Summary of Contents for TECO TVF162WMPCM
- Page 1 VERTICAL FREEZER User Manual TVF162WMPCM Freezer...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions Installation Instructions Reversing the Door Structure and Functions Packing List Operating Instructions Maintenance and Care of the Appliance Troubleshooting Repairs, Service & Warranty Specifications... -
Page 3: Important Safety Instructions
• Follow the operating instructions and safety notices in this manual. • If any trouble arise, do not attempt to fix it yourself. Please contact TECO service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST). - Page 4 • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. • If the supply cord is damaged, it must be replaced by authorised TECO service personal, service agent or similarly qualified persons in order to avoid a hazard.
- Page 5 • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: Installation Instructions
Installation Instructions • Before using the refrigerator for the first time, remove all of the packing materials, including the foam base and adhesive tape holding accessories in place; tear off the protective film on th e doors and the refrigerator body. •... -
Page 7: Reversing The Door
Reversing the Door To reverse the freezer door, ensure you have a phillips head screwdriver, a flat blade screwdriver and an allen key that suit the screws required to swap the hinge. Unplug the freezer and empty all contents before proceeding. Precautions before installation: Before installation or adjusting of accessories, it shall be ensured that the refrigerator is disconnected from power. - Page 8 Step 6. Carefully tilt the freezer Fig. 4 back to access the bottom hinge assembly. NOTE: Do not tilt >45 ° . Using a phillips head screwdriver, remove the screws holding the hinge in Adjustable Bottom place. Unscrew the adjustable foot hinge foot from the opposite side.
-
Page 9: Structure And Functions
(The pictures above are only for reference only. The actual configuration depends on the physical product). Packing List • Check the packing list that all items have been included. Part No. Model TVF162WMPCM Freezer Drawer 3 pieces Freezer Compartment 2 pieces Cover... -
Page 10: Operating Instructions
Operating Instructions Temperature control knob The temperature of the freezer can be controlled manually by adjusting the thermostat dial. Observe the markings when selecting a temperature. MIN represents the minimum (warmest) temperature, MID represents a medium temperature and MAX represents the maximum (coldest) setting. The default setting is MID for normal operating conditions. -
Page 11: Maintenance And Care Of The Appliance
Maintenance and Care of the Appliance Please unplug the freezer for defrost and cleaning. • Dusts behind the freezer and on the ground shall be timely cleaned to improve the cooling effect and energy saving. • Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent. -
Page 12: Troubleshooting
Troubleshooting Check whether the appliance is connected to power or whether the plug is in well contact . Failed operation Check whether the voltage is too low. Check whether there is a power failure or partial circuits have tripped. Odorous foods shall be tightly wrapped. Check whether Odor there is any rotten food. -
Page 13: Repairs, Service & Warranty
IF SERVICE IS REQUIRED : If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST). For warranty details please visit www.teco.com.au Service Email : had.service@teco.com.au... -
Page 14: Specifications
TVF162WMPCM 220 ~ 240 0.68 Noise Level (dB) R600a 1420... - Page 15 Did you know? TECO Australia's product range also includes: Top Load Clothes Washers Front Load Clothes Washers Auto Sensing Vented Clothes Dryers Heat Pump Clothes Dryer Refrigerators Chest and Vertical Freezers Bar Fridges Televisions Air Curtains Air Conditioners Visit www.teco.com.au for our full range.
-
Page 16: Warranty Information
Teco's warranty information for the product purchased is available at www.teco.com.au. A copy of the warranty may also be obtained by contacting Teco's Warranty and Service Department on 1300 660 037 during business hours (Mon - Fri 8.30am - 4pm AEST).
