1209217AE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUGHBOOK CF-53MAW03ZZ and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic TOUGHBOOK CF-53MAW03ZZ

Summary of Contents for Panasonic TOUGHBOOK CF-53MAW03ZZ

  • Page 1 ORDER NO. CPD1209217AE Notebook Computer CF-53MAW03ZZ Model No. This is the Service Manual for Global Customer configuration base model. © Panasonic Corporation 2012. Unauthorized copying and distribution is a violation of law.

  • Page 2: How To Replace The Fuse

    If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.

  • Page 3: Laser Safety Information

    LASER SAFETY INFORMATION Class 1 LASER Product PRODUCT COMPLIES WITH DHHD RULES 21 CFR CHAPTER 1,SUBCHAPTER J. 130KS This equipment is classified as a class 1 level LASER product and there is no hazardous LASER radiation. Caution (1) Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous exposure.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS 1. Before servicing, unplug the power cord to prevent an electric shock. 2. When replacing parts, use only manufacture's recommended components for safety. 3. Check the condition of the power cord. Replace if wear or damage is evident. 4.
  • Page 5 Use of battery packs other than those manufactured and use the computer within the allowable temperature range. supplied by Panasonic may present a safety hazard (generation This computer has a high temperature mode function that of heat, ignition or rupture).
  • Page 6 CF-AA5713A POUR UTILISER AVEC MODELE Use Only the Specified AC Adaptor With This Product Using an AC adaptor other than the one supplied (attached to your product or supplied by Panasonic) may result in a fire. Model No: CF-AA5713A 6/11...

  • Page 7: Exploded View

    Exploded View LCD Unit K108 K101 K100 K102 Screw tightening torque 0.2 ± 0.02 N . m 1.5 ± 0.02 N . m 1.5 ± 0.02 N . m K105 (2.0 ± 0.2 kgf . cm) (15.0 ± 0.2 kgf . cm) (15.0 ±...
  • Page 8 E1-8 E1-5 E1-7 E1-6 E1-2 E1-3 E1-1 E1-14 E1-4 K152 E1-12 E1-13 E1-10 E1-15 K151 E1-9 K130 E1-16 E1-16 Screw tightening torque 0.2 ± 0.02 N . m (2.0 ± 0.2 kgf . cm) 0.45 ± 0.02 N . m (4.5 ±...
  • Page 9 K109 K156 K117 K106 K64-1 K64-2 K64-3 K64-5 K64-4 K64-6 Screw tightening torque 0.2 ± 0.02 N . m 0.25 ± 0.02 N . m K64-7 (2.0 ± 0.2 kgf . cm) (2.5 ± 0.2 kgf . cm) 0.45 ± 0.02 N . m (4.5 ±...
  • Page 10 Screw tightening torque 0.2 ± 0.02 N . m 0.7 ± 0.05 N . m (2.0 ± 0.2 kgf . cm) (7.0 ± 0.5 kgf . cm) 0.8 ± 0.05 N . m 0.25 ± 0.02 N . m (8.0 ± 0.5 kgf . cm) (2.5 ±...
  • Page 11 S DFQW5645ZAT *OPERATING INSTRUCTION MANUAL 1->0 Note: About the parts which written " * " above, please order to Computer Products Europe (CPE) written below. Panasonic Manufacturing (U.K.) Ltd. Computer Products Europe (CPE) TEL: +44-(0)29-20736170 FAX: +44-(0)29-20736250 Mechanical Parts DFHR3S36YA ------ KB SPACER 1->0...
