- Page 1 172L VERTICAL FREEZER USER’S MANUAL Model : TVF172WMPA To ensure proper use of the appliance and your safety, please read the following user manual completely before operating this appliance.
- Page 2 The appliance has not been designed or manufactured for professional use. Teco declines all responsibility for damage deriving from improper use of the appliance. The freezer has undergone the necessary tests on the tightness of the refrigeration circuit and complies with the safety regulations for electrical appliances.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety precautions..........1 Name of parts and usage......... 3 Packing List ............ 4 Transporting the appliance ......5 Installation instructions........5 Reversing the Door ......... 6 Operating instructions ........8 Energy saving tips ........... 9 Maintenance ........... 9 Disconnection of the appliance ....... -
Page 4: Safety Precautions
• Do not place objects on top of the appliance which are magnetic, heavy or fi lled with water. • If the supply cord is damaged, it must be replaced by authorised TECO service personal, service agent or similarly qualifi ed persons in order to avoid a hazard. - Page 5 • Do not store fl ammable, explosive, volatile and highly corrosive materials in the freezer. Containers with fl ammable gases or liquids can leak at low temperature. There is a risk of explosion or fi re. • Do not splash water on the appliance. It may cause malfunction or electric shock.
-
Page 6: Name Of Parts And Usage
NAME OF PARTS AND USAGE 1. Temperature Control 2. Freezer Drawer 3. Freezer Compartment Cover 4. Adjustable Foot 5. Glass Shelf The freezer you purchased is subject to continuous improvement, which may not be completely consistent with the manual, however the functions and operating methods will not change. -
Page 7: Packing List
PACKING LIST Check the packing list that all items have been included. Part No. Model TVF172WMPA (see pg.3) Freezer Drawer 3 pieces Freezer 2 pieces Compartment Cover Glass Shelf 1 piece User manual 1 Copy Warranty 1 Copy Information Note: Product specifi cations are subject to change without prior notice. -
Page 8: Transporting The Appliance
TRANSPORTING THE APPLIANCE 1.The appliance must be transported only in a vertical position. The packing must be intact during the transportation. 2. When unpacking and re-packing the appliance, please memorise the position of each accessory of the appliance when unpacking it. When re-packing the appliance for transportation, ensure all accessories are secured before transportation. -
Page 9: Reversing The Door
REVERSING THE DOOR To reverse the freezer door, ensure you have a phillips head screwdriver, a fl at blade screwdriver and an allen key that suit the screws required to swap the hinge. Unplug the freezer and empty all contents before proceeding. - Page 10 Step 6. Carefully tilt the freezer Fig. 4 back to access the bottom hinge assembly. NOTE: Do not tilt >45 . Using a phillips head screwdriver, remove the screws holding the hinge in Adjustable Bottom place. Unscrew the adjustable foot hinge foot from the opposite side.
-
Page 11: Operating Instructions
WARNING... -
Page 12: Energy Saving Tips
ENERGY SAVING TIPS 1. Adjust the temperature control to a setting that is acceptable for the storage of the food. This will reduce the power consumption. 2. Only open the door when required. Frequently opening the door will increase power consumption. 3. -
Page 13: Disconnection Of The Appliance
DISCONNECTION OF THE APPLIANCE If a power failure occurs, even in summer, the freezer could store food normally for some time. 1. Power failure During a power failure, do not put additional food in the appliance and reduce opening the door frequently. Place several ice cubes into each freezer drawer if power failure is anticipated beforehand, and place it in the top of the freezer. - Page 14 SYMPTOM: The freezer does not work. SUGGESTION: It may not be connected to the power supply (plug, power failure or blown fuse) and switched on. Check that the temperature dial is not set to 0 position. SYMPTOM: The freezer does not work effi ciently as expected. SUGGESTION: It may be caused by heavy frost on the ice box compartment, by a warm temperature setting or by frequently opening the door, or low voltage.
-
Page 15: Repairs, Service & Warranty
If you have a problem, and the problem persists after you have made the checks mentioned in the Troubleshooting section of this manual, contact: TECO Australia Service on 1300 660 037 (9am to 4pm AEST Mon to Fri) For warranty details please visit www.teco.com.au... -
Page 16: Specifications
SPECIFICATIONS TVF172WMPA Model Climate class Classifi cation of Class 1 installation and use Indoor use only Rated Total Gross Volume (L) Voltage (V) 220~240 Frequency (Hz) Noise Level (dB) Refrigerant type R600a Max. Ambient Operating temp ( 1420 Height Dimensions... - Page 17 LBE-PV...
