1. C ONTENTS Please make sure the following items are included with your IM25 unattended payment terminal. If any items are missing, contact your dealer. 1 x IM25 Unattended Payment Terminal 4 x M4 nuts 4 x M4 screws 1 x IM25 Mounting Bracket 2.
back cover reset button USB Type-C port Ethernet port (RJ45) RS232 (RJ45) Figure 3: view from all sides 3. I NSTALLATION SAM Cards...
Page 4
Figure 4: SAM card slots The 2 SAM cards slots of the IM25 can be seen while the back cover is removed. To install a SAM card, open the card slot and insert the card into the slot with the contacts facing towards the IM25 and with the clipped corner of the card aligned with the slot, then lock the mount with the card inside.
Page 5
Slide the IM25 unit into place with the orientation shown in figure 7. The back portion of the device should rest securely inside the mounting bracket. Apply a torque of 0.4 to 0.6 Nm to each of the four M4 screws to secure the IM25 unit to its mounting bracket.
While the IM25 is designed to resist ingress of dust and liquids, it is not designed to resist pressurized liquids such as water hoses. Keep the back of the device away from dust and liquids as much as possible.
(RF) energy set by the Federal Communications Commission of the U.S. Government. This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm during normal operation.
